2205 S32205 S31803 Duplex Stainless Steel Tube Cold Rolled with Polished Surface

Minimum Order Quantity	50 kg
Price	US $4.55-4.95 / kg

Product Details

Model Number	2205 S32205 S31803	Shape	Round
Technique	Cold Rolled	Surface Treatment	Polished
Outer Diameter	6-630mm	Material Grade	S31803
Thickness	0.8mm - 34mm	Length	5.8m, 6m
Diameter Tolerance	+/- 0.2mm	Thickness Tolerance	+/- 0.02mm
Length Tolerance	+/- 5mm	Chromium Content	21-23%
Nickel Content	4.5-6.5%	Molybdenum Content	2.5-3.5%
Nitrogen Content	0.08-0.2%
Highlight	2205 S32205 S31803 Duplex Stainless Steel Tube , Cold Rolled Duplex Stainless Steel Pipe , Polished Surface Duplex SS Pipes

Leave a Message

Product Description

Duplex Stainless Steel Tube 2205 S32205 S31803

High-performance duplex stainless steel pipes offering superior strength, corrosion resistance, and cost-effectiveness for demanding industrial applications.

Product Specifications

Parameter	Details
Product Name	Duplex Stainless Steel Pipe S31803 00Cr22Ni5Mo3N Duplex 2205
Product Type	Round SS Seamless Pipe
Standards	ASTM, GB, DIN, AISI
Material Grade	S31803, 2205
Outer Diameter	9.5mm - 813mm
Thickness	0.8mm - 34mm
Length	5.8m, 6m, or custom lengths
Tolerance	OD: ±0.2mm, Thickness: ±0.02mm, Length: ±5mm
Surface Treatment	Annealing, Pickling, Sandblasting
Testing	Squash Test, Extended Test, Water Pressure Test, Heat Treatment, NDT

Chemical Composition

Element	2205 (%)	2507 (%)
C	≤0.030	≤0.030
Si	≤1.00	≤0.80
Mn	≤2.00	≤1.2
P	≤0.03	≤0.035
S	≤0.02	≤0.02
Cr	21-23	24-26
Ni	4.5-6.5	6-8

Industry Applications

Petrochemical Industry Pipes and Tubes
Pharmaceutical Industry Equipment
Food Processing Industry
Aviation and Aerospace Components
Architectural Decoration Applications

2205 Duplex Stainless Steel Characteristics

Alloy 2205 (UNS S32305/S31803) is a duplex stainless steel composed of 22% chromium, 3% molybdenum, and 5-6% nickel-nitrogen alloy. It delivers exceptional strength, impact toughness, and comprehensive corrosion resistance.

Key Advantages

Superior Corrosion Resistance: Outperforms 316L and 317L austenitic stainless steel in pitting and crevice corrosion resistance.
High Strength: Twice the compressive strength of austenitic stainless steel, enabling weight reduction and cost savings.
Thermal Properties: Lower thermal expansion coefficient and higher thermal conductivity compared to austenitic grades.
Temperature Range: Optimal performance between -50°F to +600°F, with considerations for welded structures beyond this range.

Detailed Chemical Composition - 2205

Element	Content (%)
Ni	4.50-6.50
Cr	21.0-24.00
Si	≤1.00
Mn	≤2.00
C	≤0.03
S	≤0.03
P	≤0.04
Mo	2.5-3.5
N	0.08-0.2

Product Applications

Common applications include chemical processing, desalination, material handling, oil and gas mining, pulp and paper, and petrochemical industries. Products constructed from 2205 duplex stainless steel include:
