Bright Annealed SS Pipe SCH40S SCH80S Stainless Steel Tube in 6m Length Cutting Short Pieces
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | BA Stainless Steel Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or As Request |
| Diameter | 6 - 219mm Or As Clients Request | Wall Thickness | 0.4 - 8.0mm |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | Bright Annealed Stainless Steel Tube,6m Stainless Steel Tube,SCH40S Stainless Steel Tube |
||
Product Description
Bright Annealed SS Pipe SCH40S SCH80S Stainless Steel Tube in 6m Length Cutting Short Pieces
Products Specification
| Standard | ASTM A213, ASTM A269, ASME SA213, ASME SA269 |
| Pipe Type | Bright Annealed Stainless Steel Tubing |
| Grades | 304, 304L, 316, 316L, 321, 310S, 2205, 2507 |
| Dimensions | Outer Diameter (OD): 1.00 mm to 76.2 mm |
| Wall Thickness | 0.2 mm to 6.0 mm |
| Length | Up to 12 meters (custom lengths available upon request) |
| Manufacturing Process | Cold Drawn, Bright Annealed, Seamless |
| Material Surface Finish | Bright Annealed (BA), Mirror Polished, No. 4 Finish |
| End Type | Plain End (PE), Beveled End (BE), Threaded End (TE) |
| Certifications | ISO 9001, EN 10204 3.1 / 3.2, PED, ASME |
ASTM A269 TP316 Stainless Steel Tubing
ASTM A269 / A269M - 15a
Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
The ASTM A269 specification covers nominal-wall-thickness, seamless and welded austenitic steel tubing for general corrosion-resisting and low- or high-temperature service. All material shall be furnished in the heat-treated condition.
Upon completion, all material need:
- To be furnished in the heat-treated condition.
- Conform to the chemical composition requirements.
- Different mechanical test requirements that includes, flaring test, flange test, hardness test, and reverse flattening test are presented.
- To be subjected to the non-destructive electric test or the hydrostatic test.
- Grade TP 321 shall have a titanium content of not less than five times the sum of the carbon and nitrogen content and not more than 0.70 %.
- Grade TP 348 shall have a columbium plus tantalum content of not less than ten times the carbon content and not more than 1.10 %.
- The tubing sizes and thicknesses usually furnished to this specification are 1/4 in. [6.4 mm] in inside diameter and larger and 0.020 in. [0.51 mm] in nominal wall-thickness and heavier.
ASTM A269 TP316 Tube Specification
| INOX ASTM A269 Tubes Size | 15 NB to 150 NB IN |
|---|---|
| ASTM A269 TP 304 Tubing Wall Thickness | .035" -.095', (special wall thicknesses available) |
| Specialized in | Large Diameter Size |
| Stainless Steel A269M Tubing Type | Seamless / ERW / Welded / Fabricated / Hollow |
| ASTM A269 Grade TP316L Tubes Schedule | SCH5, SCH10, SCH40, STD, SCH80, SCH160 |
| SS A269 GR 321 Tubes Condition | Hot-Finished, Annealed, Cold-Drawn, Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| A269 UNS N08904 Tubes Form | U-Tube, Boiler, Straight, Rectangular, Capillary, Heat-Exchanger, Round, Coiled, Square, Hydraulic, Condenser |
| SS A269 UNS S31254 Tubes Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded. |
| Marking | All SA 269 6MO Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2 |
| ASTM A269 TP316 Tube manufacturers |
|
| We can also cut, thread, and groove ASTM A269 TP 304 Tubes to meet your specifications. | |
Material Grades
| Grade | UNS |
|---|---|
|
|
INOX ASTM A269 Seamless Tube
| Outside diameter | Wall thickness | Length |
|---|---|---|
| 5.0 ~ 203.2mm | As per requirement | Upto 6 Meters |
ASTM A269 TP 304 Welded Tube
| Outside diameter | Wall thickness | Length |
|---|---|---|
| 5.0 ~ 1219.2mm | 1.0 ~ 15.0 mm | Upto 6 Meters |
