1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar

  • 1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar
  • 1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar
  • 1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar
  • 1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar
  • 1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar
Place of Origin China
Brand Name Delta
Certification ISO 9001
Model Number 1.4418 / S135 / F6NM / 0Cr13Ni5Mo / S41500
Minimum Order Quantity 500 kgs
Price 2500-3200 USD/Ton
Packaging Details wooden box or water resistant paper surround
Delivery Time 5 - 10 days
Payment Terms T/T, Western Union
Supply Ability 50 Ton per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Products Name 1.4418 Stainless Steel Bar Diameter 10 - 350mm
Length 6m Or Cutting Any Length As Request Surface Pickling Or Bright
Service Cutting Standard ASTM DIN GB EN
Other Products Round Bar, Square Bar, Flat Bar.etc Technique Hot Rolled
Leave a Message
Product Description

1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar



Products Specification



Products Name Stainless Steel Round Bar
Grade 1.4418 / S135 / F6NM / 0Cr13Ni5Mo / S41500
Products Diameter Range φ10mm - φ350mm
Length 6.1m/pcs or cutting any length as request
Surface Pickling finishing, bright finishing
Other Grade

304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,415,420,

430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc
Standard ASTM  JIS,GB,DIN EN
Service Cutting
Other Shape Square , Flat, Hexagonal, Round.etc
Loading Port Shanghai Port
MOQ 500 kgs



Product Information: Hot-Rolled & Forged 1.4418 Stainless Steel Round Bar

Material Overview

  • Grade: 1.4418 (X3CrNiMo13-4)
  • Category: Martensitic stainless steel
  • Composition: Chromium (12.5-14.5%), Nickel (3.5-4.5%), Molybdenum (0.8-1.5%), Low Carbon (≤0.05%)
  • Advantages: Combines high tensile strength with excellent corrosion resistance in chloride - rich environments.

Manufacturing Process

  • Hot Rolling: Utilizes high - temperature forming to refine grain structure and enhance ductility.
  • Forging: Apply directional force to improve density and eliminate internal defects, ensuring superior mechanical properties.

Product Features

  • Surface Quality: As - rolled finish or machined to precision tolerances (e.g., h11/h12).
  • Diameter Range: 12mm - 250mm (standard stock); larger sizes (up to 600mm) available on request.
  • Length Options: 5.8m, 6m, or custom - cut lengths with chamfered ends.

Technical Specifications

  • Mechanical Properties:
    • Tensile Strength: 800 - 1000 MPa
    • Yield Strength: ≥650 MPa
    • Elongation: ≥12%
    • Impact Resistance: ≥27 J (Charpy V - notch, room temperature)
  • Heat Treatment: Quenched and tempered to achieve optimal hardness (240 - 320 HB).

Applications

  • Marine Equipment: Shafts, fasteners, and components for offshore platforms.
  • Power Generation: Turbine parts, pump rods in hydroelectric plants.
  • Chemical Processing: Valves and fittings for corrosive fluid handling.
  • Automotive: High - stress components in racing and heavy - duty vehicles.

Certifications

  • EN 10204 3.2 material certificate
  • AD2000 W0 approval
  • NORSOK M - 630 compliant (upon request)

Quality Control

  • Ultrasonic testing (UT) for internal integrity
  • Magnetic particle inspection (MPI) for surface defects
  • Chemical composition analysis via PMI

Packaging & Logistics

  • Protection: Greased, wrapped in anti - rust paper, and bundled in wooden crates.
  • Shipping: Containerized or bulk shipments; worldwide delivery within 25 - 40 days.

Custom Solutions

  • Special Finishes: Electropolished, passivated, or coated (e.g., PTFE).
  • Non - Standard Sizes: Rapid prototyping for bespoke requirements.
  • Value - Added Services: Threading, fluting, or CNC machining.

Why Partner With Us?

  • Vertical Integration: From raw material sourcing to final inspection.
  • Technical Support: In - house metallurgists available for application consulting.
  • Sustainability: Certified production with reduced carbon footprint.

1.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar 01.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar 11.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar 21.4418 Stainless Steel Square Bar and Round Bar Forged And Hor Rolled Bright Polished Bar 3
