1m 2m 3m 6m Length 316L Stainless Steel Bars Bright Stainless Steel Shaft Diameter 4 - 350mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 316L |
| Minimum Order Quantity | 500 kgs |
| Price | 2.5 - 3.0 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Stainless Steel Round Bar | Grade | 316L |
|---|---|---|---|
| Diameter | 10- 350mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Black, Bright |
| Highlight | 350mm Stainless Steel Bars,316L Stainless Steel Bars,Bright Stainless Steel Bars |
||
Product Description
1m 2m 3m 6m Length 316L Stainless Steel Bars Bright Stainless Steel Shaft Diameter 4 - 350mm
Products Specification
| Standards | 316/316Ti/316L |
|---|---|
| Designation | ASTM, ASME, AISI A 276 , SA 276, A 479, SA 479, ASTM, ASME A276/SA 479 |
| Range | 3 MM TO 350 MM DIA |
| Finish | Bright, Polish & Black |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
Hot Rolled Stainless Steel Round Bar Diameter in Stock
| φ10mm | φ12mm | φ13mm | φ14mm | φ15mm | φ16mm | φ18mm | φ19mm |
| φ20mm | φ22mm | φ24mm | φ25mm | φ28mm | φ30mm | φ32mm | φ38mm |
| φ40mm | φ42mm | φ45mm | φ48mm | φ50mm | φ55mm | φ60mm | φ65mm |
| φ70mm | φ75mm | φ80mm | φ85mm | φ90mm | φ95mm | φ100mm | φ105mm |
| φ110mm | φ115mm | φ120mm | φ130mm | φ140mm | φ150mm | φ160mm | φ170mm |
| φ180mm | φ190mm | φ200mm | φ210mm | φ220mm | φ230mm | φ240mm | φ250mm |
| φ260mm | φ270mm | φ280mm | φ290mm | φ300mm | φ310mm | φ320mm | φ330mm |
| φ340mm | φ350mm |
Bright Stainless Steel Bar Diameter in Stock
| φ3mm | φ4mm | φ5mm | φ6mm | φ7mm | φ8mm | φ9mm | φ10mm |
| φ11mm | φ12mm | φ13mm | φ14mm | φ15mm | φ16mm | φ18mm | φ19mm |
| φ20mm | φ22mm | φ24mm | φ25mm | φ28mm | φ30mm | φ32mm | φ35mm |
| φ38mm | φ40mm | φ42mm | φ45mm | φ48mm | φ50mm | φ55mm | φ60mm |
| φ65 - 350mm bright polished bars produce as request | |||||||
316L Round Bar is made from a low-carbon version of the 316-grade stainless steel alloy. It has a maximum carbon content of only 0.03%, compared to 0.08% for 316-grade stainless steel. 316L stainless steel round bar has better corrosion resistance and is more suitable for high-temperature applications. It also has better resistance to intergranular corrosion. Due to physical properties such as excellent weldability and higher corrosion resistance, 316L stainless steel round bar is widely used in pharmaceutical and food processing equipment. They are also used in construction and marine applications.
316L stainless steel electrodes are widely used in large-gauge welding applications. This is because the stick is not prone to perish due to its chemical composition. The low carbon content helps reduce carbide precipitation, which sensitizes weld grain boundaries in these materials.
AMS 5653 is the AMS number for SS 316L material. It is also known for other specifications such as UNS S31600. It is a heat-resistant, corrosion-resistant alloy widely used in several industries. The low carbon content in the alloy improves its weldability and corrosion resistance.
Manufacturing Specifications for 316/316L Stainless Steel Round Bars, 316 Stainless Steel Rods
- ASTM A276 / A276M, Standard Specification for Stainless Steel Bars and Shapes
- ASTM A484 / A484M, Standard Specification for General Requirements for Stainless Steel Bars, Billets, and Forgings
- ASTM A479/ A479M, Standard Specification for Stainless Steel Bars and Shapes for Use in Boilers and Other Pressure Vessels
Designation of Stainless Steel 316/316L Grade Round Bars
| Stainless Steel [SS] 316 / 316H / 316 L / 316N / 316Ti | |
| AISI | 316 / 316H / 316 L / 316N / 316Ti |
| UNS | S31600 / S31609 / S31603 / S31651 / S31635 |
| Werkstoff Nr. | 1.4401 / 1.4404 / 1.4432 / 1.4435 / 1.4429 / 1.4571 |
Chemical Composition of Stainless Steel 316/316L Round Bars/Rods
| SS | 316 | 316H | 316N | 316L | 316Ti |
|---|---|---|---|---|---|
| Ni | 10 – 14 | 10 – 14 | 10 – 14 | 10 – 14 | 10 – 14 |
| Fe | Balance | ||||
| Cr | 16 – 18 | 16 – 18 | 16 – 18 | 16 – 18 | 16 – 18 |
| Mo | 2 – 3 | 2 – 3 | 2 – 3 | 2 – 3 | 2 – 3 |
| C | 0.08 max | 0.10 max | 0.03 max | 0.03 max | 0.08 max |
| Si | 0.75 max | 0.75 max | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max | 2 max | 2 max |
| P | 0.045 max | 0.045 max | 0.045 max | 0.045 max | 0.045 max |
| S | 0.030 max | 0.030 max | 0.030 max | 0.030 max | 0.030 max |
| N | 0.1 max | 0.1 max | 0.1 max | 0.1 max | |
| Ti | 5 X % (C + N) | ||||
Mechanical and Physical Properties of Stainless Steel 316/316L Round Bars
| Density | 8.0 g/cm3 |
|---|---|
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Production and Supply Range for Stainless Steel 316/316L Round Bars
| Standard | 316/316L, 1.4401, 1.4404 |
| Designation | ASTM A276, A479, ASME SA276, 479 |
| Range | 3 MM TO 350 MM DIA |
| Finish | Bright, Polish & Black |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
