Thickness 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm Hastelloy C276 Nickel Alloy Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 1.0 - 20.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | 1.5mm Nickel Alloy Plate,1.0mm Nickel Alloy Plate,1.2mm Nickel Alloy Plate |
||
Product Description
Thickness 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm Hastelloy C276 Nickel Alloy Plate
Products Specification
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 - ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 1-6mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 10-1500mm or as required |
| Plate Thickness | 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm.etc |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Hastelloy C276 Plate Features
- Good weldability and formability
- High-temperature strength
- Low thermal expansion
- Low thermal conductivity
- Excellent mechanical properties at elevated temperatures
- Low electrical resistivity
- High thermal diffusivity
- High ductility and impact strength
Introduce of Hastelloy C276 Materials
Hastelloy C276 plates are composed of nickel, molybdenum, & chromium elements. They are highly resistant to an extensive range of corrosive media. That includes sulfuric acid, hydrochloric acid, acetic acid, etc. Thus, this material is ideal for use in harsh, corrosive, and high-stress level environments.
The plate is easy to fabricate using standard techniques, such as welding, machining, and forming. At Tuolian, we use advanced manufacturing technology and follow strict quality control standards to ensure our products meet industry standards. You can avail of Hastelloy C276 plates in various ranges of sizes & thicknesses based on your projects.
If you are looking for a reliable supplier of high-quality Hastelloy C276 plates, we invite you to contact us today. We are confident we have the expertise and capabilities to exceed your expectations.
Chemical Composition
| Element | Composition |
| Nickel | 50-55% |
| Chromium | 14.5-16.5% |
| Molybdenum | 15-17% |
| Iron | 4-7% |
| Tungsten | 3-4.5% |
| Sulfur | 0.03% max |
| Cobalt | 2.5% max |
| Manganese | 1% max |
| Carbon | 0.01% max |
| Silicon | 0.08% |
| Phosphorus | 0.04% max |
Applications of Hastelloy C276
- Heat Exchanger
- Pressure Vessels
- Pickling Equipment
- Chemical Processing Equipment
- Pollution Control Equipment
- Nuclear Fuel Reprocessing
- Marine Exhaust Systems
- Acid Production Equipment
- Power Generation Equipment
- Pumps, Valves, Condensers
- Evaporators, Distillation Trays
- Seawater Desalination Systems
