1500*6000mm Hastelloy C276 Plate Hot Rolled NO.1 Finishing 2.4819 Nickel Alloy Plate Coil
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 1.0 - 20.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | Hot Rolled Nickel Alloy Plate Coil,NO.1 Finishing Nickel Alloy Plate Coil,2.4819 Nickel Alloy Plate Coil |
||
Product Description
1500*6000mm Hastelloy C276 Plate Hot Rolled NO.1Finishing 2.4819 Nickel Alloy Plate Coil
Products Specification
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 - ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 1-6mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 10-1500mm or as required |
| Plate Thickness | 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm.etc |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Review of Hastelloy C276 Plate
Hastelloy C276 Clad Plate is a corrosion-resistant clad alloy that is widely used in a variety of industrial applications, including chemical processing, oil and gas, and marine engineering. As a professional Hastelloy C276 Clad Plate supplier, We offers product that is known for excellent resistance to pitting, crevice corrosion, and stress corrosion cracking in aggressive environments.
Feature of Hastelloy C276 Material
The manufacturing process for C276 Clad Plate involves bonding a layer of Hastelloy C276 alloy to a base plate made of carbon steel or other metals. The cladding process can be achieved through a variety of techniques, including explosive bonding, roll bonding, and weld overlay. The resulting C276 Clad Plate provides the strength and durability of a base metal with the exceptional corrosion resistance of the Hastelloy C276 alloy.
One of the most notable features of C276 Clad Plate is its ability to withstand various corrosive environments, including acidic and alkaline solutions, chlorides, and oxidizing agents. This makes Hastelloy C276 Clad Plate an ideal choice for use in harsh environments where other materials may quickly corrode or fail.
Chemical Composition of ASTM B575 Alloy C276 Plate
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
ASTM B575 Alloy C276 Sheet Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Material | Ultimate Tensile (min) | Yield Strength (Min) | Elongation % | Hardness Rb | ||
| Ksi | Mpa | Ksi | Mpa | |||
| C276 Plate | 107.4 | 741 | 50.3 | 347 | 67 | 89 |
| C276 Sheet | 115.5 | 796 | 54.6 | 376 | 60 | 86 |
Hastelloy C276 Sheets, Plates & Coils Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. | EN | BS | OR | GOST | JIS |
| Hastelloy C276 | N10276 | 2.4819 | NiMo16Cr15W | – | ЭП760 | ХН65МВУ | NW 0276 |
