15CrMo Alloy Steel Plate GB ASTM EN Standard 1500mm 2000mm 2200mm Width
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 10 kgs |
| Price | 540 - 890 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Product Details
| Products | Alloy Steel Plate | Thickness | 3.0 - 200.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | 15CrMo Alloy Steel Plate,2000mm Alloy Steel Plate,2200mm Alloy Steel Plate |
||
Product Description
15CrMo Alloy Steel Plate GB ASTM EN Standard 1500mm 2000mm 2200mm Width
15CrMo Structural Steel Plate
● Product Name: Alloy structural steel
● Steel: 15CrMo
● Digital Code: A30152
● Steel Group Series: CrMo
● Implementation of the standards: GB / T3077-1999
● Delivery status: hot-rolled or annealed, the specific delivery status should be indicated in the warranty book.
● 15CrMo features:
Low-alloy heat-resistant steel, stronger than 12CrMo steel, toughness slightly lower, at 500-550 ° C or less have a higher heat resistance and oxidation resistance, and good mechanical properties, machinability and cold strain plasticity good weldability fair. Mainly used for the production of various caliber seamless steel pipe and sheet.
● chemical composition range of values:
Note: The actual chemical composition of the steel quality books to prevail.
Carbon C: 0.12 ~ 0.18
Si Si: 0.17 ~ 0.37
Chromium Cr: 0.80 ~ 1.10
Ni Ni: ≤0.030
Copper Cu: ≤0.030
Mo Mo: 0.40 ~ 0.55
Manganese Mn: 0.40 ~ 0.70
Sulfur S: ≤0.035
Phosphorus P: ≤0.035
● 15CrMo mechanical properties of a range of values:
Note: The actual mechanical properties of the steel quality books to prevail.
15CrMo yield strength σ0.2 (MPa): ≥295
15CrMo tensile strength: δbMPa ≥440
15CrMo elongation δ5%: ≥22
15CrMo hardness: ≤179HB
● 15CrMo heat treatment process:
- Hardening: Heat 900 ° C, coolant: air-cooled
- Tempering: Heat 650 ° C, coolant: air-cooled
● 15CrMo Applications:
Main steam pipe for steam parameters of 510 ° C, 530 ° C steam parameters of boiler superheater tubes, catheters and high-pressure steam header, after quenching and tempering, at room temperature can be used to manufacture a variety of important parts of the work.
