H8 H9 H10 H11 Tolerance 316L Stainless Steel Round Bar Bright Polsihed Cold Drawn Bars

Place of Origin China
Brand Name DELTA
Certification ISO
Model Number 316L
Minimum Order Quantity 500 kgs
Price 2.5 - 3.0 USD/Kg
Packaging Details standard packing for export
Delivery Time 5 - 12 days based on the quantity
Payment Terms L/C, T/T, Western Union
Supply Ability 3 Ton per week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Products Stainless Steel Round Bar Grade 316L
Diameter 10- 350mm Length 6000mm Or Custom Cutting Any Length As Request
Standard ASTM EN Service Cutting
Loading Port Shanghai Port Surface Black, Bright
Highlight

316L Stainless Steel Round Bar

,

Cold Drawn Stainless Steel Round Bar

Leave a Message
Product Description

H8 H9 H10 H11 Tolerance 316L Stainless Steel Round Bar Bright Polsihed Cold Drawn Bars



Products Specification



Standards 316/316Ti/316L
Designation ASTM, ASME, AISI A 276 , SA 276, A 479, SA 479, ASTM, ASME A276/SA 479
Range 3 MM TO 350 MM DIA
Finish Bright, Polish & Black
Form Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.



Hot Rolled Stainless Steel Round Bar Diameter in Stock



φ10mm φ12mm φ13mm φ14mm φ15mm φ16mm φ18mm φ19mm
φ20mm φ22mm φ24mm φ25mm φ28mm φ30mm φ32mm φ38mm
φ40mm φ42mm φ45mm φ48mm φ50mm φ55mm φ60mm φ65mm
φ70mm φ75mm φ80mm φ85mm φ90mm φ95mm φ100mm φ105mm
φ110mm φ115mm φ120mm φ130mm φ140mm φ150mm φ160mm φ170mm
φ180mm φ190mm φ200mm φ210mm φ220mm φ230mm φ240mm φ250mm
φ260mm φ270mm φ280mm φ290mm φ300mm φ310mm φ320mm φ330mm
φ340mm φ350mm



Bright Stainless Steel Bar Diameter in Stock



φ3mm φ4mm φ5mm φ6mm φ7mm φ8mm φ9mm φ10mm
φ11mm φ12mm φ13mm φ14mm φ15mm φ16mm φ18mm φ19mm
φ20mm φ22mm φ24mm φ25mm φ28mm φ30mm φ32mm φ35mm
φ38mm φ40mm φ42mm φ45mm φ48mm φ50mm φ55mm φ60mm
φ65 - 350mm bright polished bars produce as request



316 / 316L / 316TI are types of stainless steel which are also called as marine grade stainless steel. It is an alloy of steel that possesses elements like nickel, chromium, and molybdenum. They are used in different industries because of properties like corrosion resistance and good strength. The difference between 316 and 316L is that the 316L contains less amount of carbon in comparison to 316. Moreover, because of this characteristic, it is preferred for body piercings, biomedical implants, and body modification implants. Usually, when used inside the body there are chances of nickel to react, henceforth nickel-free alloys are preferred. 316 alloy is used in the manufacture of food as well as in its handling. Whereas, 316Ti is a titanium-based stainless steel alloy. The addition of titanium stabilizes the structure from chromium carbide precipitations.



SS 316Ti Round Bar can be used in several industries, applications and fields like in propeller shafts, fittings, heat exchangers, paper and pulp industries, exterior architectural components in the marine industry, Biodiesel and ethanol plants and tanks, bridges, flood gates, washers, wastewater handling systems and many more.

Stainless Steel 316 Round Bars Chemical Composition

Grade C Mn Si P S Cr Mo Ni Fe
316 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 11.00 - 14.00 67.845 min
316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.89 min
SS 316Ti 0.08 max 2.0 max 0.75 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.395 min

SS 316L Round Bars Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %
