EN10028 P265GH P355GH Hot Rolled Boiler Grade Steel Plate for Pressure Vessels
Product Details
| Model NO. | P265GH P355GH | Technique | Hot Rolled |
|---|---|---|---|
| Width | 100-3000mm | Yield Strength | 185-265 MPa |
| Carbon Content | 0.20% | Manganese Content | 0.80-1.40% |
| Sulfur Content | 0.015% | Nitrogen Content | 0.012% |
| Copper Content | 0.30% | Silicon Content | 0.40% |
| Phosphorus Content | 0.025% | Tensile Strength | 410-530 MPa |
| Elongation | 22% | Impact Energy | 27-40 KVJ |
| Thickness Range | ≤16mm To ≤250mm | ||
| Highlight | EN10028 P265GH Steel Plate,EN10028 P355GH Steel Plate,Hot Rolled Boiler Plate |
||
Product Description
EN10028 P265GH P355GH Z25 Boiler Grade Steel Plate
EN10028 P265GH steel plate is a specialized material designed for boiler and pressure vessel applications. This boiler pressure vessel steel is characterized by a minimum yield strength of 185-265 MPa and excellent weldability properties, making it ideal for manufacturing boilers, pressure vessels, and pipes transporting hot liquids.
Key Features
- Minimum yield strength: 185-265 MPa
- Excellent weldability characteristics
- Ideal for boiler and pressure vessel construction
- Suitable for pipes transporting hot liquids
- Compliant with EN10164-2004 standards
P265GH Steel Chemical Composition
| Grade | C.% | Mn.% | S | N | Cu | Nb | Ti. | Si. | P. | AL | Cr. | Mo. | Ni | Vi |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| P265GH | 0.20 | 0.80-1.40 | 0.015 | 0.012 | 0.30 | 0.020 | 0.03 | 0.40 | 0.025 | 0.020 | 0.30 | 0.08 | 0.30 | 0.02 |
P265GH Steel Mechanical Properties
| Grade | Type | Thickness mm | Yield Strength MPa(min) | Tensile Strength MPa | Elongation % (min) | Impact Energy (KVJ) (min) | ||
|---|---|---|---|---|---|---|---|---|
| -20° | 0° | +20 | ||||||
| P265GH | Normalized | ≤16 | 265 | 410-530 | 22 | 27 | 34 | 40 |
| 16 > to≤40 | 255 | 410-530 | 22 | 27 | 34 | 40 | ||
| 40 > to≤60 | 245 | 410-530 | 22 | 27 | 34 | 40 | ||
| 60 > to≤100 | 215 | 410-530 | 22 | 27 | 34 | 40 | ||
| 100 > to≤150 | 200 | 400-530 | 22 | 27 | 34 | 40 | ||
| 150 > to≤250 | 185 | 390-530 | 22 | 27 | 34 | 40 | ||
As leading P265GH steel suppliers, we also provide other boiler grade steel plates including P295GH, P355GH, P355NH, P275NL2, P355NL1, and P355NL2. Contact us for pricing and availability information.
