ASTM Standard UNS S52100 GCr15 Bearing Steel Plate 100Cr6 1.3505 Alloy Steel
| Place of Origin | China |
|---|---|
| Brand Name | BAOSTEEL BENSTEEL HBIS XINGCHENG |
| Certification | ISO 9001 |
| Model Number | Carbon Steel , Alloy Steel |
| Minimum Order Quantity | 500 kgs |
| Price | 550 - 850 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Steel Plate | Thickness | 6.0 - 80.0mm |
|---|---|---|---|
| Width | 1000-2200mm | Length | 2000-12000mm |
| Standard | ASTM EN GB | Other Material | Carbon Steel, Alloy Steel, Stainless Steel |
| Brand | BAOSTEEL XINYU XINGCHENG HBIS | Service | Cutting |
| Highlight | 100Cr6 Alloy Steel Plate,1.3505 Alloy Steel Plate,GCr15 Alloy Steel Plate |
||
Product Description
ASTM Standard UNS S52100 GCr15 Bearing Steel Plate 100Cr6 1.3505 Alloy Steel
Products Specification of our plate
|
Products
|
Alloy Steel Plate | |
|
Specification |
Length
|
2000mm, 2438mm, 3000mm, 3500mm,6000mm, 12000mm,or rolled,etc etc
|
|
Thickness
|
3.0 - 200mm,etc
|
|
|
Width
|
1000-2500mm or cutting any width as request
|
|
|
Material
|
Q235,Q255,Q275,SS400,A36,SM400A,St37-2,SA283Gr,S235JR,S235J0,S235J2,1cr6si2mo,1cr5mo,15crmo,12cr1mov,15cdv6,Gcr15
|
|
|
Standard
|
ASTM,AISI,JIS,GB, DIN,EN
|
|
|
Technique
|
Hot rolled / cold rolled
|
|
|
Surface
|
Black Finish ,Oiled,Shot Blasted,Spray Paint,Coated,Galvanized,Or as Your Request
|
|
|
Package
|
standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
|
|
|
Payment Term
|
T/T, L/C at sight,West Union,Paypal
|
|
|
Price Term
|
FOB,CRF,CIF,EXW all acceptable
|
|
GCr15 steel is a high-carbon chromium bearing steel with less alloy content, good performance and the most widely used. It is the most commonly used high carbon chromium bearing steel with high hardenability. Its chemical composition and mechanical properties are regulated by the Chinese standard GB/T 18254-2016.
GCr15 is equivalent to DIN 100Gr6 in Germany standard, SUJ2 in JIS in Japan, and 52100 in the US ASTM standard. GCr15 alloy steel carbon content generally does not exceed 1.05%.
GCr15 alloy steel has the following general characteristics:
(1)High carbon Content: GCr15 is the most commonly used high carbon chromium bearing steel with high hardenability. The carbon content in T10 is generally not exceed 1.05%.
(2)Excellent property: GCr15 has high contact fatigue strength, good dimensional stability and corrosion resistance, moderate cold deformation plasticity, general machinability, poor weldability, sensitive to white spot formation, and class I temper brittleness.
(3)Strong wear resistance: GCr15 has high hardness and strength, the surface is not easy to wear, and it can still maintain good performance under high temperature and high pressure conditions.
Chemical Composition(Wt%) :
| Grades | C | Si | Mn | P | S | Cr | Mo | Cu | Ni |
| GCr15 | 0.95-1.05 | 0.15-0.35 | 0.2-0.4 | ≤0.027 | ≤0.02 | 1.3-1.65 | ≤0.1 | ≤0.25 | ≤0.3 |
Features
- Superior hardness, 60-67 on Rockwell hardness scale (Rc) at room temperature
- High carbon chrome alloy steel
- Operates continually at temperatures up to 120°C
- Used to produce precision ball bearings and roller bearings
- Cost-effective
- Long working life
Applications of GCr15 Bearing Steel
For making all kinds of bearing ring and rolling element, such as steel ball roller and ferrule of inernal combustion engine, electric motorcycle, automonilrd tractors, machine tools, rolling mill, boring machine, mining machinery, general machinery, high load and high speed roating mechanical transmission bearing.
2. Sometimes also used to make tools, such as pumching die and measuring tools
3. The automotive and aircraft industry use Alloy Steel 52100 for a number of different applications including:
★Anti-friction bearings
★Mill rolls
★Taps
★Punches
★Aircraft parts
