ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | BA Stainless Steel Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or As Request |
| Diameter | 6 - 219mm Or As Clients Request | Wall Thickness | 0.4 - 8.0mm |
| Type | Seamless Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | TP316L Stainless Steel Pipe |
||
Product Description
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
Products Specification
| Standard | ASTM A213, ASTM A269, ASME SA213, ASME SA269 |
| Pipe Type | Bright Annealed Stainless Steel Tubing |
| Grades | 304, 304L, 316, 316L, 321, 310S, 2205, 2507 |
| Dimensions | Outer Diameter (OD): 1.00 mm to 76.2 mm |
| Wall Thickness | 0.2 mm to 6.0 mm |
| Length | Up to 12 meters (custom lengths available upon request) |
| Manufacturing Process | Cold Drawn, Bright Annealed, Seamless |
| Material Surface Finish | Bright Annealed (BA), Mirror Polished, No. 4 Finish |
| End Type | Plain End (PE), Beveled End (BE), Threaded End (TE) |
| Certifications | ISO 9001, EN 10204 3.1 / 3.2, PED, ASME |
Bright Annealed Stainless Steel 316L Pipe, SS 316L Bright Annealed Seamless Pipes, SS 316L BA Pipes, Stainless Steel 316L Bright Annealed Welded Tube Distributors, SS 316L Bright Annealed Tubing, SS UNS S31603 Bright Annealed Tube Exporter , SUS 316L BA Seamless Tube, AISI 316L Steel BA Welded Pipe Manufacturer, 316L Stainless Steel Bright Annealing Seamless Pipe, DIN 1.4404 / 1.4435 BA Tubes Supplier
Stainless Steel 316L BA Pipe, SS 1.4404 / 1.4435 Bright Annealed Pipe, SS 316L Bright Annealed Seamless Tube Traders , SS 316L BA Seamless Pipe, Stainless Steel S31603 BA Tubing, ASTM A312 Stainless Steel 316L Bright Annealed Pipe, ASTM A249/ A269 / A270 Stainless Steel 316L Bright Annealed Tube, Stainless Steel AISI 316L Bright Annealing Welded Pipe Stockists , Stainless Steel 316L Bright Annealed Piping Stockholders, Bright Annealed SS 316L Tube Dealers, 316L SS BA Welded Tube Manufacturers
SS 316L Bright Annealed Pipe and Tube Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 316L | S31603 | 1.4404 / 1.4435 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 |
Stainless Steel 316L BA Pipes and Tubes Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 - 18.00 | 2.00 - 3.00 | 10.00 - 14.00 | 68.89 min |
Bright Annealed SS 316L Pipe and Tubing Mechanical Properties
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 95 | 217 |
Stainless Steel Tube Bright Annealing Marking & Packing
- Marking according to MPS and Standard
- Stainless Steel Tubes Ends with Caps according to PO
- In Seaworthy Wooden Cases With Plastic Paper protect
- In Plywood Cases With Plastic Paper Protect(Recommend, All Plywood Cases made by ourselves with lower cost.)
- Steel Racks Package
- Hexagonal packing in Bundles
