Premium CD4MCU Duplex Stainless Steel Hex Bars Heat Corrosion Resistant
| Place of Origin | China |
|---|---|
| Brand Name | Delta |
| Certification | ISO 9001 |
| Model Number | CD4MCU |
| Minimum Order Quantity | 500 kgs |
| Price | 4000 - 5500 USD/Ton |
| Packaging Details | wooden box or water resistant paper surround |
| Delivery Time | 5 - 10 days |
| Payment Terms | T/T, Western Union |
| Supply Ability | 50 Ton per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | CD4MCU Stainless Steel Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m Or Cutting Any Length As Request | Surface | Pickling Or Bright |
| Service | Cutting | Standard | ASTM DIN GB EN |
| Other Products | Round Bar, Square Bar, Flat Bar.etc | Technique | Hot Rolled |
| Highlight | Corrosion Resistant Stainless Steel Hex Bars,Heat Resistant Stainless Steel Hex Bars,Duplex Stainless Steel Hex Bars |
||
Product Description
Premium CD4MCU Duplex Stainless Steel Hex Bars Heat & Corrosion Resistant
Products Specification
| Products Name | Stainless Steel Round Bar |
| Grade | CD4MCU |
| Products Diameter Range | φ10mm - φ350mm |
| Length | 6.1m/pcs or cutting any length as request |
| Surface | Pickling finishing, bright finishing |
| Other Grade |
304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,420, 430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc |
| Standard | ASTM JIS,GB,DIN EN |
| Service | Cutting |
| Other Shape | Square , Flat, Hexagonal, Round.etc |
| Loading Port | Shanghai Port |
| MOQ | 500 kgs |
CD4MCU Duplex Stainless Steel Round Bar
Product Overview
CD4MCU is a high-performance duplex (ferritic-austenitic) stainless steel round bar offering exceptional corrosion resistance, high strength, and excellent wear resistance. Its unique composition, including chromium (Cr), molybdenum (Mo), and copper (Cu), makes it ideal for harsh environments such as seawater, chemical processing, and oil & gas applications.
Key Features & Benefits
✔ Superior Corrosion Resistance – Resists pitting, crevice corrosion, and stress corrosion cracking (SCC) in chloride-rich and acidic environments.
✔ High Strength & Toughness – Nearly double the yield strength of standard 300-series stainless steels (e.g., 316L).
✔ Excellent Wear & Erosion Resistance – Ideal for abrasive and high-flow conditions.
✔ Good Weldability & Fabrication Properties – Requires controlled welding techniques for optimal performance.
✔ Cost-Effective Solution – Longer service life reduces maintenance and replacement costs.
Technical Specifications
Chemical Composition (%)
| Element | Content |
|---|---|
| Carbon (C) | ≤0.04 |
| Chromium (Cr) | 24.5–26.5 |
| Nickel (Ni) | 4.75–6.00 |
| Molybdenum (Mo) | 1.75–2.25 |
| Copper (Cu) | 2.75–3.25 |
| Nitrogen (N) | 0.10–0.25 |
| Iron (Fe) | Balance |
Mechanical Properties
-
Tensile Strength: 750–1000 MPa
-
Yield Strength: ≥550 MPa
-
Elongation: ≥15%
-
Hardness: ≤290 HB
Available Sizes
-
Diameter Range: 10mm – 300mm (custom sizes available upon request)
-
Length: Standard 3m–6m, or cut-to-length
Standards & Certifications
-
ASTM A995/A995M (Castings for pressure-containing parts)
-
UNS J93370 (Unified Numbering System)
-
EN 1.4508 (European equivalent)
Applications
-
Oil & Gas: Subsea valves, pumps, and pipelines.
-
Chemical Processing: Reactors, heat exchangers, and acid tanks.
-
Marine & Offshore: Shafts, propellers, and seawater systems.
-
Power Generation: Flue gas desulfurization (FGD) components.
-
Pulp & Paper Industry: Bleaching equipment and digesters.
Similar Grades
-
F51 (1.4462 / 2205) – Standard duplex stainless steel (lower Cu).
-
F55 (1.4501 / 2507) – Super duplex with higher Cr, Mo, and Ni.
-
CD3MN (F53) – Duplex steel without copper addition.
Why Choose Our CD4MCU Round Bars?
✅ Premium Quality – Manufactured under strict industry standards.
✅ Customizable Sizes – Available in various diameters and lengths.
✅ Competitive Pricing – Cost-effective solution for demanding applications.
✅ Global Supply – Reliable delivery and logistics support.
