High Strength Inconel 625 Seamless Tube ASTM / ASME SB444 Compliant
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 625 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Inconel 625 |
|---|---|---|---|
| Diameter | DN10 - DN300 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 0.5 - 40.0mm |
| Highlight | ASTM/ASME SB444 Seamless Tube,High Strength Seamless Tube,Inconel 625 Seamless Tube |
||
Product Description
High-Strength Inconel 625 Seamless Tube – ASTM/ASME SB-444 Compliant
Products Specification
|
Model
|
Nickel Tubes Pipes
|
|||
|
Material Grade
|
Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc |
|||
|
Diameter
|
a) Capillary Tube Outer Diameter: 0.2mm-6.mm
Welding Tube Outer Diameter: 6.mm- 840mm
Seamless Tube Outer Diameter: 6mm-630mm
|
|||
|
b) Capillary Tube Wall Thickness: 0.02mm-2mm
Welding Tube Wall Thickness: 0.5-150mm
Seamless Tube Wall Thickness: 0.5-60mm
|
||||
|
c) Length: ≤500mm Or in coil
|
||||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
|
|||
|
b) Thickness: +/- 0.01mm
|
||||
|
c) Length: +/- 0.1mm
|
||||
|
Surface Treatment
|
Polishing,Annealing, Bright, Pickling
|
|||
|
Type
|
Welded,Seamless
|
|||
|
Shape
|
Round,Square,Irregular
|
|||
|
Application
|
medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.
|
|||
What Is Inconel 625 Pipe?
According to ASTM B444, a grade 2 seamless pipe is required to pass through hydrostatic testing. DIN 2.4856 Erw Pipe needs to follow the fiber stress that is allowed by conducting a nondestructive electric test. Apart from this Inconel 625 seamless pipes are passed through which include micro-macro test, chemical analysis, flattening test, hardness test, and so on. Inconel 625 welded pipe withstands severe corrosive conditions owing to the high nickel content. There is no impact on Nickel Alloy 625 Hollow Pipe even in the presence of neutral salts or alkaline environment. Nor does the severe corrosive environment affect Alloy 625, Clad Pipes.
ASTM B444 Inconel 625 Pipe Documentation
- as per EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
- Heat Treatment Charts
- Guarantee Letter
- Fumigation Certificates
- Form A for the purposes of the Generalized System of Preferences (GSP)
- NABL approved Laboratory Test Reports
- Quality Assurance Plan (QAP)
- Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
- Raw Material Test Reports
- Commercial Invoice which includes HS Code
- Test Certificates certifying NACE MR0103, NACE MR0175
- Material Traceability Records
Industrial Application Of ASME SB444 625 Inconel Pipe And Tube
- Evaporators for wet-process phosphoric acid containing H2SO4, HF and ferric salts
- Weld Overlay
- Flue gas desulfurization scrubbers
- Chemical process equipment handling mixed acids both oxidizing and reducing
Material Test Conducted On Alloy 625 Welded Pipe
- Mechanical Testing Such as Tensile of Area
- Pitting Resistance Test
- Intergranular Corrosion (IGC) Test
- Hardness Test
- Flattening Test
- Flaring Test
- Positive Material Identification – PMI Testing
- Chemical Analysis – Spectro Analysis
- Micro and MacroTest
Inconel 625 Tube Suppliers, Manufacture of ASTM B444 UNS N06625 Seamless Tubing for chemical, marine, oil and gas industry
inconel pipe suppliers, We Keep Bulk Stock of Nickel Alloy 625 Seamless and Welded Pipe at our stockyard, view Inconel 625 Tubing Price
A variety of Nickel chromium alloys are available in the market. However, Inconel 625 Pipe is the only one that provides high fabricability along with high strength and resistance to corrosion. Properties of Inconel 625 erw pipe dependent upon the dimensions and heat treatment that is used. They are available in different shapes and sizes like Inconel 625 square pipe and Alloy 625 rectangular pipe are a few examples.
The Inconel 625 Seamless Pipe is not affected by the oxidizing chemicals that might be present in liquid solutions or its environment. In a non-oxidizing environment Inconel, 625 welded pipe derives its resistance to corrosion from the high nickel and molybdenum. The High molybdenum also assists in resisting local crevice corrosion and pitting which was noted by Inconel 625 Pipe Suppliers in Mumbai. Inconel 625 Tubes are usually made up of this alloy. Inconel 625 exhaust tubes are said to be non-magnetic alloy.
To protect ASME Sb 444 Uns N06625 Welded Pipe from sensitization, niobium is added. According to Inconel 625, Pipe Suppliers adding niobium also prevents intergranular cracking. ASTM B444 UNS N06625 pipe shave 2 standard specifications ATSM B444, and ASME SB 444. Inconel 625 Pipe Price range from Rs.4,000 to Rs.59,000 .Inconel Alloy 625 Round Pipe are similar chemical as well as mechanical properties of ASME SB444 UNS N06625.
Nickel Alloy 625 Pipes are ductile and are readily formed by cold working. There are available in 2 types
- AMS 5581 type 1 (they are seamless and drawn)
- AMS 5581 type 2 ( they are welded and drawn)
On the other hand, Alloy 625 Tube is well known for its high tensile strength and high corrosion resistance. Inconel 625 Tubing maintains this high tensile strength at 2000 degrees F as well according to Inconel 625 Tube Suppliers.
Furthermore, in the presence of chloride ions, Inconel 625 Seamless Tubing is said to resist stress-related corrosion cracking. This is why Inconel 625 seamless Tubes do not show oxidation and corrosion so often. UNS N06625 Tube has a tensile strength of 1,35,000 -psi 930-MPa and yield strength of 75,000-psi 517 MPa. Inconel 625 Tubing Price starts at Rs.3200 in India which is the cheapest compared to other countries. Alloy 625 tubing is available in a variety of sizes and shapes.We are here to guide you through all the varieties of these pipes and assist you in making the right decision.
ASTM B444 Inconel 625 Pipe Documentation
- as per EN 10204 3.1 and EN 10204 3.2 Material Test Certificates (MTC)
- Heat Treatment Charts
- Guarantee Letter
- Fumigation Certificates
- Form A for the purposes of the Generalized System of Preferences (GSP)
- NABL approved Laboratory Test Reports
- Quality Assurance Plan (QAP)
- Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
- Raw Material Test Reports
- Commercial Invoice which includes HS Code
- Test Certificates certifying NACE MR0103, NACE MR0175
- Material Traceability Records
- Curran 1000 T Hybrid Epoxy
- Novolac Epoxy
- liquid epoxy coatings
- Thin Film Engineered Polymer Coatings
- IGS high velocity thermal spray (HVTS) coating solutions
- HVAC Chillers and Heat Exchanger Coatings
- Phenol Epoxy
- High Functionality Epoxy - Curran Coating
- Sakaphen- Shell and tube heat exchanger lining
- Surface Condenser Tube Sheet
Industrial Application Of ASME SB444 625 Inconel Pipe And Tube
- Evaporators for wet-process phosphoric acid containing H2SO4, HF and ferric salts
- Weld Overlay
- Flue gas desulfurization scrubbers
- Chemical process equipment handling mixed acids both oxidizing and reducing
Material Test Conducted On Alloy 625 Semaless Pipe
- Mechanical Testing Such as Tensile of Area
- Pitting Resistance Test
- Intergranular Corrosion (IGC) Test
- Hardness Test
- Flattening Test
- Flaring Test
- Positive Material Identification – PMI Testing
- Chemical Analysis – Spectro Analysis
- Micro and MacroTest
Stock List Of Alloy 625 Pipe And Tube
| Alloy | Product form | Dimension |
|---|---|---|
| INCONEL 625 (22 Cr/61 Ni/9 Mo) | Pipe; bright solution annealed, welded | 60.033 x 2.077 milimeter (2"nb sch 10s) |
| Pipe; pickled, seamless, annealed | 33.040 x 3.038 milimeter (1"nb sch 40s) | |
| Pipe; annealed, seamless | 4.050 x 0.075 milimeter | |
| Pipe; cold drawn, seamless, annealed, ground | 60.033 x 3.091 milimeter (2"nb Sch 40s) |
Chemical Resistance Guide ASME SB444 Inconel 625 Pipe And Tube
| Grade | Mn | C | Ni | Fe | Si | Cr2 | S | Al-Ti | |
| 625 | minimum | – | – | 58.0 | – | – | 20.00 | – | – |
| maximum | 0.050 | 0.010 | – | 5.00 | 0.050 | 23.00 | 0.015 | 0.040 | |
Equivalent Grades Table 625 Inconel Seamless Pipe
| Grade | GOST | UNS No | Japanese JIS | Old British | Euronorm | ||
| En | BS | AFNOR | No | ||||
| Inconel 625 | ХН75МБТЮ | N06625 | NCF 625 | NiCr22Mo9Nb | NA 21 | NC22DNB4M | 2.4856 |
