EN 10207 P265GH Hot Rolled Boiler Steel Plate for High Temperature Applications
Product Details
| Material Grade | P265GH | Technique | Hot Rolled |
|---|---|---|---|
| Width Range | 100-3000mm | Carbon Content | 0.20% |
| Silicon Content | 0.40% | Manganese Content | 0.80-1.40% |
| Phosphorus Content | 0.025% | Sulfur Content | 0.015% |
| Aluminum Content | 0.020% | Nitrogen Content | 0.012% |
| Yield Strength | 265-185 MPa | Tensile Strength | 410-530 MPa |
| Elongation | 22% | Impact Energy | 27-40 J |
| Thickness Range | ≤16mm To ≤250mm | ||
| Highlight | EN 10207 P265GH Steel Plate,Hot Rolled Boiler Steel Plate,High Temperature Applications Pressure Vessel Steel Plate |
||
Product Description
EN 10207 P265GH Carbon Steel Boiler Plate
P265GH is a heat-resistant pressure vessel steel defined in the EN 10028 system, designed specifically for high-temperature applications in demanding industrial sectors.
Material Overview
Grade P265GH is a non-alloy steel engineered for high-temperature applications, making it ideal for use in the oil and gas sector, chemical processing industries, and petrochemical applications where thermal resistance is critical.
Chemical Composition
| Element | C | Si | Mn | P | S | Al(min) | N |
|---|---|---|---|---|---|---|---|
| P265GH Max (%) | 0.20 | 0.40 | 0.80-1.40 | 0.025 | 0.015 | 0.020 | 0.012 |
| Additional Elements | Cr | Cu | Mo | Nb | Ni | Ti | V |
|---|---|---|---|---|---|---|---|
| P265GH Max (%) | 0.30 | 0.30 | 0.08 | 0.020 | 0.30 | 0.03 | 0.02 |
Mechanical Properties
| Thickness (mm) | Yield Min (MPa) | Tensile (MPa) | Elongation Min (%) | Impact Energy (KV J) min |
|---|---|---|---|---|
| ≤ 16 | 265 | 410-530 | 22 | 27 |
| 16 > to ≤ 40 | 255 | 410-530 | 22 | 27 |
| 40 > to ≤ 60 | 245 | 410-530 | 22 | 27 |
| 60 > to ≤ 100 | 215 | 410-530 | 22 | 27 |
| 100 > to ≤ 150 | 200 | 400-530 | 22 | 27 |
| 150 > to ≤ 250 | 185 | 390-530 | 22 | 27 |
Related Steel Grades
Ordinary Carbon Structural Steel: Q235A, Q275A, Q295A, SS400, AS3678-250, A36, SM400A, St37-2, SA283GrA, S235JR, S235J0, S235J2, S275JR, S275J0, S275J2, S275N, S275NL
Low Alloy High Strength Steel: Q345A, Q355B, Q390A, Q420A, S420N, LS420M, S460M, S420ML/S460ML, AS3678-300, AS3678-350, S460N, S460NL, SM490B, SM490YB, A572Gr50, A572Gr65, St52-3, S355JR, A709Gr50, A633C/D, A633E, SM520, SM570, S315, StE355, StE460, S355JO, S355J2, S355J2W, S355K2, S355N, S355NL
Offshore Structural Steel: S355G2+N, S355G3+N, S355G5+M, S355G6+M, S355G7+M, S355G7+N, S355G8+M, S355G8+N, S355G9+M, S355G9+N, S355G10+M, S355G10+N
Boilers & Pressure Vessels: SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, A515Gr65, A515G70, A516Gr60, A516Gr65, A516Gr70, A516Gr415, A516Gr485, SPV355, SPV450, 19Mn6, 15Mo3, 16Mo3, A573Gr70, SA285GrC, SB41, SP235GH, P265GH, P295GH, P275NH, P275NL1, P355GH, P355NH, P355NL1, SA662GrC, P460NH, A537CL1, A537CL2
Bridge Steel: Q235qc, Q345qc, Q370qc, Q420qc, Q345qDNH, Q370qDNH, A709-50F-2, A709-50T-2
EN 10207 Specification Details
- EN 10207 covers steels for simple pressure vessels, defined as any welded vessel subject to internal gauge pressure greater than 0.5 bar intended to contain air or nitrogen without firing.
- Steel certified to EN 10207 P265S is available as plate, cut plate, or profiles (cut shapes).
- EN 10207 P265S is pressure-purpose steel with minimum yield strength of 265 MPa and specified mechanical properties at elevated temperatures.
- Material is delivered in normalized condition or equivalent condition obtained by normalized rolling.
For custom requirements or additional information about our steel plate products, please contact our technical team for expert assistance.
