AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 10 kgs |
| Price | 560 - 880 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Alloy Steel Plate | Thickness | 3.0 - 200.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | 42CrMo4 Alloy Steel Plate,160.0mm Alloy Steel Plate,AISI4140 Alloy Steel Plate |
||
Product Description
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
Products Specification
| Product | Alloy Steel Plate/Sheet | ||||||||||
| Standard | ASTM A285,ASTM A283,SA516,SA517,EN10025-2-2004,ASTM A572,ASTM A529,ASTM A573,ASTM A663,JIS G3101-2004,ASTM A678,ASTM A588,ASTM A242,etc | ||||||||||
| Material | A36,SS400,A283,Gr.A,.Gr.B.Gr.C,A285
Gr.A,.Gr.B.Gr.C,Q235,Q195,Q215,S185,SM400, S235J0,S235JR,S235J2,Q275,Gr50,GR55,GR.65,GR.A, S275JR,S275J0,E295,SS490, SS540,GR.60,GR.70,S355J0,SM570,E335,S235J2W,Q355,SMA490,S355J2W, Q265,P235GH,SB410,SPV235,SGV410,SG255,P265GH,SB450,SG295,P295GH,etc 15CrMo 30CrMo 42CrMo 65Mn12CrNiMoV 8620H 4340 4140 4150 5140 .etc |
||||||||||
| Size | Thickness:6.0-400mm
Width:1250mm,1500mm,1800mm,2000mm,2200mm,2500mm,etc Length:1000mm,1500mm,2000mm,3000mm,5000mm,8000mm,1000m,etc |
||||||||||
| Surface | Coated,Embossed,Brushed,Polished,Anodized,etc | ||||||||||
| Application | Boiler Plate Container Plate Flange Plate Ship Plate | ||||||||||
| MOQ | 1 ton. Sample order is acceptable. Please contact for details. | ||||||||||
| Package | Standard Sea Worthy Packing or customized | ||||||||||
AISI 4140 Alloy steel material stockholders and suppliers from China-OTAI SPECIAL STEEL . we have more 16 years experience in 4140 steel plate, round bar, flat bar, square supply.AISI 4140 alloy steel is chromium, molybdenum, manganese containing low alloy steel. It has high fatigue strength, abrasion and impact resistance, toughness, and torsional strength. The following datasheet gives an overview of AISI 4140 alloy steel.
4140 alloy steel material is a high quality Quenched and Tempered Alloy Structural steel, It belong to the high quality medium carbon alloy steel, Oil Quenched & Tempered Hardenss is 28-34 HRC.4140 Annealing delivery hardenss less than 250HB.
1. SAE AISI 4140 steel Form of Supply
ASTM / AISI 4140 Alloy structural steel, we can supply the round bar, steel flat bar, plate, hexagonal steel bar and square, block. 4140 alloy steel Round bar can be cut to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be cut from flat bar or plate to your specific sizes. Ground tool steel bar can be supply, providing a quality precision finished bar to tight tolerances.
Shape of 42CrMo Alloy Materials:
- Round
- sheet
- Square
- Plate
- Hexagonal
- Pipe
2. AISI 4140 equivalent material
- JAPAN : JIS SCM440 alloy steel
- GERMANY: DIN WN-r 1.7255 / 42CrMo4 steel alloy
- CHINA : GB 42CrMo steel
- BRITISH: BS 708M40
3. AISI 4140 alloy steel Chemical composition
| ASTM A29/29M | C | Si | Mn | Cr | Mo | P | S |
| 4140 | 0.38~0.43 | 0.15~0.35 | 0.75~1.00 | 0.80~1.10 | 0.15~0.25 | ≤0.035 | ≤0.040 |
| DIN WN-r | C | Si | Mn | Cr | Mo | P | S |
| 1.7225 | 0.38~0.45 | ≤0.40 | 0.60~0.90 | 0.90~1.20 | 0.15~0.30 | ≤0.035 | ≤0.035 |
| GB/T | C | Si | Mn | Cr | Mo | P | S |
| 42CrMo | 0.38~0.45 | 0.17~0.37 | 0.50~0.80 | 0.90~1.20 | 0.15~0.25 | ≤0.030 | ≤0.030 |
| BS | C | Si | Mn | Cr | Mo | P | S |
| 708M40 | 0.36~0.44 | 0.10~0.35 | 0.70~1.00 | 0.90~1.20 | 0.15~0.25 | ≤0.035 | ≤0.035 |
| JIS | C | Si | Mn | Cr | Mo | P | S |
| SCM440 | 0.38~0.43 | 0.15~0.35 | 0.60~0.85 | 0.90~1.20 | 0.15~0.30 | ≤0.030 | ≤0.030 |
4. Applications
DIN 4140 Tool steel is a alloy structural steel, 4140 is used for engineering structural, like high tensile shafts, bolts and nuts, gears, pinions and spindles. Locomotive traction with the big gear, supercharger drive gear, pressure vessel, rear axle, gear load of connecting rod and a spring clip,4140 can also be used to under 2000 m deep well of oil drill pipe joint and the fishing tool, and can be used for bending machine mould, etc
5. Supply Size range
Hot Rolled 4140 steel bar: Ø5mm-200mm
Forging 4140 steel bar: Ø140mm-3000mm
Hot rolled 4140 steel plate: Thickness 10mm-200mm x width 100-2300mm
Forged 4140 material steel plate: Thickness 150-1500mm x Width 100 x 3000mm
Others 4140 material have not specified size, pls contact our experienced sales team.
