Bright Polished Stainless Steel Pipe / Welded Tube ASTM GB SUS JIS EN Standard
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Bright Polished Stainless Steel Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or As Request |
| Diameter | 6 - 219mm Or As Clients Request | Wall Thickness | 0.4 - 8.0mm |
| Type | Welded Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | SUS Stainless Steel Pipe,GB Stainless Steel Pipe,Bright Polished Welded Stainless Steel Pipe |
||
Product Description
Bright Polished Stainless Steel Pipe / Welded Pipe Tube ASTM GB SUS JIS EN Standard
Products Specification
|
Product Name
|
Welded Stainless steel pipe
|
|
Standard
|
ASTM AISI DIN, EN, GB, JIS
|
|
Steel Grade
|
200 Series: 201,202
300 Series: 301,304,304L,316,316L,316Ti,317L,321,309s,310s 400 Series: 409L,410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L,2205,2507,2101,2520,2304 |
|
Outer Diameter
|
6-325mm(as required)
|
|
Thickness
|
0.4mm - 10.0mm |
|
Length
|
6m / pcs or custom other fixed length as request
|
|
Technique
|
Seamless/Welded
|
|
Surface
|
pickling finishing, 2B , Hairline , polishing |
|
MOQ
|
500 kgs
|
|
Price Terms
|
FOB,CFR,CIF
|
The introduction of stainless steel welded pipe
Stainless steel welded pipe is made of stainless steel strip or sheet crimped by welding process. It has the characteristics of high production efficiency, low cost, flexible specifications, etc., and is widely used in petroleum, chemical, construction, food, machinery and other fields. According to the different welding process and surface treatment, stainless steel welded pipe can be divided into many types, such as ordinary welded pipe, polished welded pipe, bright welded pipe and so on.
Welding process
The main welding process of stainless steel welded pipe includes:
TIG welding (Tungsten inert gas welding) :
Welding is performed using tungsten electrodes and inert gases such as argon.
Suitable for thin-wall pipe and high-precision welding, with high weld quality and smooth surface.
Plasma welding:
The use of plasma arc welding, energy concentration, welding speed.
Suitable for thick wall pipe and high strength requirements.
Laser welding:
Laser beam welding, high precision, small heat affected zone.
Suitable for high precision, high quality welding requirements.
High Frequency Welding (HFW) :
Welding edges are heated by high frequency current, suitable for mass production.
Low cost, high efficiency, but the weld quality is slightly lower than TIG welding.
Submerged Arc Welding (SAW) :
It is suitable for the production of thick wall pipe and large diameter pipe, and the welding efficiency is high.
specification
- Material: Common materials include 304, 304L, 316, 316L, 321, 310S, etc.
- Outer diameter: usually 6mm to 2000mm, can be customized according to demand.
- Wall thickness: Common range is 0.5mm to 30mm.
- Length: usually 6 meters, can also be customized according to customer requirements.
- Surface treatment: polishing, pickling, sandblasting and other treatments can be carried out according to demand.
Standard
The production and use of stainless steel welded pipes meet the following international and industry standards:
- ASTM A312/A312M: Standard for seamless, welded, and cryogenically processed Austenitic stainless steel pipes.
- ASTM A269: Universal Standard for seamless and welded Austenitic stainless steel pipes.
- ASTM A358: Standard for high-temperature electric arc welding of austenitic stainless steel pipes.
- EN 10217-7: Standard for welded stainless steel tubes for pressure purposes.
- GB/T 12771: Welded stainless steel pipe for fluid transport.
- GB/T 21833: Austenite-ferritic duplex stainless steel welded steel pipe.
- JIS G3459: Welded stainless steel pipe for pipes.
Apply
- Stainless steel welded pipe is widely used in the following fields:
- Oil and Gas Industry:Transmission pipeline, oil well pipe, natural gas pipeline.
- Chemical Industry:Corrosion resistant pipes, heat exchangers, reactors.
- Food and Beverage Industry:Pipeline, storage tank, food processing equipment.
- Construction industry:Structural support, decorative pipe, water supply and drainage pipe.
- Machinery Manufacturing:Conveying equipment, mechanical components, hydraulic systems.
- Automotive industry:Exhaust pipe, decorative parts, structural parts.
- Energy industry:Nuclear power equipment, boiler pipes, heat exchangers.
- Pharmaceutical industry:High purity medium transport pipeline, bioreactor.
Stainless steel welded pipe with its efficient production process, flexible specifications and a wide range of applications, has become an indispensable material in industrial production and daily life. Through different welding processes and surface treatments, it can meet the needs of a variety of industries, especially in corrosion resistance, high strength and hygiene requirements.
