ASTM B575 UNS N10276 / 2.4819 / Alloy 276 Plate / Sheet / Coil / Strips
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 1.0 - 20.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | ASTM B575 Alloy 276 Plate,2.4819 Alloy 276 Plate,UNS N10276 Alloy 276 Plate |
||
Product Description
ASTM B575 UNS N10276 / 2.4819 / Alloy 276 Plate /Sheet / Coil / Strips
Quick Informations
| Grade | Hastelloy C276 | Type | Sheet, Plate |
| Thickness | 1.0-25.0mm | Width | Within 1500mm |
| Length | Within 6m | Service | Laser Cutting |
While the Alloy C276 Sheet has a higher rate of work hardening in comparison to its austenitic counterpart grades, an in processing annealing may be required if the Nickel Alloy C276 Sheet is to be work hardened to a higher degree. A solution annealing process may be required if the Nickel C276 Strip undergoes a deformation rate of more than 15%.
ASTM B575 Alloy C276 Plate is resistant to general corrosion, stresscorrosion cracking, pitting and crevice corrosion in a broad range of severe environments. Alloy C276 Hastelloy plate has exceptional resistance to sulfuric acid and hydrochloric acid.
Specification and Material grade of C276 Hastelloy plate
| ASTM Specification | ASTM B575 |
|---|---|
| Standard | MSRR, AMS, BS |
| Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available |
| Thickness | 0.1mm to 100 mm Thk |
| Width | 10-2500mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper | Annealed |
| Condition | Polished on both sides |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Stock in form of | Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | POSCO, JISCO, TISCO, LISCO, BAOSTEEL |
| Test Report |
|
| Profiling |
To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
ASME SB575 Hastelloy C276 Plate Manufacturers, Hot Rolled JIS NW 6022 Plate exporter , 2B/ BA/ HL/ NO.1 finish ASTM B575 Hastelloy C276 Shim Sheets supplier, Check Hastelloy UNS N10276 Polished Plates Sizes
Specification and grade of Hastelloy Alloy C22 Plate/ Sheet
| UNS: | N10276 |
| Specifications: | ASTM B575, ASTM B906 |
Ready Stock of C276 Hastelloy Plate
| Hastelloy C276 Chequered Plate | C276 Hastelloy Quarto Plate |
| Nickel Alloy C276 Clad Plate | ASTM B575 UNS N10276 Tisco Plate |
| Hastelloy DIN 2.4819 Chequer Plate | Hastelloy Alloy C276 Tread Plate |
| ASTM B575 UNS N10276 Checker Plate | Nickel C276 Polished Plate |
| Hastelloy Alloy C276 Plate Mirror Finish | Nickel Alloy C276 Chequered Plate |
| Nickel C276 Plate Brushed Finish | Hastelloy C276 Hot Rolled Sheet |
| Nickel Alloy C276 10mm Plate | ASTM B575 UNS N10276 Cold Rolled Sheet |
| Hastelloy C276 1/4 Inch Plate | Hastelloy UNS N10276 Perforated Sheet |
| Hastelloy UNS N10276 Plate | Alloy C276 Rolling Plate |
| C276 Hastelloy Hot Rolled Plate | Nickel C276 Perforated Plate |
| Alloy C276 Cold Rolled Plate | Hastelloy 2.4819 Bbq Plate |
| Nickel C276 Plate 2b Finish | Nickel Alloy C276 Diamond Plate |
| Alloy Hastelloy C276 Plate | Hastelloy C-276 UNS N10276 Cold Rolled Plate |
| ASTM B575 C276 Hastelloy 2D Plate | Hastelloy UNS N10276 Polished Cold Drawn Plate |
| Hastelloy C276 Alloy Strip Tape | Hastelloy C276 N10276 Slitting Coil |
| Alloy C276 Hastelloy Hot Rolled Plate | Hastelloy UNS N10276 Polished Cold Drawn Plate |
| C276 Hastelloy Shim Sheet | 2.4819 Alloy C276 Flat Plate |
| Hastelloy C276 Alloy Strip Tape | Hastelloy C276 ASTM B575 Polish Plate |
| Alloy C276 Hastelloy Hot Rolled Plate | Hastelloy C276 Circle |
| Hastelloy 2.4819 Plate Mill Finish | Hastelloy DIN 2.4819 Thin Plate |
| ASTM B575 UNS N10276 Custom Cut Plate | Alloy C276 Sheet |
| Hastelloy UNS N10276 Checkered Plate | Hastelloy C276 Laser Cut Plate |
| Alloy C276 Embossed Plate | Hastelloy UNS N10276 Plasma Cutting Plate |
Hastelloy Alloy C276 Plate Mechanical Strength Table
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
UNS N10276 Sheet Chemical Composition Standard
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Equivalent grades of Nickel C276 Plate/ Sheet
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ??760 |
Distributor of Hastelloy C276 Sheets, Trader of Hastelloy C276 Perforated Coils, Check Alloy C276 Shim Sheet Price Per Kg, Ready Stock of DIN 2.4819 Strips. Hot Rolled C276 Hastelloy Hot Rolled Plates, ASTM B575 Hastelloy C276 Strips manufacturers.
