Laser Cutting 321 Stainless Steel Plate and Sheet in Thickness 0.6 - 30.0mm with Custom Cutting
Product Details
| Model NO. | 321 | Shape | Flat |
|---|---|---|---|
| Technique | Cold Rolled | Surface Treatment | Bright |
| Specification | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm | Thickness | 0.6 To 80 Mm |
| Width | 1219mm, 1500mm, 1800mm, 2000mm | Length | 2m, 2.44m, 3m, 6m Or As Required |
| Finish | SATIN, 2B, 2D, BA NO (8), CR, HR, No.1, 1D, No.4, BA, 8K, Hairline, Brush, Mirror | Carbon Content | 0.08 |
| Chromium Content | 17.0-19.0 | Nickel Content | 9.0-12.0 |
| Yield Strength | 30 Ksi | Tensile Strength | 75 Ksi |
| Elongation | 40% | ||
| Highlight | Laser Cutting Stainless Steel Plate,Thickness 0.6 - 30.0mm Stainless Steel Sheet,Custom Cutting 321 Stainless Steel |
||
Product Description
Laser Cutting 321 Stainless Steel Plate
Custom cutting service for 321 stainless steel plates in thickness range 0.6 - 30.0mm
Product Specifications
| Product Type | 321 Stainless Steel Sheet, 321 Stainless Steel Plate |
|---|---|
| Specification | ASTM A240 / ASME SA240 |
| Dimensions | Cold rolled 321 Stainless Steel Sheet 4ft*8ft [1219*2438mm] Hot rolled 321 Stainless Steel Plate 5ft*20ft, 6ft*20ft [1500*6000mm 1800*6000mm 2000*6000mm] |
| Thickness | 0.6 to 80 mm |
| Width | 1219mm, 1500mm, 1800mm, 2000mm |
| Length | 2m, 2.44m, 3m, 6m or as required |
| Finish | SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc. |
| Our Service | Laser Cutting, bending, welding, polishing |
Available Forms & Shapes
Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate
Grade 321 Stainless Steel Overview
321 stainless is a titanium stabilized grade commonly used for service in the 1000-1600°F temperature range. For service temperatures up to about 1600°F, a stabilizing treatment at 1550-1650°F, air cool, may be used to provide optimum resistance to intergranular corrosion and to polythionic acid stress corrosion cracking.
321 stainless is readily welded by all common methods including submerged arc. Appropriate weld fillers are AWS ER347 bare wire and E347 covered electrodes. 321 stainless is similar in machinability to 304 stainless steel with a machinability rating of 45% relative to AISI B1112.
Chemical Composition
| Element | 321 |
|---|---|
| Carbon | 0.08 |
| Chromium | 17.0-19.0 |
| Nickel | 9.0-12.0 |
| Manganese | 2.00 |
| Silicon | 0.75 |
| Nitrogen | 0.10 |
| Phosphorus | 0.045 |
| Sulfur | 0.030 |
| Titanium | 5(C+N) min / 0.70 max |
Maximum, unless range is indicated
Mechanical Properties
| Property | 321 |
|---|---|
| Yield Strength, min. (ksi) | 30 |
| Tensile Strength, min. (ksi) | 75 |
| Elongation, min. (%) | 40 |
| Hardness, max. (Rb) | 95 |
Typical Applications
- Aircraft piston engine manifolds
- Expansion joints
- Firearms production
- Thermal oxidizers
- Refinery equipment
- High temperature chemical process equipment
