Cold Rolled SUS436L Stainless Steel Sheet with Polished Surface for Corrosion Resistant Automotive Exhaust Applications

Certification	AISI, ASTM, EN
Minimum Order Quantity	100 kg
Price	US $1.75-2.35 / kg

Product Details

Model Number	436L	Shape	Flat
Technique	Cold Rolled	Surface Treatment	Polished
Dimensions	12202440, 15003000, 15006000, 20006000mm	Carbon Content	≤0.12
Manganese Content	≤1.00	Silicon Content	≤1.00
Chromium Content	16.0~18.0	Molybdenum Content	0.75~1.25
Tensile Strength	531 MPa Min	Yield Strength	365 MPa Min
Elongation	22% Min	Hardness	HRB 89 Max
Thickness Range	0.2 - 200 Mm
Highlight	Cold Rolled Stainless Steel Sheet , Polished Surface SUS436L Sheet , Corrosion Resistant Automotive Exhaust Sheet

Leave a Message

Product Description

Automotive Exhaust Parts Materials SUS436L Stainless Steel Sheet

436 stainless steel is a modified steel grade of 434 that reduces the tendency to "wrinkle" during relatively stringent stretch forming operations. 430 is used as a molded product for automotive interior trim panels, and uses 434 and 436 stainless steel when better corrosion resistance is required.

436 Stainless Steel Specifications

Standard: AISI, ASTM
Model Number: 436
UNS number: S43600

Chemical Composition

Element	Content (%)
Carbon C	≤ 0.12
Manganese Mn	≤ 1.00
Silicon Si	≤ 1.00
Chromium Cr	16.0 ~ 18.0
Nickel Ni2	-
Phosphorus P	≤ 0.04
Sulfur S	≤ 0.03
Molybdenum Mo	0.75 ~ 1.25
Nb	(5C ~ 0.80)

Mechanical Properties at Room Temperature (Annealed)

Property	Value
Ultimate Tensile Strength	77 KSI min (531 MPa min)
Yield Strength (0.2% Offset)	53 KSI min (365 MPa min)
Elongation	22% min
Hardness	HRB 89 max

Available Stainless Steel Products

Grades Available

201, 301, 304, 304L, 309S, 310S, 316L, 317L, 321, 409L, 410, 410S, 430, 439, 444, 904L, 2205, 2507, etc.

Available Finishes

NO.1, 2B, 2D, BA, NO.4, NO.8, 8K, mirror, hair line, sand blast, brush, etching, checkered, embossed, etc.

Dimensions

Parameter	Range
Thickness	0.2 - 200 mm
Width	4 - 2000 mm
Length	500 - 12000 mm / coil

Stainless Steel Grade Comparison

Grade	C	Si	Mn	P	S	Ni	Cr	Mo	Hardness
201	≤0.15	≤1.00	5.5/7.5	≤0.060	≤0.03	3.5/5.5	16.0/18.0	-	HB≤241,HRB≤100,HV≤240
304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	8.0/11.0	18.0/20.0	-	HB≤187,HRB≤90,HV≤200
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.00/14.00	16.0/18.0	2.00/3.00	HB≤187,HRB≤90,HV≤200
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	10.00/14.00	16.0/18.0	2.00/3.00	HB≤187,HRB≤90,HV≤200
410	≤0.15	≤1.00	≤1.25	≤0.060	≤0.03	≤0.06	11.5/13.5	-	HB≤183,HRB≤88,HV≤200
430	≤0.12	≤1.00	≤1.25	≤0.040	≤0.03	-	16.0/18.0	-	HB≤183,HRB≤88,HV≤200

Surface Finish Specifications

Surface	Feature	Manufacturing Method	Application
NO.1	Silver white matt	Hot rolled to specified thickness, then annealed and descaled	Does not require surface gloss
NO.2D	Silver white	Heat treatment and pickling after cold rolling	Applications without strict surface requirements, general materials, deep drawing
NO.2B	Gloss stronger than NO.2D	After NO.2D treatment, final pass lightly cold rolled by polishing rollers	General materials
BA	Bright as a mirror	Bright annealed surface processing with high reflectivity	Building materials, kitchen utensils
NO.3	Rough grinding	Using 100~200# grinding belt	Building materials, kitchen utensils
NO.4	Intermediate grinding	Polished surface obtained by grinding with 150~180# abrasive belt	Building materials, kitchen utensils
NO.240	Fine grinding	Grinding with 240# grinding belt	Kitchenware
NO.320	Very fine grinding	Grinding with 320# grinding belt	Kitchenware
NO.400	Gloss close to BA	Using 400# polishing wheel for grinding	General timber, construction timber, kitchen utensils
HL	Hairline grinding	Grinding with 150~240# abrasive material	Buildings, construction materials
NO.7	Close to mirror polishing	Using 600# rotary polishing wheel	Art and decoration
NO.8	Mirror grinding	Mirror grinding with polishing wheel	Reflector, decoration

Product Application
