ASTM B444 Inconel 625 Seamless Pipe UNS N06625 Alloy For Harsh Environments
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | inconel 625 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Pipe | Grade | Inconel 625 |
|---|---|---|---|
| Diameter | DN10 - DN300 | Length | 6m Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Thickness | 0.5 - 40.0mm |
| Highlight | Harsh Environments Inconel 625 Seamless Pipe,ASTM B444 Inconel 625 Seamless Pipe,UNS N06625 Inconel 625 Seamless Pipe |
||
Product Description
ASTM B444 Inconel 625 Seamless Pipe – UNS N06625 Alloy for Harsh Environments
Products Specification
|
Model
|
Nickel Tubes Pipes
|
|||
|
Material Grade
|
Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc |
|||
|
Diameter
|
a) Capillary Tube Outer Diameter: 0.2mm-6.mm
Welding Tube Outer Diameter: 6.mm- 840mm
Seamless Tube Outer Diameter: 6mm-630mm
|
|||
|
b) Capillary Tube Wall Thickness: 0.02mm-2mm
Welding Tube Wall Thickness: 0.5-150mm
Seamless Tube Wall Thickness: 0.5-60mm
|
||||
|
c) Length: ≤500mm Or in coil
|
||||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
|
|||
|
b) Thickness: +/- 0.01mm
|
||||
|
c) Length: +/- 0.1mm
|
||||
|
Surface Treatment
|
Polishing,Annealing, Bright, Pickling
|
|||
|
Type
|
Welded,Seamless
|
|||
|
Shape
|
Round,Square,Irregular
|
|||
|
Application
|
medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.
|
|||
Inconel 625 Seamless Pipe proposal different dimensions of extraordinary temperature excellence, location obstacle, ingesting and breakdown opposition in a wide scope of natural and inorganic acids just as sulfides and chlorides. Inconel 625 Seamless Pipe according to AMS 5581 is only a case of cold drawn tubing frequently shaped by suppliers Combined. Similarly Inconel 625 Welded Pipe is the tradename of Singular Metals Group of Businesses and comparable to NR 2.4856, UNS N06625 etc.
Composition Standard of Nickel Alloy 625 Pipe
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
Mechanical Properties Chart of Inconel 625 Pipe
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Material Equivalent of Alloy 625 Pipe
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4MNiCr22Mo9Nb | NiCr23Fe |
Specification of Inconel Alloy 625 Pipe
| UNS: | N06625 |
| Specifications: | ASTM B444, ASTM B751, ASTM B829, ASTM B775, ASTM B705, ASTM B704, AMS 5581 |
| international Specifications: | ISO 6207, VdTüV 499, BS 3074NA21, DIN 17751, WERKSTOFF Nr 2.4856 |
Grade of Nickel Alloy Pipes we can supply
N08020 , INCOLOY Alloy 20 , N08028 , INCOLOY Alloy 28 , N08330 , INCOLOY , Alloy 330 ,
N08800, Paduan INCOLOY 800 , N08810 , Paduan INCOLOY 800H , N08825 , Paduan INCOLOY 825 ,
N06600, Inconel 600, N06601, Inconel 601, N06625, Inconel 625, INCOLOY Alloy 625 ,
N07718 , Inconel 718 , INCOLOY Alloy 718 , N07750 , Inconel X750 , N04400 , MONEL400 ,
Nickl200 , S66286 , N10276 , Hastelloy C-276 , N06455 , Hastelloy C-4 , N06022 , Hastelloy C-22 ,
N10665 , Hastelloy B-2 , N10675 , Hastelloy B-3 , N06030 , Hastelloy G-30 , INCOLOY Alloy A286 ,
N08926, Paduan INCOLOY 25-6Mo, dll.
2.4060,1.4980,1.4529,2.4460,1.4563,1.4886,1.4876,1.4876,2.4858,2.4816 ,
2.4851,2.4856,2.4856,2.4668,2.4669,2.4360,2.4375,2.4819,2.4610,2.4602 ,
2.4617,2.4660 , dll.
