ASTM A213 TP304 Cold-Drawn Seamless Stainless Steel Pipe with Polished Surface
Product Details
| Outer Diameter | 1.0-1220mm | Wall Thickness | 0.1-150mm |
|---|---|---|---|
| Length | 3m, 5.8m, 6m, 11.8m | Surface Treatment | Pickled, Annealed, Polished, Bright, Sand Blast, Hair Line |
| Material Grade | 316/316L | Carbon Content | ≤0.08 (316), ≤0.03 (316L) |
| Silicon Content | ≤1.00 | Manganese Content | ≤2.0 |
| Phosphorus Content | ≤0.035 | Sulfur Content | ≤0.03 |
| Chromium Content | 10-14 (316), 16.0-18.5 (316L) | Nickel Content | 16.0-18.5 |
| Tensile Strength | 515 MPa (316), 485 MPa (316L) | Yield Strength | 205 MPa (316), 170 MPa (316L) |
| Elongation | 40% | ||
| Highlight | ASTM A213 TP304 Stainless Steel Pipe,Cold-Drawn Seamless Stainless Steel Tube,Polished Surface SS Pipe |
||
Product Description
ASTM A312 TP316L Stainless Steel Seamless Pipe
High-quality SUS316L stainless steel seamless pipes manufactured to ASTM standards, ideal for marine and industrial applications requiring superior corrosion resistance.
Product Specifications
Standards & Materials
Standards: ASTM A249, ASTM A268, ASTM A269, ASTM A312
Materials: 316, 316L Stainless Steel
Brand: BAOSTEEL, TISCO
Materials: 316, 316L Stainless Steel
Brand: BAOSTEEL, TISCO
Dimensions & Tolerances
| Parameter | Specification |
|---|---|
| Outer Diameter | 1.0-1220mm (1/8"-48") |
| Wall Thickness | 0.1-150mm (SCH 5S-XXS) |
| Length | 3m, 5.8m, 6m, 11.8m, or custom |
| Outer Diameter Tolerance | ±0.2mm |
| Thickness Tolerance | ±0.02mm |
| Length Tolerance | ±5mm |
Surface Finishes
Pickled, annealed, polished, bright, sand blast, hair line, 2B, BA, 6K, 8K, 12K, No1
316 vs 316L Stainless Steel Comparison
316 and 316L stainless steels are molybdenum-containing alloys with superior performance compared to 310 and 304 stainless steel. The molybdenum content in 316L is slightly higher, providing excellent chloride corrosion resistance, making it ideal for marine environments. 316L has a maximum carbon content of 0.03%, allowing for use in applications requiring maximum corrosion resistance without post-weld annealing.
Chemical Composition
| Material | C | Si | Mn | P | S | Cr | Ni |
|---|---|---|---|---|---|---|---|
| 201 | ≤0.12 | ≤0.75 | 9.5-12.5 | ≤0.045 | ≤0.03 | 13-16 | 0.8-1.5 |
| 304 | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤0.03 | 18-19 | 8-10 |
| 316 | ≤0.08 | ≤1.00 | ≤2.0 | ≤0.035 | ≤0.03 | 10-14 | 16.0-18.5 |
| 430 | ≤0.12 | ≤0.75 | ≤2.0 | ≤0.04 | ≤0.03 | 16-18 | ≤0.6 |
Mechanical Properties
| Grade | UNS | Tensile Strength (MPa) min | Yield Strength (MPa) min | Elongation (%) min | Brinell Hardness (HB) max | Rockwell Hardness (HRB) max |
|---|---|---|---|---|---|---|
| 316 | S31600 | 515 | 205 | 40 | 217 | 95 |
| 316L | S31603 | 485 | 170 | 40 | 217 | 95 |
Applications
Stainless steel pipes are versatile economical sections used extensively in industrial and decorative applications including:
- Decoration Industry
- Kitchenware
- Building Construction
- Elevator Components
- Upholstery
- Staircase Handrails
- Window Protection
- Railings
- Furniture
Packaging
- 1pc/plastic bag
- 10-20 pcs/bundle, fastened by film
- 50-70 pcs/wooden case
- Standard export seaworthy packaging available
Payment Terms
T/T, L/C
