CD4MCU Alloy Stainless Steel Bars Ideal for Chemical Marine
| Place of Origin | China |
|---|---|
| Brand Name | Delta |
| Certification | ISO 9001 |
| Model Number | CD4MCU |
| Minimum Order Quantity | 500 kgs |
| Price | 4000 - 5500 USD/Ton |
| Packaging Details | wooden box or water resistant paper surround |
| Delivery Time | 5 - 10 days |
| Payment Terms | T/T, Western Union |
| Supply Ability | 50 Ton per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | CD4MCU Stainless Steel Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m Or Cutting Any Length As Request | Surface | Pickling Or Bright |
| Service | Cutting | Standard | ASTM DIN GB EN |
| Other Products | Round Bar, Square Bar, Flat Bar.etc | Technique | Hot Rolled |
| Highlight | Chemical Stainless Steel Bars,Alloy Stainless Steel Bars,Marine Stainless Steel Bars |
||
Product Description
CD4MCU Alloy Stainless Steel Bars Ideal for Chemical & Marine Applications
Products Specification
| Products Name | Stainless Steel Round Bar |
| Grade | CD4MCU |
| Products Diameter Range | φ10mm - φ350mm |
| Length | 6.1m/pcs or cutting any length as request |
| Surface | Pickling finishing, bright finishing |
| Other Grade |
304,304L,309S,310S,310H,316L,316Ti,316H,317L,321,329,347,410,420, 430F,431,440A/B/C,2205,2507,904l,254SMO,253MA,CD4MCU,XM-19,17-4PH,15-5PH,17-7PH,C276,600,601,625,718,800,800H,825,926.etc |
| Standard | ASTM JIS,GB,DIN EN |
| Service | Cutting |
| Other Shape | Square , Flat, Hexagonal, Round.etc |
| Loading Port | Shanghai Port |
| MOQ | 500 kgs |
MATERIAL DATA SHEET - Grade CD4MCu
MATERIAL CATEGORY - Duplex stainless steel - 25Cr-5Ni-2Mo-3Cu
MATERIAL SPECIFICATIONS - ASTM A959 (2004), A276, A312, A632, A176, A580, A564
CHEMICAL COMPOSITION (WEIGHT %)
- C (％): ≤ 0.04
- Si (％): ≤ 1.00
- Mn (％): ≤ 1.00
- P (％)≤: 0.040
- S (％)≤: 0.040
- Ni (％): 4.75 ~ 6.00
- Cr (％): 24.5 ~ 26.5
- Mo (％): 1.75 ~ 2.25
- Cu (%): 2.75 ~ 3.25
MECHANICAL PROPERTIES FINAL HEAT TREATMENT
- Condition: solution, annealed
- Tensile strength, σb/MPa: ≥ 689
- Yield strength, σ0.2/MPa: ≥483
- Elongation, δ (％): 16.0
- Reduction of area, ф (％): -
- Hardness | HRB: 94RB ~ 27RC
Stainless Steel Rod, Bar, Wire, Cold drawn, ground and polished
Standard length of bars: 2 - 3 meter.
Austenitic Stainless Steel for implants, with high corrosion resistance.
According to ISO 5832/1, F-138 Vacuum melt grade (VAR)
For surgical instruments, fracture fixation devices, screws for implants and many more similar applications.
PRODUCT DESCRIPTION
The alloy is usually produced by AOD / VOD /VIM followed by electroslag refining (ESR) / VAR if necessary for special purpose.
Bars and, where applicable, forgings are subjected to ultrasonic examination based on the different levels according to the buyers' requirements.
Bars are usually supplied black/bright in the annealed condition.
Final heat treatment - solution treatment / QT
TYPICAL APPLICATIONS
- Chemical equipment
- Mechanical parts used in the condition of corrosion resistance
- Bolt and nut
- Pressure vessel
PRODUCT PROFILE & FORMS
- Round bar / Wire rod (Diameter): 5.5mm to 550mm
- Square bar / Flat bar: 3mm to 1000mm
- Plate / Sheet steel / Steel strip: 0.1mm to 1000mm
- Width: 8mm to 1000mm
- Length: random length or based on the customer's special requirement.
- Forged steel shape: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.
