Hastelloy C276 Plate And Nickel Alloy N10276 Sheet / Strip / Coil Thickness 0.5 - 20.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Plate | Grade | Hastelloy C276 |
|---|---|---|---|
| Thickness | 1.0 - 20.0mm | Width | 1000mm 1219mm 1500mm |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | 2B NO.1 |
| Highlight | Nickel Alloy N10276 Strip,Nickel Alloy N10276 Sheet,Nickel Alloy N10276 Coil |
||
Product Description
Hastelloy C276 Plate and Nickel Alloy N10276 Sheet/Strip/Coil Thickness 0.5 - 20.0mm
Introduce of Hastelloy C276
ASTM B575 UNS N10276 Hastelloy C276 Sheet is widely used in a variety of sectors, which include petrochemicals, chemical oil and gas, power production, pharmaceuticals, pulp and paper processing, and wastewater treatment. Hastelloy C276 Coil has a high tolerance to matching, stress degradation, and oxidising conditions. ASME SB 575 UNS N10276 content is often resistant to salt water corrosion in crevice environments, which may trigger aggressive assault in other products which are used on a large scale. UNS N10276 plate is normally remedy heat-treated at 2050 degrees Fahrenheit and easily quenched.
Specification Table Of Hastelloy C276 Plate
Products Specification
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 - ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 1-6mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 10-1500mm or as required |
| Plate Thickness | 0.5-20.0mm or as required |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Other Hastelloy C276 Plate Information
| ASTM B575 Alloy C276 Plate, Sheet and Strip |
ISO 6208, ASTM B 575/B 906 & ASME SB 575/SB 906, VdTÜV 400/12.98, DIN 17750,
|
|---|---|
| Tolerances of width and thickness |
|
| Hastelloy C276 Plate standards and approvals |
|
| Standard 2.4819 Plate & Sheet Sizes |
1000 x 2000 mm, 1220 x 2440 mm, 1500 x 3000 mm, 2000 x 2000 mm, 2000 x 4000 mm
|
| Alloy C276 Plate Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard ASTM B575 Alloy C276 Sheet suppliers |
| Availability of Nickel Alloy C276 Foil sizes | Thickness : 8-100 microns (0.00031-0.004 in) Width: Up to 500 mm (19.5 in) Weight (in rolls) : Up to 50 kg (110 lb); e.g. approxi- mately 1400 m at 8 microns and ap- proximately 112 m at 100 microns. |
| Profiling |
To provide a full profiling service in India we use numerous profiling methods including:
|
| Plasma profiles | As per customer's drawings |
| Value added services for Hastelloy C276 Plate | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| UNS N10276 Plate Manufacturer in india |
|
| DIN 2.4819 Plate Origin | Indian Origin, European Origin, Japanese Origin |
| Packing of C276 Alloy plate | Bundles with waterproof cloth outside or plywood box |
| services for Hastelloy Alloy C276 Coil |
|
| Test | UT, SGS testing, TUV etc |
| dealers & distributors are located in | Abu Dhabi, Port-of-Spain, Pimpri-Chinchwad, New Delhi, Gimhae-si, Jamshedpur, Howrah, Kolkata, Tehran, Gurgaon Surat, Caracas, Istanbul, Thiruvananthapuram, Hyderabad, Santiago, Melbourne, Lagos, Calgary, Manama, Bogota, Janeiro, Ahvaz, Courbevoie, Sydney, India, Baroda, Ernakulam, Noida, Ludhiana, Mexico Rajkot, Ranchi, Bengaluru, Riyadh, Ankara, Vadodara, Montreal, Ahmedabad, London, Chennai, Tau, Perth, Karachi, Kuwait, Kanpur, Gujarat, Muscat, Dammam, Ludhiana, Mumbai, Khobar, Nagpur,Indore, Coimbatore, Bangalore |
| Why buy UNS N10276 Plate from Jignesh Steel ? |
|
What Is Hastelloy C276 Plate?
The materials used to make Hastelloy C-276 UNS N10276 Cold Rolled Plate must meet not only the chemical specifications, but also the mechanical requirements which have been stated in the ASTM B575 norm. When it comes to the mechanical properties of Hastelloy c276 Plate, this alloy must meet the requisite tensile properties. Various forms such as foils, sheets, strips, clad plate, coils, and other shapes and sizes.
Equivalent Of Hastelloy C276 Plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Properties Of Alloy C276 Plate
Hastelloy C276 Plate Chemical Composition
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
UNS N10276 Plate Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Material | Ultimate Tensile (min) | Yield Strength (Min) | Elongation % | Hardness Rb | ||
|---|---|---|---|---|---|---|
| Ksi | Mpa | Ksi | Mpa | |||
| C276 Plate | 107.4 | 741 | 50.3 | 347 | 67 | 89 |
| C276 Sheet | 115.5 | 796 | 54.6 | 376 | 60 | 86 |
Uses Of UNS N10276 Plate
- Equipment for processes utilizing halide or acid catalysts.
- Digesters and bleach plants in the paper industry.
- Equipment for flue-gas desulfurisation plants.
- Sulfuric acid reactors.
- Evaporators, heat exchangers, filters and mixers used in sulfuric acid environments.
- Components exposed to sour gas.
- Organic chloride process equipment.
