Nickel Alloy 625 Seamless Tube Superior Oxidation Pitting Resistance
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 625 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Inconel 625 |
|---|---|---|---|
| Diameter | DN10 - DN300 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 0.5 - 40.0mm |
| Highlight | Nickel Alloy 625 Seamless Tube,Inconel 625 Seamless Pipe,Alloy 625 Seamless Pipe |
||
Product Description
Nickel Alloy 625 Seamless Tube – Superior Oxidation & Pitting Resistance
Products Specification
|
Model
|
Nickel Tubes Pipes
|
|||
|
Material Grade
|
Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc |
|||
|
Diameter
|
a) Capillary Tube Outer Diameter: 0.2mm-6.mm
Welding Tube Outer Diameter: 6.mm- 840mm
Seamless Tube Outer Diameter: 6mm-630mm
|
|||
|
b) Capillary Tube Wall Thickness: 0.02mm-2mm
Welding Tube Wall Thickness: 0.5-150mm
Seamless Tube Wall Thickness: 0.5-60mm
|
||||
|
c) Length: ≤500mm Or in coil
|
||||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
|
|||
|
b) Thickness: +/- 0.01mm
|
||||
|
c) Length: +/- 0.1mm
|
||||
|
Surface Treatment
|
Polishing,Annealing, Bright, Pickling
|
|||
|
Type
|
Welded,Seamless
|
|||
|
Shape
|
Round,Square,Irregular
|
|||
|
Application
|
medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.
|
|||
Inconel 625 Pipe is a nickel chromium super alloy pipe that is made up of 58% nickel, 20% chromium, carbon, manganese, silicon, iron, sulfur, aluminum and titanium in the composition. The pipes are highly corrosion resistant. Navstar Steel is a leading manufacturer and supplier of the Inconel 625 Pipe and tubes. The material has 517MPa minimum yield strength and 930MPa minimum tensile strength.
The Alloy 625 Seamless Tubing comes in sizes ranging from 4mm to 219mm. There are welded, fabricated and LSAW pipes as well. The welded and EFW pipes range from 5mm to 1219.2mm in size. The wall thickness of the Inconel 625 Seamless Pipe ranges from 0.5mm 20mm. The pipes are specified for larger diameters with schedules ranging from 5 to 160. The pipes come in different forms such as round and hydraulic pipes. The lengths of the pipes vary as single random, double random and cut to lengths.
UNS N06625 Tube Schedules
| 1/8" IPS(.405"O. D.) | 3 1/2" IPS( 4.000"O. D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4" IPS(.540"O. D.) | 4" IPS(4.500"O. D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8" IPS(.675"O. D.) | 5" IPS( 5.563"O. D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2" IPS(.840"O. D.) | 6" IPS(6.625"O. D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4" IPS(1.050"O. D.) | 8 ” IPS(8.625"O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS:(1.315′O. D.) | 10" IPS(10.750"O. D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4" IPS(1.660"O. D.) | 12" IPS(12.750"O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2" IPS(1.900"O. D.) | 14" IPS(14.000"O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2" IPS(2.375"O. D.) | 16" IPS(16.000"O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2" IPS(2.875"O. D.) | 18" IPS (18.000"O. D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3" IPS( 3.500"O. D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
Inconel Din 2.4856 Welded Pipe Composition Standard
| Grade | C | Mn | Si | Fe | S | Cr2 | Al-Ti | Ni | |
|---|---|---|---|---|---|---|---|---|---|
| 625 | min. | – | – | – | – | – | 20.0 | – | 58.0 |
| max. | 0.10 | 0.50 | 0.50 | 5.0 | 0.015 | 23.0 | 0.40 | – | |
ASME SB444 Alloy 625 Hexagonal Pipe Characteristics
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
|---|---|---|---|---|---|
| 625 | Psi – 1,35,000 , MPa -930 | Psi – 75,000 , MPa – 517 | 42.5 | – | – |
