UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | UNS N06625 |
| Minimum Order Quantity | 10 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | 10 - 350mm | Length | Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | Hot Rolled Nickel Alloy Bars,Poilsihed Shaft Nickel Alloy Bars,UNS N06625 Nickel Alloy Bars |
||
Product Description
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
Products Specification
| Inconel 625 ASTM Standard for Bar | ASTM B446, ASME SB 446, AMS 5666 |
|---|---|
| Specifications | ISO 9723, ISO 9724, ISO 9725, VdTüV 499, BS3076NA21, EN 10095, DIN 17752, DIN 17753, DIN 17754; DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 625 Inconel Round Bars size | Diameter: 3-~800mm |
| Inconel 625 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Inconel 625 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Inconel 625 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 625 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Inconel 625 Billet Size | 1/2 to 495mm Diameter |
| Inconel 625 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Inconel 625 Hex Bar size | 2-100mm A/F |
| Inconel 625 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
Inconel 625 bar introduction
Inconel 625 is a nickel-based superalloy composed mainly of nickel, chromium, molybdenum and niobium, with excellent corrosion resistance, high temperature strength and oxidation resistance. It performs well in extreme environments and is widely used in aerospace, chemical, ocean engineering and other fields.
specification of Inconel 625 Round Bars
Inconel 625 bars come in a variety of sizes, from 6mm to 300mm in diameter and usually 3 or 6 meters in length, and can also be customized according to requirements.
Standard of Inconel 625 Round Bars
- Inconel 625 bars are produced and tested according to the following standards:
- ASTM B446: Standard Specification for Nickel Alloy Bars, Wires, and profiles.
- AMS 5666: Specification for Aerospace materials, applicable to superalloy bars.
- DIN 17752: German standard for nickel and nickel alloy bars.
EQUIVALENT GRADES OF INCONEL 625 ROUND BARS
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
CHEMICAL COMPOSITION OF INCONEL 625 ROUND BARS
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
Peculiarity of Inconel 625 Round Bars
- Corrosion resistance: Excellent performance in both oxidizing and reducing environments, especially in acidic and chloride environments.
- High temperature strength: still maintain high strength at high temperature, suitable for high temperature environment.
- Oxidation resistance: It has good antioxidant properties at high temperatures.
- Fatigue strength: High fatigue strength, suitable for cyclic load.
- Machinability: It can be formed by a variety of processing methods, but pay attention to its high strength and hardness.
Application of Inconel 625 Round Bars
Inconel 625 bars are widely used in the following fields:
- Aerospace: Used in engine components, combustion chambers and turbine blades.
- Chemical: For the manufacture of corrosion resistant reactors, heat exchangers and pipes.
- Marine engineering: Used in seawater treatment equipment and Marine components.
- Nuclear industry: Components used in nuclear reactors.
- Oil and gas: Used for downhole tools and pipeline systems.
Inconel 625 bars are widely used in many industrial fields due to their excellent corrosion resistance, high temperature strength and oxidation resistance. Its specifications and standards are diverse, and suitable products can be selected according to specific needs.
