ASTM A312 TP316L Cold-Drawn Seamless Stainless Steel Pipe with Polished Surface
Product Details
| Model NO. | 316L | Shape | Round |
|---|---|---|---|
| Technique | Cold-Drawing | Surface Treatment | Polished |
| Outer Diameter | 1.0-1220mm | Wall Thickness | 0.1-150mm |
| Length | 3m, 5.8m, 6m, 11.8m | Carbon Content | ≤0.03 |
| Molybdenum Content | 2.00~3.00 | Tensile Strength | 485 MPa |
| Yield Strength | 170 MPa | Elongation | 40% |
| Brinell Hardness | 217 HB | Rockwell Hardness | 95 HRB |
| Production Capacity | 500000kgs | ||
| Highlight | ASTM A312 TP316L Stainless Steel Pipe,Cold-Drawing Technique Seamless Pipe,Polished Surface SS Pipe |
||
Product Description
ASTM A312 TP316L SS Seamless Pipe - SUS316L Stainless Steel Pipe
High-quality ASTM A312 TP316L stainless steel seamless pipes designed for marine and industrial applications. These SUS316L stainless steel pipes offer superior corrosion resistance and mechanical properties.
Product Specifications
Standards: ASTM A249, ASTM A268, ASTM A269, ASTM A312
Material Grades: 316, 316L Stainless Steel
Available Specifications:
- Outer Diameter: 1.0-1220mm (1/8"-48")
- Wall Thickness: 0.1-150mm (SCH 5S-XXS)
- Length: 3m, 5.8m, 6m, 11.8m, or custom lengths
- Surface Treatments: Pickled, annealed, polished, bright, sand blast, hair line
316 vs 316L Stainless Steel Comparison
Both 316 and 316L stainless steels are molybdenum-containing alloys that provide enhanced performance compared to 310 and 304 stainless steels. The molybdenum content gives these steels excellent chloride resistance, making them ideal for marine environments.
316L Advantages: Maximum carbon content of 0.03% allows for use in applications that cannot be annealed after welding and require maximum corrosion resistance.
Chemical Composition Comparison
| Material | C | Si | Mn | P | S | Ni | Cr | Mo | N |
|---|---|---|---|---|---|---|---|---|---|
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.035 | ≤0.03 | 10.0~14.0 | 16.0~18.5 | 2.00~3.00 | ≤0.10 |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.0~14.0 | 16.0~18.0 | 2.00~3.00 | ≤0.10 |
Mechanical Properties Comparison
| Grade | UNS | Tensile Strength (MPa) min | Yield Strength (MPa) min | Elongation (%) min | Brinell Hardness (HB) max | Rockwell Hardness (HRB) max |
|---|---|---|---|---|---|---|
| 316 | S31600 | 515 | 205 | 40 | 217 | 95 |
| 316L | S31603 | 485 | 170 | 40 | 217 | 95 |
