EN10028-2 P265GH Hot Rolled Steel Plate for High Temperature Applications in Boiler and Pressure Vessels
Product Details
| Model Number | P265GH | Technique | Hot Rolled |
|---|---|---|---|
| Width Range | 100-3000mm | Thickness Range | 5-300mm |
| Length Range | 3000-12000mm | Carbon Content | 0.20% |
| Silicon Content | 0.40% | Manganese Content | 0.80-1.40% |
| Phosphorus Content | 0.025% | Sulfur Content | 0.015% |
| Yield Strength | 265-185 Mpa | Tensile Strength | 390-530 Mpa |
| Elongation | 22% | Impact Energy | 27-40J |
| Production Capacity | 500000kgs | ||
| Highlight | EN10028-2 P265GH Steel Plate,Hot Rolled Steel Plate,High Temperature Applications Steel Plate |
||
Product Description
EN10028-2 P265GH Steel Plate
P265GH is a heat-resistant pressure vessel steel defined in the EN 10028 system. This non-alloy steel is specifically designed for high-temperature applications, making it ideal for use in the oil and gas sector, chemical processing industries, and petrochemical sectors.
Chemical Composition
Maximum Percentage by Mass
| Element | C | Si | Mn | P | S | Al(min) | N |
|---|---|---|---|---|---|---|---|
| P265GH | 0.20 | 0.40 | 0.80-1.40 | 0.025 | 0.015 | 0.020 | 0.012 |
| Element | Cr | Cu | Mo | Nb | Ni | Ti | V |
| P265GH | 0.30 | 0.30 | 0.08 | 0.020 | 0.30 | 0.03 | 0.02 |
Mechanical Properties
| Thickness (mm) | Yield Strength Min (MPa) | Tensile Strength (MPa) | Elongation Min (%) | Impact Energy (KV J) min |
|---|---|---|---|---|
| ≤ 16 | 265 | 410-530 | 22 | 27 |
| 16 to ≤40 | 255 | 410-530 | 22 | 27 |
| 40 to ≤60 | 245 | 410-530 | 22 | 27 |
| 60 to ≤100 | 215 | 410-530 | 22 | 27 |
| 100 to ≤150 | 200 | 400-530 | 22 | 27 |
| 150 to ≤250 | 185 | 390-530 | 22 | 40 |
Product Specifications
Steel Category: Steel for Boilers and Pressure Vessels
Standard: EN10028-2
Steel Grade: EN10028-2 P265GH
Available Dimensions
Thickness: 5-300mm
Width: 1500-3500mm
Length: 3000-12000mm
Applications
P265GH steel plate offers excellent tensile strength, good toughness, plasticity, and processing properties. It can be rolled into steel plates, shaped steel, and profile steel, making it suitable for constructing workshops, bridges, vessels, and various industrial applications. Delivery conditions typically include hot rolled, control rolled, or normalized states.
Related Steel Grades
Steel plates for boilers and pressure vessels: SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, A516Gr60, A516Gr65, A516Gr70, SPV355, SPV450, 19Mn6, 15Mo3, 16Mo3, and other related grades.
We are professional carbon and low alloy steel suppliers with extensive inventory available through our spot trade platform. Our services extend to numerous countries across Europe, America, Southeast Asia, Middle East, South America, and Africa.
