Marine & Saltwater Resistant 316Ti Stainless Steel Plate / 1.4571 Stainless Steel Sheet
| Place of Origin | China |
|---|---|
| Brand Name | TISCO BAOSTEEL |
| Certification | ISO |
| Model Number | 316Ti / 1.4571 |
| Minimum Order Quantity | 500 kgs |
| Price | 3000 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Plate | Grade | 316Ti / 1.4571 |
|---|---|---|---|
| Thickness | 0.6 - 80.0mm | Width | 1500mm 1219mm 1000mm |
| Surface | NO.1 | Brand | BAOSTEEL TISCO |
| Standard | ASTM A240/240M | Loading Port | Shanghai Port |
Product Description
Marine & Saltwater Resistant 316Ti Stainless Steel Plate / 1.4571 Stainless Steel Sheet
Products Specification
| Products Name | 316Ti Stainless Steel Plate |
| Main Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316TI, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L,630,631,254SMO,253MA,2205,2507.etc |
| Thickness | 3.0 - 80.0mm |
| Width | 1250mm,1500mm ,1800mm,2000mm, or custom other size as request |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Laser Cutting |
| Form | Plate / coil |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Brand | TISCO, LISCO,BAOSTEEL , POSCO, JISCO |
Unrivaled Performance, Limitless Possibilities
316Ti stainless steel sheet stands out as a premium choice in the realm of metallic materials. Compared with common stainless steel grades, its unique alloy composition, with the strategic addition of titanium, endows it with remarkable features that redefine industry standards.
Distinctive Alloy Composition
The chemical makeup of 316Ti stainless steel sheet is the cornerstone of its superior performance. With a precisely controlled carbon content capped at ≤0.08%, it minimizes the risk of carbide precipitation, which can lead to corrosion. A substantial chromium (16.00 - 18.00%) and nickel (10.00 - 14.00%) content forms a robust passive oxide layer, safeguarding the material from oxidation and general corrosion. The inclusion of 2.00 - 3.00% molybdenum further fortifies its resistance to pitting and crevice corrosion, especially in chloride - laden environments. What truly sets 316Ti apart is the addition of titanium, which ties up carbon atoms, preventing intergranular corrosion even under harsh thermal cycling conditions.
Superior Physical and Mechanical Attributes
- Physical Properties: Boasting a density of 7.98 g/cm³, 316Ti stainless steel sheet strikes an optimal balance between strength and weight. Its broad melting point range of 1375 - 1450 °C ensures stability across diverse thermal applications. With a thermal conductivity of 16 W/m·K at 100 °C, it efficiently manages heat transfer, while a coefficient of thermal expansion of 16.0×10⁻⁶/K (20 - 100 °C) allows for dimensional stability during temperature fluctuations.
- Mechanical Properties: The material exhibits a tensile strength of ≥515 MPa and a yield strength (0.2% offset) of ≥205 MPa, ensuring structural integrity under heavy loads. An elongation at break of ≥40% and a hardness (HB) of ≤200 make it highly ductile and formable, enabling complex shaping without cracking.
Outstanding Features
Unmatched Corrosion Resistance
In highly corrosive marine settings, where saltwater spray and humidity are constant threats, 316Ti stainless steel sheet outperforms standard grades. Its enhanced resistance to chloride - induced pitting means it can be used for seawater handling systems, ship hull components, and offshore rig structures without succumbing to premature corrosion. In chemical processing plants dealing with acids and alkalis, the material's ability to withstand aggressive chemical attacks ensures long - term durability of reactors, pipelines, and storage vessels.
Exceptional High - Temperature Stability
From the high - heat zones of power plant boilers to the exhaust systems of high - performance engines, 316Ti stainless steel sheet maintains its mechanical properties up to 800 °C. It resists oxidation and creep deformation, ensuring reliable operation in continuous high - temperature applications and reducing the need for frequent replacements.
Seamless Fabrication and Welding
Our 316Ti stainless steel sheets are engineered for ease of fabrication. Cold - forming processes such as stamping and bending can be carried out with precision, allowing for the creation of intricate shapes. When it comes to welding, its excellent weldability ensures that joints are not only strong but also retain the material's corrosion - resistant properties. Our in - house team of experts can provide detailed welding guidelines to ensure optimal results.
Production Excellence
Our 316Ti stainless steel sheets are manufactured using state - of - the - art facilities and processes. The melting stage involves a carefully controlled electric arc furnace process to ensure accurate alloy composition. After casting, the material undergoes hot rolling to achieve the desired thickness and shape, followed by cold rolling for improved surface finish and dimensional accuracy. Advanced heat - treatment processes are then applied to optimize the material's mechanical properties. Rigorous quality checks are conducted at every stage, from raw material inspection to the final product, ensuring that only the highest quality sheets reach our customers.
Available Specifications
- Thickness: Ranging from a thin 0.15 mm for applications requiring lightweight and flexibility to a robust 60 mm for heavy - duty structural uses.
- Width: Available in widths from 500 mm to 2500 mm to meet different project requirements.
- Length: Customizable lengths up to 15000 mm are offered to minimize waste and maximize efficiency in your projects.
- Surface Finishes: A variety of finishes are available, including 2B (dull matte finish suitable for general applications), BA (bright and smooth finish for decorative purposes), No. 4 (satin finish with a uniform grain for architectural elements), and 8K (mirror - like finish for high - end decorative applications).
Extensive Applications
- Food and Beverage Industry: Due to its hygienic properties, 316Ti stainless steel sheet is the go - to choice for food processing equipment, storage tanks, and conveyor belts. Its smooth surface prevents the accumulation of bacteria and food residues, ensuring compliance with strict hygiene standards.
- Medical Field: In the manufacturing of medical devices such as surgical instruments, implants, and hospital furniture, 316Ti's biocompatibility and corrosion resistance are crucial. It provides a safe and reliable material for applications that come into direct contact with the human body.
- Architectural Design: From modern skyscraper facades to interior decorative elements, 316Ti stainless steel sheet adds a touch of elegance and durability. Its resistance to weathering and staining makes it suitable for both indoor and outdoor architectural applications.
Quality Assurance and Certifications
Our 316Ti stainless steel sheets comply with multiple international standards, including ASTM A240, EN 10088, and JIS G4305. We are also certified by ISO 9001:2015 for our quality management system, ensuring consistent product quality. Additionally, our products have obtained relevant industry certifications for specific applications, such as the FDA certification for use in the food industry and medical - grade approvals for the healthcare sector.
Customer - Centric Services
We offer comprehensive pre - sales consulting to help you select the most suitable 316Ti stainless steel sheet for your project. Our after - sales service team is always on standby to address any concerns, provide technical support, and offer solutions for product - related issues. Whether you need custom - sized sheets, special surface treatments, or detailed material specifications, we are dedicated to meeting your unique requirements.
For more information, sample requests, or to place an order, please don't hesitate to contact our sales representatives. Experience the difference of 316Ti stainless steel sheet and elevate your projects to new heights.
