TP321 Stainless Steel Hexagonal Hollow Tube 321 Stainless Steel Hex Pipe S14 - S75mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 3200 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Hexagonal Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or As Request |
| Diameter | S14-S70 | Innner Diameter | 4 - 60mm |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | 321 Stainless Steel Hexagonal Hollow Tube,S14 Stainless Steel Hexagonal Hollow Tube,S75mm Stainless Steel Hexagonal Hollow Tube |
||
Product Description
TP321 Stainless Steel Hexagonal Hollow Tube 321 Stainless Steel Hex Pipe S14 - S75mm
|
Commodity
|
304 316 321 Hollow Hexagonal Stainless Steel Pipe
|
|
Grade
|
Austenitic: 304/L/H/N, 316/L/H/N/Ti, 321/H, 309/H, 310S, 347/H, 317/L, 904L
Duplex steel: S31803,S32205,S32750,S32760 |
|
Standard
|
ASTM A213, A312, ASTM A269,ASTM A778, ASTM A789, DIN 17456,DIN 17457,DIN 17459, JIS G3459, JIS G3463, GOS T9941,EN 10216, BS3605,
GB13296,etc. |
|
Technique
|
Hot Rolled / Cold Drawn
|
|
Type
|
Seamless pipe
|
|
Size
|
S14*6-8 - S80*55-70mm
|
|
Length
|
custom any length as request
|
|
Packing
|
In bundles, Nylon bags, wooden cases or as required
|
|
Delivery Time
|
Ready stocks 3-7 days, customized 7-10 days for customized size
|
|
MOQ
|
1 Ton
|
|
Export To
|
Singapore, Canada, Indonesia, Korea, USA, UK, Thailand,Saudi Arabia, Vietnam,India, Peru, Ukraine ,Brazil,South Africa, etc.
|
321 Stainless Steel Hexagonal Pipe – Technical Overview
1. Introduction
321 stainless steel hexagonal pipe is a hollow hexagonal bar made from titanium-stabilized austenitic stainless steel (321). The addition of titanium (Ti) enhances its resistance to intergranular corrosion, particularly in high-temperature environments (up to 900°C). It is widely used in aerospace, chemical processing, heat exchangers, and exhaust systems due to its excellent thermal stability and oxidation resistance.
2. Specifications
-
Shape & Dimensions:
-
Hexagonal across flats (S): 6mm to 50mm
-
Wall thickness (T): 0.5mm to 5mm
-
Length: 1m to 6m (custom lengths available)
-
-
Surface Finish: Smooth, polished, or matte finish options.
3. Standards Compliance
-
International Standards:
-
ASTM A312/A269 (Seamless & Welded Pipes)
-
ASTM A554 (Welded Mechanical Tubing)
-
EN 10296-2 (European Standard)
-
-
Chinese Standards:
-
GB/T 12770 (Welded Stainless Steel Pipes)
-
GB/T 14976 (Seamless Stainless Steel Pipes)
-
4. Chemical Composition (%)
| Element | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr | Ni | Ti | Fe |
|---|---|---|---|---|---|---|---|---|---|
| 321 | 0.08 | 0.75 | 2.00 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | ≥5×C% | Balance |
Key Feature: Titanium (Ti) ≥ 5×C% prevents chromium carbide precipitation, improving high-temperature performance.
5. Mechanical Properties
| Property | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) |
|---|---|---|---|---|
| 321 | ≥520 | ≥205 | ≥40 | ≤187 |
Note: Retains strength at elevated temperatures (up to 900°C).
6. Manufacturing Process
-
Material Preparation: 321 stainless steel billets (with Ti stabilization).
-
Forming:
-
Seamless Pipes: Hot extrusion or cold drawing.
-
Welded Pipes: Rolled into hexagonal shape and TIG welded.
-
-
Heat Treatment: Solution annealing (920–1150°C) followed by rapid cooling to dissolve carbides.
-
Surface Treatment: Pickling, passivation, or polishing for corrosion resistance.
7. Key Features
✅ High-Temperature Resistance: Stable up to 900°C (avoids sensitization).
✅ Intergranular Corrosion Resistance: Titanium prevents chromium depletion.
✅ Oxidation Resistance: Forms a protective Cr₂O₃ layer in oxidizing atmospheres.
✅ Good Weldability: Suitable for welded structures.
8. Packaging
-
Standard: Plastic end caps, bundled with steel straps, waterproof wrapping.
-
Special: Wooden crates for heavy-duty protection.
9. Applications
-
Aerospace: Jet engine components, exhaust systems.
-
Chemical Industry: High-temperature pipelines, reactors.
-
Heat Exchangers: Boilers, condensers.
-
Automotive: Exhaust manifolds, catalytic converters.
-
Architecture: Decorative structures requiring heat resistance.
Summary
321 stainless steel hexagonal pipe is ideal for high-temperature and corrosive environments, offering superior thermal stability and mechanical strength. Its titanium stabilization ensures long-term performance in critical applications.
Need customization or testing reports? Contact us for details!
