Duplex F60 Stainless Steel Round Bar / Hot Rolled Forged 2205 Rod ASTM A276
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 440C |
| Minimum Order Quantity | 500 kgs |
| Price | 2200 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507,440C.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Duplex F60 Stainless Steel Round Bar,ASTM A276 Stainless Steel Round Bar,Hot Rolled Stainless Steel Round Bar |
||
Product Description
Duplex F60 Stainless Steel Round Bar / Hot Rolled Forged 2205 Rod ASTM A276
Products Specification
| Products | Stainless Steel Bar |
| Grade | F60 / 1.4462 / S32205 / 2205 |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
2205 duplex stainless steel rod introduction
2205 duplex stainless steel rod is a kind of stainless steel material composed of ferrite and austenite two phases, with excellent corrosion resistance, high strength and good welding performance, widely used in chemical industry, petroleum, offshore engineering and other fields.
Main parameter
Chemical composition (%) :
- Carbon (C): ≤0.03
- Silicon (Si): ≤1.00
- Manganese (Mn): ≤2.00
- Phosphorus (P): ≤0.030
- Sulfur (S): ≤0.020
- Chromium (Cr): 22.0-23.0
- Nickel (Ni): 4.5-6.5
- Molybdenum (Mo): 3.0-3.5
- Nitrogen (N): 0.14-0.20
Density: 7.8 g/cm³
Melting point: 1400-1450°C
Coefficient of thermal expansion: 13.7 x 10⁻⁶/°C (20-100°C)
Thermal conductivity: 15 W/m·K (20°C)
Resistivity: 0.80Ω ·mm²/m (20°C)
Performance characteristics
Corrosion resistance:
- Excellent resistance to chloride stress corrosion cracking.
- Good resistance to pitting and crevice corrosion.
- Performs well in acidic, alkaline and saline environments.
High strength:
- The yield strength is about twice that of ordinary austenitic stainless steel.
- High tensile strength, suitable for high stress environments.
Weldability:
- Good welding performance, no heat treatment after welding.
- Welded joints maintain high strength and corrosion resistance.
Fatigue strength:
- High fatigue strength, suitable for dynamic load environments.
Processing properties:
It can be formed by cold working and hot working, but the cold working hardening rate is higher.
Specification
- Diameter range: 5mm - 300mm
- Length: Usually 3000mm-6000mm, can also be customized.
- Surface treatment: black skin, pickling, polishing, etc.
Standard
- International standards: ASTM A276, ASTM A479, EN 10088-3
- Chinese standard: GB/T 1220, GB/T 4237
Application field
- Chemical industry: Used to manufacture reactors, heat exchangers, pipelines, etc.
- Oil and gas: Used in offshore platforms, pipelines, valves, etc.
- Marine engineering: Used in seawater treatment equipment, ship parts, etc.
- Paper industry: Used to manufacture bleaching equipment, storage tanks, etc.
- Environmental protection equipment: used for flue gas desulfurization equipment, wastewater treatment equipment, etc.
- Food processing: Used to manufacture food processing equipment, storage tanks, etc.
2205 duplex stainless steel rod with its excellent corrosion resistance, high strength and good weldability, is widely used in many industrial fields, especially suitable for high corrosion and high stress environments.
