Inconel 600 Nickel Alloy Round Bar UNS N06600 Cutting to Length Free
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | UNS N06600 |
| Minimum Order Quantity | 10 kgs |
| Price | 20-25 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Round Bar | Grade | Inconel 600 |
|---|---|---|---|
| Diameter | 10 - 350mm | Length | Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | Inconel 600 Nickel Alloy Round Bar |
||
Product Description
Inconel 600 Nickel Alloy Round Bar UNS N06600 Cutting to Length Free
Products Specification
|
Name
|
Incoloy Alloy Bar
|
|||
|
Grade
|
Hastelloy
|
Hastelloy C-276(C-4 /C-200 /C-22 /B-3 /B-2 ),Hastelloy-X ,HastelloyR-135
|
||
|
Monel Alloy
|
Monel400 Monel401 Monel404 Monel K500
|
|||
|
Inconel alloy
|
Inconel 600/N06600 , Inconel 601/N06601/2.4851 , Inconel625/N06625 690/N06690 ,Inconel 718/N07718/GH4169 , X-750/N07750/GH4145
|
|||
|
Incoloy alloy
|
Incoloy 800/N08800 , Incoloy 800H/N08810 ,Incoloy 800HT/N08811 , Incoloy 825/N08825/2.4858, Incoloy901/GH2901 ,Incoloy 903/GH2903 , Incoloy 925 ,Incoloy 926/N08926/1.4529
|
|||
|
Nimonic alloy
|
Nimonic80A /GH4080A , Nimonic90 /GH4090
|
|||
|
Udimet alloy
|
Udimet500 /GH4500 , Udimet A286 /GH2132
|
|||
|
Alloy 20
|
alloy20cb3 /N08020 , alloy20 alloy28 /N08028 , NS1403
|
|||
|
Size
|
Sheet
|
δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
|
||
|
Strip
|
0.05*5.0-5.0*250mm
|
|||
|
Pipe
|
φ6-273mm;δ1-30mm;Length 1000-8000mm
|
|||
|
Bar
|
φ4-50mm;Length 2000-5000mm
|
|||
|
Wire
|
0.01-10mm
|
|||
|
Standard
|
Sheet/Strip
|
Pipe
|
Bar
|
Wire
|
|
AMS 5542
AMS 5598 |
ASTM B637
|
ASTM B637
|
AMS 5698
AMS 5699 |
|
|
Density
|
8.0 g/cm³
|
|||
|
Melting point
|
1350-1400 °C
|
|||
Introduction to Inconel 600 bars
Inconel 600 is a nickel-chromium alloy with excellent corrosion resistance, high temperature strength and oxidation resistance. Widely used in high temperature and corrosive environments.
Main parameter
Chemical composition of Inconel 600 Alloy
- Nickel (Ni): ≥72%
- Chromium (Cr): 14-17%
- Iron (Fe): 6-10%
- Carbon (C): ≤0.15%
- Manganese (Mn): ≤1.0%
- Sulfur (S): ≤0.015%
- Silicon (Si): ≤0.5%
- Copper (Cu): ≤0.5%
Physical properties of Inconel 600 Alloy:
- Density: 8.47 g/cm³
- Melting point: 1354-1413°C
- Coefficient of thermal expansion: 13.3µm /m°C (20-100°C)
- Thermal conductivity: 14.9 W/m·K (100°C)
Mechanical properties of Inconel 600 Alloy Bar
- Tensile strength: ≥550 MPa
- Yield strength: ≥240 MPa
- Elongation: ≥30%
Specification
- Diameter: usually 5mm to 300mm
- Length: Usually 3 meters or 6 meters, can also be customized
- Shape: round bar, square bar, hexagonal bar, etc
Standard of Inconel 600 Round Bar
- ASTM: B166 (Nickel-chromium Iron Alloy bar)
- AMS: 5665 (Nickel alloy bar)
- DIN: 17752 (nickel-chromium alloy bar)
- GB: GB/T 15007 (Chinese standard)
Apply of Inconel 600 Round Bar
- Aerospace: Used in engine components, combustion chambers, etc.
- Chemical: Used for corrosion resistant equipment, such as reactors, heat exchangers, etc.
- Nuclear industry: Used for nuclear reactor components.
- Heat treatment: for high temperature furnace components.
- Marine engineering: for seawater treatment equipment.
Because of its excellent corrosion resistance and high temperature properties, Inconel 600 bars are widely used in many industrial fields.
