Hastelloy C276 Sheet Plate 1.0mm 1.2mm 1.5mm in size 4ft*8ft Alloy UNS N10276
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 0.5 - 16.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | 4ft*8ft Hastelloy C276 Sheet Plate,1.2mm Hastelloy C276 Sheet Plate,1.5mm Hastelloy C276 Sheet Plate |
||
Product Description
Hastelloy C276 Sheet Plate 1.0mm 1.2mm 1.5mm in size 4ft*8ft Alloy UNS N10276
Products Specification
| Product Name | Hastelloy C276 Nickel Alloy Plate |
|---|---|
|
Standard |
ASTM EN DIN GB JIS |
| Thickness |
Cold Rolled: 0.6mm,0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm Hot Rolled:4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm Forged : 20 - 200mm custom any size as request |
| Standard Size |
Cold rolled Sheet 1219*2438mm Hot rolled Plates 1500*6000mm |
| Main Grade | 600,601,625,718,800,800H,800HT,926,C276,C4,Monel400 K500 904L 254SMO 654SO 317L.etc |
| Service | Laser Cutting any size as request |
| Other Products | Coil, Sheet, Plate, Wire, Round Bar, Square Bar,Pipe,Tube.etc |
Hastelloy C276 Sheets also contain carbon, manganese, silicon, sulfur, nickel, iron, chromium, molybdenum, and phosphorus in their chemical composition. These Alloy C276 sheets and plates come in a variety of specifications that include standards, dimensions, tolerance, applications, types, thickness, shape, size, form, hardness, and finishing. Hastelloy C276 plates are manufactured with physical and mechanical properties that include density, melting point, yield strength, tensile strength, elongation, modulus of expansion, thermal conductivity, and electrical conductivity. Plates and sheets exist in many forms, including coils, polished plates, foils, shim sheets, hot-rolled plates, cold-rolled sheets, strips, and circles.
UNS N10276 Hastelloy sheets are suitable for application in several industries, including offshore oil drilling, petrochemical, power generation, chemical equipment, food processing, gas processing, speciality chemicals, pharmaceutical equipment, heat exchangers, condensers, seawater equipment, and paper and pulp industry. Sheets and plates are also well suited for general purposes in aerospace, spacecraft, military applications, valves, shafts, infrastructure construction, and transportation.
Our Hastelloy Alloy C276 Sheets & Plates Specification
- Standard of Hastelloy C276 Sheet: ASTM B 575 B575 / ASME SB 575 / AMS 5540
- Size of Hastelloy C276 Sheet and Plate: 1219*2438mm , 1500 x 6000mm
- Thickness of Hastelloy C276 Sheet and Plate: 0.6mm,0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm,4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25.0mm,30.0mm
- Other Hastelloy C276 Products: Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) , Pipe, Bars.etc
Hastelloy C276 Hot Rolled Sheet
ASTM B575 Hastelloy Alloy C276 Hot Rolled Sheet, ASME SB575 Hastelloy C276 HR Sheets, UNS N10276 Hot Rolled Sheets, 2.4819 Hot Rolled Sheets, Nickel Alloy C276 Hot Rolled Sheet Exporter, Hastelloy C276 HR Plain Sheet Supplier, Hastelloy C276 2B Finish HR Sheets, Hastelloy C276 BA Finish HR Sheets, Hastelloy C276 HR Sheets, Hastelloy C276 Hot Rolled Sheets
Hastelloy C276 Cold Rolled Sheet
ASTM B575 Hastelloy Alloy C276 Cold Rolled Sheet, ASME SB575 Hastelloy C276 CR Sheets, UNS N10276 Cold Rolled Sheets, 2.4819 Cold Rolled Sheets, Nickel Alloy C276 Cold Rolled Sheet Exporter, Hastelloy C276 CR Plain Sheet Supplier, Hastelloy C276 2B Finish CR Sheets, Hastelloy C276 BA Finish CR Sheets, Hastelloy C276 CR Sheets, Hastelloy C276 Cold Rolled Sheets
Hastelloy C276 Hot Rolled Plate
ASTM B575 Hastelloy Alloy C276 Hot Rolled Plate, ASME SB575 Hastelloy C276 HR Plates, UNS N10276 Hot Rolled Plates, 2.4819 Hot Rolled Plates, Nickel Alloy C276 Hot Rolled Plate Exporter, Hastelloy C276 HR Plain Plate Supplier, Hastelloy C276 2B Finish HR Plates, Hastelloy C276 BA Finish HR Plates, Hastelloy C276 HR Plates, Hastelloy C276 Hot Rolled Plates
Hastelloy C276 Cold Rolled Plate
ASTM B575 Hastelloy Alloy C276 Cold Rolled Plate, ASME SB575 Hastelloy C276 CR Plates, UNS N10276 Cold Rolled Plates, 2.4819 Cold Rolled Plates, Nickel Alloy C276 Cold Rolled Plate Exporter, Hastelloy C276 CR Plain Plate Supplier, Hastelloy C276 2B Finish CR Plates, Hastelloy C276 BA Finish CR Plates, Hastelloy C276 CR Plates, Hastelloy C276 Cold Rolled Plates
Equivalent Grades Of Hastelloy C276 Sheets And Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
|---|---|---|---|---|---|---|
| C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Hastelloy C276 Sheet And Plates Chemical Properties
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Hastelloy C276 Sheet / Plate Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Hastelloy C-276 is a nickel-based superalloy with excellent corrosion resistance and high temperature properties. It is widely used in a variety of harsh environments, especially in highly corrosive media and high temperature conditions. The following are the main uses of Hastelloy C-276 sheets:
1. Chemical industry
Used in the manufacture of chemical reactors, heat exchangers, evaporators and piping systems.
Suitable for the treatment of sulfuric acid, hydrochloric acid, phosphoric acid, chlorine and other corrosive media.
Excellent performance in wet chlorine, chloride and organic acid environments.
2. Oil and gas industry
Used in offshore and onshore oil and gas production equipment such as pipelines, valves and pumps.
Suitable for high sulfur oil and gas environment, resistance to hydrogen sulfide (H₂S) and chloride corrosion.
3. Environmental protection and flue gas desulfurization (FGD) system
- Used in flue gas desulfurization equipment, resistant to sulfuric acid, chloride and fluoride corrosion.
- It is widely used in coal-fired power plants and industrial waste gas treatment systems.
4. Pharmaceutical and food processing
- For the manufacture of corrosion resistant reaction vessels, pipes and storage tanks.
- In line with health standards, suitable for high purity media processing.
5. Pulp and paper industry
- Used in bleaching equipment and chemical recovery systems to resist the corrosion of chlorine gas and chloride.
6. Nuclear industry
- Used for nuclear fuel reprocessing equipment to resist the corrosion of radioactive media.
7. Ocean engineering
- For seawater treatment equipment, desalination systems and offshore platforms, resistant to seawater and salt spray corrosion.
8. Aerospace
- For components in high temperature and corrosive environments, such as engines and exhaust systems.
9. Other applications
- Manufacture corrosion-resistant fasteners, flanges and seals.
- For heat exchangers and condensers in high temperature and pressure environments.
Hastelloy C-276 Main characteristics
- Excellent resistance to pitting corrosion, crevice corrosion and stress corrosion cracking.
- It performs well in both oxidizing and reducing media.
- Good weldability and processability.
Hastelloy C-276 sheet is a versatile material that is particularly suitable for use in extremely corrosive and high-temperature environments.
