Hot Rolled Hastelloy C276 Plate 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 1.0 - 20.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | 14.0mm Hastelloy C276 Plate,12.0mm Hastelloy C276 Plate,10.0mm Hastelloy C276 Plate |
||
Product Description
Hot Rolled Hastelloy C276 Plate 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm Thickness
Products Specification
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 - ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 1-6mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 10-1500mm or as required |
| Plate Thickness | 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm.etc |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
What is Hastelloy C276 Plate, Sheet and Coil?
Hastelloy C276 is designed in definite shapes of plates, sheets, and coils. Each of these components has its set of features and functionality in the system.
- Hastelloy C276 plates are high-strength material that provides stability and strength to different items. These robust plates are designed in thickness above 6mm or more.
- Hastelloy C276 sheets are devices designed in thickness less than 6mm but higher than 0.5mm. These modules focus more on weight-saving and adding an aesthetical value rather than providing strength and stability.
- Hastelloy C276 coils are wound soon after the rolling process. Designed in thickness between 1.2mm up to 20mm, they can be easily transported from one place to the other.
2.4819 Alloy C 276 Plate equivalent
| Europe | America | Japan | Russia | Europe | Russia | |
|---|---|---|---|---|---|---|
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Alloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Hastelloy C276 ASTM B575 chemical composition
| Hastelloy C276 | Analysis |
|---|---|
| Ni | Bal |
| Mo | 15 – 17 |
| Cr | 14.5 – 16.5 |
| Fe | 4 – 7 |
| W | 3 – 4.5 |
| Co | 2.5 max |
| Mn | 1.0 max |
| C | 0.01 max |
| v | 0.35 max |
| P | 0.04 max |
| S | 0.03 max |
| Si | 0.08 max |
UNS N10276 Plates mechanical properties
| Density | 8.89 g/cm3 |
| Melting Range | 1370 °C (2500 °F) |
| Tensile Strength | Psi – 1,15,000 MPa – 790 |
| Yield Strength (0.2%Offset) | Psi – 52,000 MPa – 355 |
| Elongation | 40 % |
Is Hastelloy C276 Clad Plate corrosion resistant?
Hastelloy C276 clad plate is a chromium, nickel, iron, and molybdenum grade that is solid-solution strengthened. These plates showcase excellent corrosion resistance properties and have exceptional stress resistance across different stress-induced setups. The superior chemical content in the clad plate gives them enhanced resistance against crevice corrosion and pitting in marine setups. Apart from this, the superalloy resists the development of precipitates due to the formation of grain boundary leading to enhanced corrosion resistance properties.
Is Alloy C276 Plate magnetic?
The alloy C276 plate is an austenitic grade designed to perform well in oxidizing and reducing environments. Most austenite grades are non-magnetic in nature, but the plates in the C276 grade have a magnetic permeability at 15.9 kA/m of 1.002.
