Cold Rolled 316 Stainless Steel Sheet with Polished Surface and Corrosion Resistance for Construction
Product Details
| Model NO. | 316 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Polished |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Thickness | 0.3mm-25mm |
| Width | 1000,1219,1250,1500mm | Carbon Content | ≤0.03 |
| Manganese Content | ≤2.0 | Nickel Content | 10.0-14.0 |
| Chromium Content | 16.0-18.0 | Molybdenum Content | 2.0-3.0 |
| Yield Strength | ≥170 N/MM2 | Tensile Strength | ≥485 N/MM2 |
| Elongation | ≥40% | ||
| Highlight | Cold Rolled Stainless Steel Sheet,Polished Surface SS 316L Sheet,Corrosion Resistant 316 Stainless Steel Plate |
||
Product Description
316 Stainless Steel Sheet
High-quality 316 stainless steel sheets designed for construction applications, available in thicknesses from 0.25mm to 3mm.
Product Features
- 316L: Low carbon version offering excellent resistance to inter-granular corrosion in corrosive environments
- 316Ti: Titanium-stabilized grade with excellent formability and good impact properties at extremely low temperatures
Product Specifications
Commodity: 300 Series 316L Stainless Steel Plate
Grades Available: 301, 302, 304, 304L, 316, 316L, 310S, 309S, 321, 310
Brands: TISCO, BAOSTEEL, POSCO, JISCO, LISCO
Certifications: SGS, BV, IQI, TUV, ISO
Thickness: 0.3mm - 25mm
Width: 1000mm, 1219mm, 1250mm, 1500mm (custom widths available)
Standards: ASTM, AISI, SUS, JIS, EN, DIN, GB, ASME
Chemical Composition & Properties
Chemical Composition (wt%)
| Specification | Grade | C | Mn | Ni | Cr | Mo | Ti |
|---|---|---|---|---|---|---|---|
| ASTM/JIS | 316L/022Cr17Ni12Mo2 | ≤0.03 | ≤2.0 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | - |
| JIS | SUS310S | ≤0.03 | ≤2.0 | 12.0-15.0 | 16.0-18.0 | 2.0-3.0 | - |
| ASTM/JIS | 316Ti/SUS 316Ti | ≤0.08 | ≤2.0 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 | 5*(C+N)-0.7 |
Mechanical & Physical Properties
| Spec | Grade | Y.S (N/mm²) | T.S (N/mm²) | EL (%) | HRB | Specific Heat (J/gºC) | Modulus of Elasticity (KN/mm²) |
|---|---|---|---|---|---|---|---|
| ASTM/GB | 316L/022Cr17Ni12Mo2 | ≥170 | ≥485 | ≥40 | ≤95 | 0.5 | 193 |
| JIS | SUS316L | ≥175 | ≥480 | ≥40 | ≤90 | 193 | |
| ASTM | 316Ti | ≥205 | ≥515 | ≥40 | ≤95 | 0.5 | 200 |
Applications
316L: Widely used in corrosion-susceptible environments and mechanical components requiring corrosion resistance without post-forming heat treatment
316Ti: Primarily used for industrial components requiring enhanced performance characteristics
Packaging & Delivery
MOQ: 1 Ton
Price Terms: FOB, CIF, CNF
Payment: L/C at sight or 30% TT deposit
Delivery Time: 5-10 days after deposit receipt
Samples: Free samples available (express charges borne by customer)
Container Specifications
Standard export packaging with Kraft paper and wooden trays
20ft GP: 5.8m × 2.13m × 2.18m (24-26 CBM, 23 MTS)
40ft GP: 11.8m × 2.13m × 2.18m (54 CBM, 27 MTS)
40ft HG: 11.8m × 2.13m × 2.72m (68 CBM, 27 MTS)
Stainless Steel Grade Comparison
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo | Hardness |
|---|---|---|---|---|---|---|---|---|---|
| 201 | ≤0.15 | ≤1.00 | 5.5-7.5 | ≤0.060 | ≤0.030 | 3.5-5.5 | 16.0-18.0 | - | HB≤241, HRB≤100, HV≤240 |
| 304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0-11.0 | 18.00-20.00 | - | HB≤187, HRB≤90, HV≤200 |
| 316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00-14.00 | 16.0-18.0 | 2.00-3.00 | HB≤187, HRB≤90, HV≤200 |
| 316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.00-14.00 | 16.0-18.0 | 2.00-3.00 | HB≤187, HRB≤90, HV≤200 |
| 410 | ≤0.15 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.030 | ≤0.060 | 11.5-13.5 | - | HB≤183, HRB≤88, HV≤200 |
| 430 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.040 | ≤0.03 | - | 16.00-18.00 | - | HB≤183, HRB≤88, HV≤200 |
