2000mm Width 321 Stainless Steel Plate with 3.0 - 40.0mm Thickness for High Temperature Applications
Product Details
| Width | 2000mm | Thickness Range | 3.0 - 40.0mm |
|---|---|---|---|
| Model Number | 321 | Shape | Flat |
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Production Capacity | 50000kgs |
| Finish Options | SATIN, 2B, 2D, BA NO (8), CR, HR, No.1, 1D, No.4, BA, 8K, Hairline, Brush, Mirror | Forms Available | Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle) |
| Carbon Content | 0.08% | Chromium Content | 17.0-19.0% |
| Nickel Content | 9.0-12.0% | Yield Strength | 30 Ksi |
| Tensile Strength | 75 Ksi | ||
| Highlight | 2000mm Width Stainless Steel Plate,321 Stainless Steel Plate,3.0 - 40.0mm Thickness Stainless Steel Sheet |
||
Product Description
321 Stainless Steel Plate - 2000mm Width, 3.0-40.0mm Thickness
High-quality 321 stainless steel plates and sheets available in various dimensions and finishes, specifically designed for high-temperature applications.
Product Specifications
Product Type: 321 Stainless Steel Sheet, 321 Stainless Steel Plate
Specification: ASTM A240 / ASME SA240
Available Dimensions
Cold Rolled Sheets: 4ft×8ft (1219×2438mm)
Hot Rolled Plates: 5ft×20ft, 6ft×20ft (1500×6000mm, 1800×6000mm, 2000×6000mm)
Hot Rolled Plates: 5ft×20ft, 6ft×20ft (1500×6000mm, 1800×6000mm, 2000×6000mm)
Thickness Range: 0.6 to 80 mm
Available Widths: 1219mm, 1500mm, 1800mm, 2000mm
Available Lengths: 2m, 2.44m, 3m, 6m or custom requirements
Surface Finishes
SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror, and more.
Additional Services
Laser cutting, bending, welding, and polishing services available.
Available Forms & Shapes
Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate.
Grade 321 / 321H Stainless Steel Overview
321 stainless steel is a titanium-stabilized austenitic grade specifically designed for service in the 1000-1600°F temperature range. This stabilization provides excellent resistance to intergranular corrosion and polythionic acid stress corrosion cracking.
Welding & Machining: Readily welded by all common methods including submerged arc. Appropriate weld fillers are AWS ER347 bare wire and E347 covered electrodes. Machinability rating of 45% relative to AISI B1112.
Product Forms
Sheet, plate, coil, strip, wire, pipe, tube, bar, profile, round, flat, square, hexagonal.
Specifications & Certifications
- Grade 321/321H
- ASTM A240, ASME SA240, BS EN 10028-7, BS EN 10088-2, BS EN 10088-4
- EN 10088/2, EN 10088/4 with CE Marking
- NACE MR 0175/ISO 15156 Certification
Typical Applications
- Aircraft piston engine manifolds
- Expansion joints
- Firearms production
- Thermal oxidizers
- Refinery equipment
- High temperature chemical process equipment
Chemical Composition
| Element | 321 Composition (%) |
|---|---|
| Carbon | 0.08 |
| Chromium | 17.0-19.0 |
| Nickel | 9.0-12.0 |
| Manganese | 2.00 |
| Silicon | 0.75 |
| Nitrogen | 0.10 |
| Phosphorus | 0.045 |
| Sulfur | 0.030 |
| Titanium | 5(C+N) min / 0.70 max |
Mechanical Properties
| Property | 321 Requirements |
|---|---|
| Yield Strength, min. (ksi) | 30 |
| Tensile Strength, min. (ksi) | 75 |
| Elongation, min. (%) | 40 |
| Hardness, max. (Rb) | 95 |
International Grade Equivalents
| Grade | UNS No | British Standard | Euronorm | Swedish SS | Japanese JIS |
|---|---|---|---|---|---|
| 321 | S32100 | 321S31 | 1.4541 | 2337 | SUS 321 |
| 321H | S32109 | 321S51 | 1.4878 | - | SUS 321H |
Alternative Grade Comparison
| Alternative Grade | Selection Criteria |
|---|---|
| 304L | When resistance to intergranular corrosion is required without high-temperature strength needs |
| 3CR12 | For mild high-temperature environments up to approximately 600°C |
| 304H | For mild high-temperature environments up to approximately 800°C |
| 310 | For operating environments up to approximately 1100°C |
| S30815 (253MA) | For operating environments up to approximately 1150°C |
Additional Available Grades
201, 202, 304, 304L, 304H, 309S, 310S, 310H, 310Si2, 316L, 316Ti, 316LN, 317L, 321, 347, 409L, 410, 410S, 416, 420, 430, 431, 436L, 439, 441, 443, 444, S31803, S32750, 904L, S30815, S31254, C276, C4, 600, 625, and more.
