TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler

  • TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler
  • TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler
  • TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler
  • TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler
  • TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler
Place of Origin China
Brand Name DELTA
Certification ISO
Model Number 314
Minimum Order Quantity 500 kgs
Price 8-12 USD/Kg
Packaging Details standard packing for export
Delivery Time 5 - 12 days based on the quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3 Ton per week
Product Details
Products Stainless Steel Seamless Pipe Grade 314
Diameter DN100 - DN400 Length 6m Or Custom Cutting Any Length As Request
Standard ASTM EN Service Cutting
Loading Port Shanghai Port Thickness 4.0 - 50.0mm
Highlight

Boiler Seamless Stainless Steel Pipe

,

X15CrNiSi25-20 Seamless Stainless Steel Pipe

,

DN400 Seamless Stainless Steel Pipe
Leave a Message
Product Description

TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 for Boiler



Products Specification



Products Name Stainless Steel Seamless Pipe

Grade:		 304 304L 309S 310S 314 316L 316Ti 321 329 347H 410 2205 2507 904L 254SMO and equal grade in GB JIS EN DIN Standard
Standards: ASTM A213M-94b ASTM A249M-94a ASTM A269-94a
ASTM A312M-94b,ect.
DIN 17456-85 DIN 17458-85 DIN 17459-92.ect
JIS G3446-1994 JIS G3448-1997 JIS G3459-1997 JIS G3463-1994,ect.
GB13296-1991 GB14975-2002 GB14976-2002,ect.
Size: ND5 - DN400
Length: 6m length or cutting any length as request
Applications: fluid and gas transport, structure , boiler, heat exchanger, super heater



TP314/1.4841/X15CrNiSi25-20 Chemical Composition

C Mn P S Si Cr Ni
≤0.25 ≤2.00 ≤0.045 ≤0.030 1.50－3.00 23.00－26.00 19.00－22.00



TP314/1.4841/X15CrNiSi25-20 Mechanical Properties

Tensile strength ≥689 MPa
Yield strength ≥345 MPa
Elongation (in 50 mm) ≥40%
Hardness, Rockwell HRB ≤85
Hardness, Brinell HB ≤433



Application of TP314 Stainless Steel Seamless Pipe

  • High-Temperature applications
  • Furnace conveyor systems
  • Heat Exchangers
  • Radiant tubes
  • Equipment for furnaces
  • Heat treatment components
  • Annealing and carburizing boxes

Packing Informations of Our Stainless Steel Pipe

  • Ply Wooden Boxes
  • PE Fabric Bundles
  • Standard seaworthy export packing
  • Plastic Bags, or as required

 Pipe Marking Informations on the Pipe

  • Supplier / Manufacturer Name or Custom Logo - on request
  • Specification
  • Material Grade
  • Nominal Size
  • Schedule or Wall Thickness
  • Method of Manufacturing (Seamless or Welded)
  • Heat Number

TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler 0TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler 1TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler 2TP314/1.4841/X15CrNiSi25-20 Seamless Stainless Steel Pipe Tube DN100 - DN400 For Boiler 3
