Cold Rolled ASTM A240 XM-21 Stainless Steel Sheet with Pickling Surface for Industrial Applications

Certification	AISI, ASTM
Minimum Order Quantity	150 kg
Price	US $2.98-4.25 / kg

Product Details

Shape	Flat	Technique	Cold Rolled
Surface Treatment	Pickling	Specification	12202440, 15003000, 15006000, 20006000mm
Thickness	Cold Rolled 0.3 - 3.0mm Hot Rolled 4.0 - 10.0mm	Standard Size	Cold Rolled 10002000mm 12192438mm Hot Rolled 1500*6000mm
Surface	2B BA NO.4 Hailrline Mirror 8K .etc	Carbon Content	0.08
Manganese Content	2.00	Phosphorus Content	0.045
Sulfur Content	0.030	Silicon Content	0.75
Chromium Content	18.0 - 20.0	Nickel Content	8.0 - 10.5
Nitrogen Content	0.16 - 0.30
Highlight	Cold Rolled Stainless Steel Sheet , Pickling Surface Stainless Steel Plate , ASTM A240 XM-21 Stainless Steel

Leave a Message

Product Description

ASTM A240 XM-21 Stainless Steel Sheet & Plate (UNS S30452)

ASTM A240 XM-21 Stainless Steel Sheet / Stainless Steel Plate UNS S30452 Stainless Steel

Product Specifications

Products	XM-21 Stainless Steel Sheet
Thickness	Cold Rolled: 0.3 - 3.0mm Hot Rolled: 4.0 - 10.0mm
Standard Size	Cold Rolled: 1000×2000mm, 1219×2438mm Hot Rolled: 1500×6000mm
Surface	2B, BA, NO.4, Hairline, Mirror 8K, etc.
Brand	TISCO, JISCO, POSCO, BAOSTEEL
Standard	ASTM A240 / JIS G4305 / EN 10088-2
Other Grades	201, 202, 301, 304, 304L, 309S, 310S, 316L, 316Ti, 317L, 321, 347, 405, 410, 420, 430, 440, 441, 443, 444, 2205, 2507, etc.
Our Service	Slit Cutting, Surface Processing

UNS S30452 (XM-21) Stainless Steel Overview

S30452 stainless steel is an austenitic stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the annealed condition. XM-21 is the ASTM designation for this material, while S30452 is the UNS number.

This material has a moderately low ductility among wrought austenitic stainless steels.

Chemical Composition and Mechanical Properties

Chemical Composition:

Element	C	Mn	P	S	Si	Cr	Ni	Mo	N	Cu	Other
XM-21 (S30452)	0.08	2.00	0.045	0.030	0.75	18.0-20.0	8.0-10.5	---	0.16-0.30	---	---

Mechanical Properties:

Grade	Tensile Strength, min	Yield Strength, min	Elongation, min %	Hardness, max	Cold Bend
XM-21 Stainless Steel Coil	90 ksi / 620 MPa	50 ksi / 345 MPa	30%	241 Brinell / 100 Rockwell B	Not required
XM-21 Stainless Steel Plate	85 ksi / 585 MPa	40 ksi / 275 MPa	30%	241 Brinell / 100 Rockwell B	Not required

Applications

Grade 304N stainless steel is widely used in:

General service industries (petroleum, food, chemical, paper, fertilizer, fabric, aviation and nuclear)
Fluid, gas and oil transport
Pressure and heat transmission
Construction and ornament
Boiler heat exchangers

Alternative Names

A240 XM-21 stainless steel plate/coil, S30452 stainless steel plate/coil, Austenitic XM-21 stainless steel plate/coil

Additional Conditions Available

UT (Ultrasonic examination), AR (As Hot Rolled only), TMCP (Thermal Mechanical Control Processing), N (Normalized), Q+T (Quenched and Tempered), Z Direction Test (Z15, Z25, Z35), Charpy V-Notch Impact Test, Third Party Test (such as SGS Test), Coated or Shot Blasting and Painting.
