UNS S31500 Stainless Steel Pipe Alloy 315 SS Pipe ASTM A790 Standard Custom Cutting in Length
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | UNS S31200 |
| Minimum Order Quantity | 500 kgs |
| Price | 4-8 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 14 days based on the quantity |
| Payment Terms | L/C,T/T,Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Seamless Pipe | Grade | UNS 31500 |
|---|---|---|---|
| Diameter | DN10 - DN400 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 4.0 - 50.0mm |
| Highlight | UNS S31500 stainless steel pipe,ASTM A790 alloy 315 SS pipe,custom cut stainless steel pipe |
||
Product Description
UNS S31500 Stainless Steel Pipe Alloy 315 SS Pipe ASTM A790 Standard Custom Cutting in Length
Products Specification
| Products Name | 315 Stainless Steel Seamless Pipe |
Grade: |
304 304L 309S 310S 314 315 316L 316Ti 317L 321 329 347H 410 2205 2507 S32760 904L 254SMO and equal grade in GB JIS EN DIN Standard |
| Standards: | ASTM A213M-94b ASTM A249M-94a ASTM A269-94a ASTM A312M-94b,ect. ASTM A790 |
| DIN 17456-85 DIN 17458-85 DIN 17459-92.ect | |
| JIS G3446-1994 JIS G3448-1997 JIS G3459-1997 JIS G3463-1994,ect. | |
| GB13296-1991 GB14975-2002 GB14976-2002,ect. | |
| Size: | ND5 - DN400 |
| Length: | 6m length or cutting any length as request |
| Applications: | fluid and gas transport, structure , boiler, heat exchanger, super heater |
UNS S31500 stainless steel pipe, also known as Alloy 315 SS pipe, is a versatile austenitic-ferritic duplex stainless steel product designed to balance the advantages of both austenitic and ferritic stainless steels. It is widely recognized for its excellent corrosion resistance, moderate strength, and good weldability, making it suitable for various industrial applications. Below is a detailed introduction covering its parameters, standards, specifications, similar grades, characteristics, and applications.
Key Parameters
-
Chemical Composition (Typical, %):
- Chromium (Cr): 18.0-20.0
- Nickel (Ni): 4.0-6.0
- Manganese (Mn): 4.0-6.0
- Silicon (Si): ≤1.0
- Carbon (C): ≤0.08
- Phosphorus (P): ≤0.040
- Sulfur (S): ≤0.030
- Nitrogen (N): 0.05-0.20
-
Mechanical Properties:
- Tensile Strength: ≥620 MPa
- Yield Strength (0.2% Offset): ≥310 MPa
- Elongation: ≥25%
- Hardness: ≤290 HBW
Standards Compliance
Alloy 315 stainless steel pipes are primarily manufactured in accordance with ASTM A790, a standard specification for seamless and welded duplex stainless steel pipe. This standard ensures consistent quality, dimensional accuracy, and performance across different production batches. Additional standards may apply based on specific industry requirements, such as ASME BPVC (for pressure vessel applications) or ISO 1127 (for general stainless steel pipe specifications).
Specifications
- Type: Seamless pipe, welded pipe (ERW, TIG, or LASER welded)
- Outer Diameter (OD): Typically ranges from 1/8 inch (3.18 mm) to 24 inches (609.6 mm), with custom sizes available.
- Wall Thickness (WT): From SCH 5S to SCH 160, including standard, extra-strong (XS), and double extra-strong (XXS) schedules; custom thicknesses are offered for specific needs.
- Length: Standard lengths include 6 meters (20 feet), 12 meters (40 feet), or cut-to-length as per customer requirements (custom cutting in length is available for precise project needs).
- Surface Finish: Annealed and pickled (AP), polished (BA, 2B, or 4K), or sandblasted, depending on application demands for corrosion resistance or aesthetics.
Equal Grade of Alloy 315
UNS S31500/Alloy 315 is comparable to other duplex or austenitic stainless steels with similar chemical and mechanical properties, including:
UNS S31500/Alloy 315 is comparable to other duplex or austenitic stainless steels with similar chemical and mechanical properties, including:
- UNS S31803/S32205 (Alloy 2205): A widely used duplex stainless steel with higher chromium and molybdenum content, offering superior corrosion resistance in harsh environments.
- UNS S32750 (Alloy 2507): A super duplex stainless steel with enhanced strength and corrosion resistance, suitable for extreme conditions (e.g., offshore oil and gas).
- UNS S30400 (304 Stainless Steel): An austenitic stainless steel with lower strength but excellent formability; often considered where moderate corrosion resistance is sufficient.
Characteristics
- Balanced Microstructure: Combines austenitic and ferritic phases (typically 50-50%), providing a good balance of strength and toughness.
- Corrosion Resistance: Resistant to general corrosion, pitting, and crevice corrosion in mild to moderate environments, such as freshwater, atmospheric conditions, and dilute acids.
- Weldability: Compatible with common welding processes (TIG, MIG, SMAW) with minimal risk of sensitization, though post-weld annealing may be recommended for critical applications.
- Cost-Effectiveness: Offers better strength than austenitic stainless steels (e.g., 304) at a relatively lower cost compared to super duplex grades, making it a cost-efficient choice for many industries.
Applications
Alloy 315 stainless steel pipes are utilized in various industries due to their versatile performance:
- Chemical Processing: For transporting mild acids, alkalis, and chemical solutions.
- Water Treatment: In pipelines for water distribution, wastewater treatment, and desalination plants.
- Oil and Gas: For non-critical onshore pipeline systems and storage facilities.
- Food and Beverage: In processing equipment and piping where hygiene and corrosion resistance are required.
- Construction: For structural piping, architectural components, and marine environments (mildly corrosive seawater conditions).
In summary, UNS S31500 (Alloy 315) stainless steel pipe under ASTM A790 standard is a reliable choice for applications requiring a balance of corrosion resistance, strength, and affordability, with the flexibility of custom cutting to meet specific project lengths.
