Heat Resistant TP314 / 1.4841 Stainless Steel Pipe 2% High Silicon 310S Tube
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 314 |
| Minimum Order Quantity | 500 kgs |
| Price | 8-12 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Seamless Pipe | Grade | 314 |
|---|---|---|---|
| Diameter | DN100 - DN400 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 4.0 - 50.0mm |
| Highlight | 2% High Silicon Stainless Steel Pipe,1.4841 Stainless Steel Pipe,Heat Resistant Stainless Steel Pipe |
||
Product Description
Heat Resistant TP314 / 1.4841 Stainless Steel Pipe 2% High Silicon 310S Pipe Tube
Products Specification
| Products Name | Stainless Steel Seamless Pipe |
Grade: |
304 304L 309S 310S 314 316L 316Ti 321 329 347H 410 2205 2507 904L 254SMO and equal grade in GB JIS EN DIN Standard |
| Standards: | ASTM A213M-94b ASTM A249M-94a ASTM A269-94a ASTM A312M-94b,ect. |
| DIN 17456-85 DIN 17458-85 DIN 17459-92.ect | |
| JIS G3446-1994 JIS G3448-1997 JIS G3459-1997 JIS G3463-1994,ect. | |
| GB13296-1991 GB14975-2002 GB14976-2002,ect. | |
| Size: | ND5 - DN400 |
| Length: | 6m length or cutting any length as request |
| Applications: | fluid and gas transport, structure , boiler, heat exchanger, super heater |
314 Stainless Steel Seamless Tube, 314 Stainless Steel welded Tube, 314 Stainless Steel Seamless Pipe, 314 Stainless Steel welded Pipe, 314 Stainless Steel Seamless Tubing, 314 Stainless Steel welded Tubing, 314 Stainless Steel Instrumentation Tubes Supplier, SS 314 Welded Tube, ASTM A312 TP 314 Stainless Steel Pipes, ASTM A312 TP 314 Stainless Steel Tube , SS 314 Tubing Bends, Hot finished seamless SS 314 tubing, SS 314 Capillary tube, SS 314 heater tubes, Cold drawn seamless SS 314 tubing, SS 314 Electric resistance welded Pipe, 314 Stainless Steel ERW Pipe
314 stainless steel tube, 1Cr25ni20Si2 as China GB steel number, belongs to austenitic stainless steel tube. Commonly referred to as stainless steel, its corrosion resistance mainly comes from chromium. Experiments show that the corrosion resistance of steel can be greatly improved only when the chromium content exceeds 12%. Therefore, the chromium content in stainless steel is generally not less than 12%. Due to the increase of chromium content, group also has a great influence on steel, when high chromium content and carbon content rarely, chromium can make the iron carbon balance, on the graph Υ area reduced, or even disappear, organizational structure, this kind of stainless steel for ferrite when heating does not occur, is called the iron grain size of stainless steel.
When the chromium content is low (but higher than 12%), the carbon content is high, the alloy from the high temperature cooling, easy to form martensite, so called this type of steel martensite stainless steel.
Nickel can be extended Υ area, make steel with austenitic organization. If the nickel content is sufficient to make the steel have austenitic structure at room temperature, then this steel is called austenitic stainless steel.
ASTM A312 TP314 Stainless Steel Seamless Pipes Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. |
| SS 314 | S31400 | 1.4841 |
UNS S31400 Stainless Steel Seamless Pipe Chemical Composition
| Grade | C | Ni | Si | S | Mn | P | Cr | Mo | |
| SS 314 | min. | - | 19.0 | 1.50 | - | - | - | 23.0 | - |
| max. | 0.25 | 22.0 | 3.00 | 0.03 | 2.0 | 0.045 | 26.0 | ||
Stainless Steel WERKSTOFF NR. 1.4841 Seamless Pipes Mechanical Properties
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 314 | 689 | 40 | 345 | 85 | 433 |
