Hastelloy C276 Round Bar Custom Cutting in Length UNS N10276 Alloy 276 With EN 10204-3.1 Certificate
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Round Bar | Grade | C276 |
|---|---|---|---|
| Diameter | 5-300mm | Length | Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Bright,black |
| Highlight | Hastelloy C276 round bar,UNS N10276 alloy bar,EN 10204-3.1 certified Hastelloy |
||
Product Description
Hastelloy C276 Round Bar Custom Cutting in Length UNS N10276 Alloy 276 With EN 10204-3.1 Certificate
More Specification Informations
| Products Name | Hastelloy C276 Nickel Alloy Round Bar |
| Diameter | 5-300mm |
| Length | custom cutting any length as request |
| Surface | bright, Black,pickling,polishing |
| Brand | DELTA |
| Service | cutting, Polishing |
| MOQ | 2 Kgs |
| Other Type | bar, strip,coil,pipe.sheet, plate,wire.etc |
| Packing | Wooden box |
| Loading Port | Shanghai Port |
| Price term | EXW,FOB,CIF,CFR |
| Deliver time | within 12 days |
Hastelloy C276 Round Bar Custom Cutting in Length UNS N10276 Alloy 276 With EN 10204-3.1 Certificate
Product Overview
Hastelloy® C276 (UNS N10276, W.Nr. 2.4819) is a premium nickel-molybdenum-chromium-tungsten alloy renowned for its exceptional corrosion resistance across a wide range of aggressive chemical environments—both oxidizing and reducing. Our Hastelloy C276 round bars are precision-manufactured to meet international standards and can be custom-cut to your exact length requirements, ensuring seamless integration into your industrial applications. Each batch is supplied with an EN 10204-3.1 Mill Test Certificate, guaranteeing full traceability, chemical compliance, and mechanical integrity.
Ideal for use in chemical processing, oil & gas, pollution control, and marine engineering, C276 round bars offer unmatched durability in the presence of chlorides, acids, and high-temperature corrosive media.
Chemical Composition (Weight %)
| Element | Content (%) |
|---|---|
| Nickel (Ni) | 52.0 – 60.0 |
| Molybdenum (Mo) | 15.0 – 17.0 |
| Chromium (Cr) | 14.5 – 16.5 |
| Iron (Fe) | ≤ 5.0 |
| Tungsten (W) | 3.0 – 4.5 |
| Carbon (C) | ≤ 0.01 |
| Manganese (Mn) | ≤ 1.00 |
| Silicon (Si) | ≤ 0.08 |
| Phosphorus (P) | ≤ 0.040 |
| Sulfur (S) | ≤ 0.030 |
| Cobalt (Co) | ≤ 2.5 |
Note: C + S ≤ 0.05% as per ASTM B574.
This balanced composition provides superior resistance to pitting, crevice corrosion, and stress corrosion cracking—even in wet chlorine, hypochlorite, and chloride-rich environments.
Mechanical Properties (Typical at Room Temperature)
| Property | Value |
|---|---|
| Tensile Strength (Rm) | ≥ 690 MPa (100 ksi) |
| Yield Strength (Rp0.2) | ≥ 283 MPa (41 ksi) |
| Elongation (A5) | ≥ 40% |
| Hardness (HB) | ≤ 241 |
| Density | 8.9 g/cm³ |
| Melting Range | 1325–1370°C (2417–2498°F) |
These properties ensure excellent formability, weldability, and structural reliability under demanding service conditions.
Product Standards & Certifications
Our Hastelloy C276 round bars comply with the following global specifications:
- ASTM B574: Standard Specification for Nickel-Molybdenum Alloy Rod
- ASME SB574
- UNS N10276
- W.Nr. 2.4819 (DIN/EN)
- ISO 6208
- NACE MR0175 / ISO 15156 (for sour service)
- EN 10204-3.1 Certificate: Full mill test report with chemical & mechanical data, heat number traceability, and conformity declaration
All products undergo rigorous quality control, including ultrasonic testing (UT), dimensional inspection, and surface finish verification.
Key Features
- ✅ Outstanding corrosion resistance in oxidizing & reducing acids (e.g., sulfuric, hydrochloric, phosphoric)
- ✅ Resistant to pitting, crevice corrosion, and SCC in chloride environments
- ✅ Weldable without post-weld heat treatment—no sensitization or carbide precipitation
- ✅ Stable performance from cryogenic to 1000°C (short-term)
- ✅ Custom lengths available: From 100 mm to 6000 mm (or as per client request)
- ✅ Surface finishes: Peeled, ground, polished, or black (as-rolled)
Equivalent Grades
| Region | Grade Designation |
|---|---|
| USA | UNS N10276, ASTM B574, ASME SB574 |
| Germany | W.Nr. 2.4819, NiMo16Cr15W |
| China | NS3304 |
| France | NC17D4M |
| Japan | NW 0276 |
| ISO | ISO 15156 (for oil & gas) |
Common Applications
Hastelloy C276 round bars are used to fabricate critical components in the most corrosive environments:
- Chemical Processing: Reactors, agitators, shafts, valves, pump parts
- Flue Gas Desulfurization (FGD): Scrubber internals, dampers, fans
- Oil & Gas: Downhole equipment, sour gas service components
- Pharmaceutical & Pulp/Paper: Bleaching vessels, digesters
- Waste Treatment: Acid neutralization systems
- Marine Engineering: Seawater piping, heat exchangers
- Nuclear Industry: Fuel reprocessing equipment
Its ability to withstand mixed acids, hot seawater, and contaminated process streams makes it indispensable in high-integrity systems.
Packaging & Shipping
To ensure safe delivery and prevent surface damage:
- Bars are individually wrapped in anti-rust paper or VCI film
- Bundled with steel straps and labeled with heat number, grade, dimensions, and certificate reference
- Packed in wooden crates or pallets compliant with ISPM 15 for international shipping
- Optional: Vacuum-sealed packaging for long-term storage
- Shipping worldwide via air, sea, or land freight
- Lead time: 3–15 days (stock items); 4–6 weeks for custom orders
All shipments include:
- Commercial Invoice
- Packing List
- EN 10204-3.1 Certificate
- Material Safety Data Sheet (MSDS)
Other Nickel-Based Alloys We Supply
In addition to Hastelloy C276, we offer a comprehensive range of high-performance nickel alloys in bar, plate, pipe, and sheet forms:
| Alloy Family | Common Grades |
|---|---|
| Hastelloy® | C22 (N06022), C2000 (N06200), B2/B3 (N10665/N10675), G30 (N06030), X (N06002) |
| Inconel® | 600 (N06600), 625 (N06625), 718 (N07718), X-750 (N07750) |
| Incoloy® | 800/800H (N08800), 825 (N08825), 925 (N09925) |
| Monel® | 400 (N04400), K500 (N05500) |
| Pure Nickel | Nickel 200/201 (N02200/N02201) |
| Duplex Stainless Steels | 2205 (S31803), 2507 (S32750), Zeron 100 (S32760) |
All products are available in standard or custom dimensions with full certification.
Available Product Forms
- Round Bars (Ø4 mm to Ø300 mm)
- Hexagonal & Square Bars
- Forged Rounds & Blooms
- Seamless Pipes & Tubes
- Plates & Sheets (0.5 mm – 100 mm thick)
- Flanges, Fittings, and Custom Machined Parts
Why Choose Our Hastelloy C276 Round Bars?
