430 Stainless Steel Pipe Welded Bright Polished SS Pipe OD6 - 114mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 321 310S 314 347 2205 2507 904L.etc |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | T/T, Western Union, L/C |
| Supply Ability | 10 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Bright Polished Stainless Steel Pipe | Grade | 304 316L 321 2205 310S 904L.etc |
|---|---|---|---|
| Standard | ASTM GB EN | Length | 6m Or As Request |
| Diameter | 6 - 219mm Or As Clients Request | Wall Thickness | 0.4 - 8.0mm |
| Type | Welded Pipe | Service | Cutting |
| Other Shape | Square, Rectangle | ||
| Highlight | 430 Welded Stainless Steel Pipe,Bright Polished Stainless Steel Pipe,OD 6mm Welded Stainless Steel Pipe |
||
Product Description
430 Stainless Steel Pipe Welded Pipe Bright Polished SS Pipe OD6 - 114mm
Products Specification
|
Product Name
|
Welded Stainless steel pipe
|
|
Standard
|
ASTM AISI DIN, EN, GB, JIS
|
|
Steel Grade
|
200 Series: 201,202
300 Series: 301,304,304L,316,316L,316Ti,317L,321,309s,310s 400 Series: 409L,410,410s,420j1,420j2,430,444,441,436 Duplex Steel: 904L,2205,2507,2101,2520,2304 |
|
Outer Diameter
|
6-325mm(as required)
|
|
Thickness
|
0.4mm - 10.0mm |
|
Length
|
6m / pcs or custom other fixed length as request
|
|
Technique
|
Seamless/Welded
|
|
Surface
|
pickling finishing, 2B , Hairline , polishing |
|
MOQ
|
500 kgs
|
|
Price Terms
|
FOB,CFR,CIF
|
430 stainless steel welded pipe introduction
430 stainless steel welded pipe is a kind of ferritic stainless steel welded pipe, with moderate corrosion resistance, good processing performance and magnetism, often used in decoration, home appliances and general industrial fields. Due to its high chromium content (about 16%-18%), 430 stainless steel shows good corrosion resistance in oxidizing environments, but poor corrosion resistance in chloride environments.
Main parameter
Material: 430 stainless steel
Chemical composition:
- Chromium (Cr) : 16%-18%
- Carbon (C) : ≤0.12%
- Manganese (Mn) : ≤1.0%
- Silicon (Si) : ≤1.0%
- Phosphorus (P) : ≤0.04%
- Sulfur (S) : ≤0.03%
- Density: 7.75 g/cm³
- Magnetic: Has magnetic properties
- Welding performance: It can be welded by TIG welding, plasma welding, etc., but after welding, it needs to be annealed to restore corrosion resistance.
Standard
- ASTM A268 (Universal Ferritic Stainless Steel Seamless and Welded Steel Pipe)
- JIS G4309 (Stainless Steel welded pipe)
- GB/T 12770 (Stainless steel welded steel pipe)
specification
- Outer diameter: Φ6mm-Φ500mm (can be customized according to demand)
- Wall thickness: 0.5mm-6.0mm (can be customized)
- Length: Usually 6 m (customizable)
- Shape: round tube, square tube, rectangular tube, etc
peculiarity
- Corrosion resistance:Performs well in dry and oxidizing environments, but has poor corrosion resistance in chloride environments (such as coastal areas).
- Magnetism:It is magnetic and suitable for application scenarios that require magnetism.
- Processing properties:Easy to cut, bend and weld for a variety of processing needs.
- Economy:Compared to 304 stainless steel, 430 stainless steel costs less and is suitable for projects with limited budgets.
- Beautiful surface:The decorative effect can be enhanced by polishing, drawing and other surface treatments.
- Heat resistance:The oxidation resistance is better in high temperature environment, but the high temperature strength is low.
Apply
- Architectural Decoration:Used for indoor and outdoor decorative materials, such as stair handrails, guardrail, door and window frames, etc.
- Home appliance Industry:Used for washing machine, microwave oven, refrigerator and other home appliances shell and internal structure.
- Automotive industry:Used for exhaust pipes, decorative strips and other components.
- Industrial field:Used for general industrial pipes, conveying equipment, etc.
- Kitchen Equipment:Used to make kitchen utensils, tableware, etc.
- Environmental protection equipment:Used for flue gas treatment equipment, dust removal equipment, etc.
- Matters needing attention
- Environmental adaptability: 430 stainless steel has poor corrosion resistance in wet or perchloride environments (such as coastal areas), it is recommended to choose 304 or 316 stainless steel.
- Post-welding treatment: annealing treatment is required after welding to restore its corrosion resistance.
- Surface maintenance: Clean the surface regularly to avoid accumulation of dirt affecting the appearance and corrosion resistance.
430 stainless steel welded pipe with its economy, good processing properties and magnetic properties, widely used in building decoration, home appliances, automobiles and industrial fields. It is a cost-effective option in dry and oxidizing environments, but needs to be used with caution in highly corrosive environments.
