P265GH Hot Rolled Steel Plate for High Temperature Applications in Boiler and Pressure Vessel Construction

Minimum Order Quantity	1 Ton
Price	US $750-1,450 / Ton

Product Details

Model NO.	P265gh	Technique	Hot Rolled
Width	100-3000mm	Production Capacity	500000kgs
Carbon Content	0.20%	Silicon Content	0.40%
Manganese Content	0.80-1.40%	Phosphorus Content	0.025%
Sulfur Content	0.015%	Aluminum Content	0.020%
Nitrogen Content	0.012%	Yield Strength	265-185 Mpa
Tensile Strength	410-530 Mpa	Elongation	22%
Impact Energy	27-40 KV J
Highlight	P265GH Steel Plate , Hot Rolled Boiler Plate , High Temperature Applications Pressure Vessel Steel Plate

Leave a Message

Product Description

P265GH Steel Plate - Heat Resistant Pressure Vessel Steel

P265GH is a non-alloy heat resistant pressure vessel steel defined in the EN 10028 system, specifically designed for high temperature applications. This material is widely utilized in demanding industrial sectors including oil and gas, chemical processing, and petrochemical industries.

Chemical Composition (Maximum %)

Grade	C	Si	Mn	P	S	Al(min)	N
P265GH	0.20	0.40	0.80-1.40	0.025	0.015	0.020	0.012
Cr	Cu	Mo	Nb	Ni	Ti	V
0.30	0.30	0.08	0.020	0.30	0.03	0.02

Mechanical Properties

Grade	Thickness (mm)	Yield Min (MPa)	Tensile (MPa)	Elongation Min (%)	Impact Energy (KV J) min
P265GH	≤ 16	265	410-530	22	27
	16 > to ≤ 40	255	410-530	22	27
	40 > to ≤ 60	245	410-530	22	27
	60 > to ≤ 100	215	410-530	22	27
	100 > to ≤ 150	200	400-530	22	27
	150 > to ≤ 250	185	390-530	22	27

Related Steel Plate Grades

Ordinary Carbon Structural Steel Plate: Q235A, Q275A, Q295A, SS400, AS3678-250, A36, SM400A, St37-2, SA283GrA, S235JR, S235J0, S235J2, S275JR, S275J0, S275J2, S275N, S275NL

Low Alloy High Strength Steel Plate: Q345A, Q355B, Q390A, Q420A, S420N, LS420M, S460M, S420ML/S460ML, AS3678-300, AS3678-350, S460N, S460NL, SM490B, SM490YB, A572Gr50, A572Gr65, St52-3, S355JR, A709Gr50, A633C/D, A633E, SM520, SM570, S315, StE355, StE460, S355JO, S355J2, S355J2W, S355K2, S355N, S355NL

Offshore Structural Steel Plate: S355G2+N, S355G3+N, S355G5+M, S355G6+M, S355G7+M, S355G7+N, S355G8+M, S355G8+N, S355G9+M, S355G9+N, S355G10+M, S355G10+N

Steel Plates for Boilers and Pressure Vessels: SA387Gr11, SA387Gr22, 15MnNiR, 12Cr1MoVR, A515Gr60, (S)A515Gr65, (S)A515G70, (S)A516Gr60, (S)A516Gr65, (S)A516Gr70, (S)A516Gr415, (S)A516Gr485, SPV355, SPV450, 19Mn6, 15Mo3, 16Mo3, A573Gr70, SA285GrC, SB41, SP235GH, HII/P265GH, P295GH, P275NH, P275NL1, P355GH, P355NH, P355NL1, SA662GrC, P460NH, A537CL1, A537CL2

Steel Plate for Bridge Construction: Q235qc, Q345qc, Q370qc, Q420qc, Q345qDNH, Q370qDNH, A709-50F-2, A709-50T-2
