Duplex Stainless Steel Bar S32750 / F53 / 1.4410 SS Bar Black / Bright Shaft
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 440C |
| Minimum Order Quantity | 500 kgs |
| Price | 2200 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507,440C.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | 1.4410 Duplex Stainless Steel Bar,Black Duplex Stainless Steel Bar,Bright Shaft Duplex Stainless Steel Bar |
||
Product Description
Duplex Stainless Steel Bar S32750 / F53 / 1.4410 SS Bar Black / Bright Shaft
Products Specification
| Products | Stainless Steel Bar |
| Grade | F53 / S32750 / 1.4410 |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
Super Duplex Steel F53 (UNS S32750)
F53 is a high alloy duplex stainless steel. F53 has excellent resistance to pitting and crevice corrosion resistance compared with the ordinary austenitic or duplex types. Due to this F53 stainless steel is used primarily in highly corrosive conditions.
| Chemical Composition Limits | ||||||||||
| Weight% | C | Mn | P | S | Si | Cr | Ni | Mo | N | Cu |
| Super Duplex F53 | 0.03 max | 1.2 max | 0.035 max | 0.015 max | 0.8 max | 24-26 | 6-8 | 3-5 | 0.3 | 0.5 max |
Typical Mechanical Properties
| Alloy | Tensile Strength ksi | Proof Strength 0.2% ksi (min) | Elongation (%) (min) | Hardness Rockwell C |
| Super Duplex F53 Annealed Condition | 110-135 | 80 | 15 | 28 max |
Availability
Super Duplex F53 is available in Bar, for sizes contact Sales.
Specifications
ASTM A182 F53
ASTM A276 F53
ASTM A479 F53
AISI F53
WS 1.4410
X2CrNiMoN25.7.4
AFNOR Z3CND25.07Az
UNS S32750
URANUS 47N(+)
Key Features:
- Excellent corrosion resistance in a wide variety of corrosive chemicals
- Pitting Resistance Equivalent number (PREN) of >41
- Outstanding resistance to pitting and crevice corrosion in seawater and other chloride containing environments
- Critical Pitting Temperature exceeding 50°C
- High strength compared to austenitic and 22%Cr duplex stainless steels
- Excellent ductility and impact strength at both ambient and sub-zero temperatures
- High resistance to abrasion, erosion and cavitation erosion
- Excellent resistance to stress corrosion cracking in chloride containing environments
- Listed in NACE MR 0175 for sour service
- ASME Approval for Pressure Vessel application
Applications:
- Process industry components in nitric acid, dioxide, polypropylene & PVC production, caustic evaporators
- Equipment handling organic & fatty acids
- Marine industry and shipbuilding propellers, shafts, rudders, shaft seals, pumps, bolts, fasteners, valves, instrumentation
- Oil and chemical tankers
- Oil & Gas industry pumps, valves, pipe, vessels, wellhead equipment, subsea equipment
- Pollution control systems, fans and pumps, wet scrubbers, incinerators, flue gas desulphurisation (FGD)
- Pulp & paper industry components such as black liquor heater tubes, digester blow valves, rotary feed valves, I.D.fans, brownstock washers, precipitators, bleaching components
- Food Industry applications including sugar cane centrifuges, corn and vegetable processing plant
- Agrochemicals production such as fertilisers (based on wet phosphoric acid)
- Sewage treatment, seawater cooling, desalination plants
