253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications

  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
  • 253mA Hot Rolled Polished Stainless Steel Pipe and Seamless Tube for High Temperature Applications
Certification AISI, ASTM
Minimum Order Quantity 100 kg
Price US $3.65-10.85 / kg
Product Details
Model Number 1.4835/S30815/253mA Shape Round
Technique Hot Rolled Surface Treatment Polished
Outer Diameter 6-630mm Production Capacity 500000kgs
Max Temperature 1150°C Tensile Strength 600 MPa Min
Yield Strength 310 MPa Min Elongation 40% Min
Hardness 95 HRB Max Density 7800 Kg/m3
Elastic Modulus 200 GPa Thermal Conductivity 15.0 W/m.K At 20°C
Electrical Resistivity 850 NW.m
Highlight

253mA Stainless Steel Pipe

,

Hot Rolled Stainless Steel Tube

,

Polished Seamless Tube
Leave a Message
Product Description
1.4835/S30815/253mA Stainless Steel Pipe & Seamless Tube
UNS S30815 253MA stainless steel is a specialized grade that combines excellent high-temperature service properties with ease of fabrication. This austenitic stainless steel resists oxidation at temperatures up to 1150°C and provides superior performance to Grade 310 in carbon, nitrogen, and sulphur-containing atmospheres.
Key Features & Benefits
  • Excellent oxidation resistance up to 1150°C
  • Superior performance in carbon, nitrogen, and sulphur atmospheres
  • Good oxide stability and high elevated temperature strength
  • Excellent resistance to sigma phase precipitation
  • Maintains toughness even at cryogenic temperatures
  • Lower nickel content provides advantages in reducing sulphide atmospheres
Specifications & Standards
ASME SA 182, ASME SA 213, ASTM A 240, ASTM A 276, ASTM A 312, ASTM A 479, UNS S30815, Werkstoff 1.4835
Common Stainless Steel Grade Comparison
ASTM JIS AISI EN
S30100 SUS301 301 1.431
S30400 SUS304 304 1.4301
S30403 - 304L 1.4307
S31008 SUS310S 310S 1.4845
S31603 - 316L 1.4404
S32100 SUS321 321 1.4541
S41008 SUS410S 410S -
S43000 SUS430 430 1.4016
S43932 - - 1.451
S44400 SUS444 444 1.4521
S44500 SUS430J1L - -
Dimension Ranges
Width: 600mm - 2030mm
Thickness: 0.1mm - 120.0mm
Length: 300mm - 6000mm (Maximum 18000mm)
Surface Finish Options
No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating, color-coating, embossing
Applications
Typical applications for 253MA stainless steel include:
  • Furnace components (burners, retorts, conveyor belts, fans)
  • Jigs, baskets, rollers, and walking beams
  • Radiant tubes and electric heater elements
  • Refractory anchors, hoods, flues, and grates
  • Expansion bellows and petrochemical tube hangers
Chemical Composition
Element Min (%) Max (%)
C 0.05 0.10
Mn - 0.80
Si 1.10 2.00
P - 0.040
S - 0.030
Cr 20.0 22.0
Ni 10.0 12.0
N 0.14 0.20
Ce 0.03 0.08
Mechanical Properties
Property Value
Tensile Strength (MPa) min 600
Yield Strength 0.2% Proof (MPa) min 310
Elongation (% in 50mm) min 40
Rockwell B (HR B) max 95
Brinell (HB) max 217
Physical Properties
Property Value
Density (kg/m³) 7800
Elastic Modulus (GPa) 200
Mean Coefficient of Thermal Expansion (mm/m/°C) 0-100°C 17.0
Mean Coefficient of Thermal Expansion (mm/m/°C) 0-600°C 18.5
Mean Coefficient of Thermal Expansion (mm/m/°C) 0-1000°C 19.5
Thermal Conductivity (W/m.K) at 20°C 15.0
Thermal Conductivity (W/m.K) at 1000°C 29.0
Specific Heat 0-100°C (J/kg.K) 500
Electrical Resistivity (nW.m) 850
International Grade Equivalents
UNS No Euronorm Swedish SS Japanese JIS
S30815 1.4835 X9CrNiSiNCe21-11-2 2368 -
These comparisons are approximate only. The list is intended as a comparison of functionally similar materials not as a schedule of contractual equivalents. If exact equivalents are needed, original specifications must be consulted.
Alternative Material Options
Grade Selection Considerations
310 Carburising atmospheres require a higher nickel content
304H Lower cost alternative for operating temperatures below about 800°C
Nickel Alloys For carburising atmospheres or temperatures above 1100-1150°C maximum of 253MA
