Hastelloy C276 ASTM B574 N10276 / 2,4819 Round Bar / Hot Rolled C276 Bars Cutting Retail
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | hastelloy C276 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Alloy Bar | Grade | Hastelloy C276 |
|---|---|---|---|
| Diameter | 4 - 300mm | Length | 6000mm Or Custom Cutting Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Bright |
| Highlight | N10276 C276 Bar,Hot Rolled C276 Bar,ASTM B574 C276 Bar |
||
Product Description
Hastelloy C276 Bar ASTM B574 N10276 / 2,4819 Round Bar / Hot Rolled C276 Bars Cutting Retail
Hastelloy WNR 2.4819 Hexagonal Bars is resistant to suffixation and other kinds of hot corrosion due to its high chromium and modest nickel content. It is a soaring temperature chromium nickel austenitic steel with good creep strength and resistance to oxidation at dry air temperatures. It has many of the same properties and uses, such as resistance to corrosion and oxidation and the ability to sustain high temperatures.Under gently cyclic circumstances, it has high oxidation resistance. It is effective in decreasing conditions that include sulphur. It's low-grade steel that keeps embrittlement and sensitization at bay.
No other element can substitute chromium in this Nickel Alloy C276 Triangular Bars to obtain its stainless characteristic and impact chrome's efficacy in creating or maintaining the layer. It is extremely resistant to oxidising acids and the majority of typical corrosive chemicals. This steel's strong nickel and chromium concentrations provide outstanding higher temperature strength and oxidation resistance. The fact that these high temperature alloys are designed primarily for usage at temperatures above 550 degrees Celsius is a common trait.It is commonly employed in mildly carburizing atmospheres, such as those found in petrochemical plants. At high temperatures, it produces a tenacious scale, is resistant to spelling, and outperforms thermal cycling applications.
Products Specification
| Specification | Hastelloy C276 Nickel Alloy Round Bar |
| Grade | Hastelloy C276 – UNS N10276 |
| ASTM B574 Hastelloy C276 Round bar size | Diameter: 10-300mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Hastelloy C276 Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Cutting our bars into any length as request |
| Form | Hastelloy C276 Round, Welding Rod, T-Bar, Rod, Precision Ground Bar, Channel Bar, Square, Flat Bar, Blocks, Round Rod, Hollow, Rings, Rectangle, Hex (A/F), Triangle, Threaded, Profiles, Billet, Ingot, I/H Bar, Half Round Bar, Forging etc. |
Grade Specification
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN | GOST | OR |
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | NiMo16Cr15W | ХН65МВУ | ЭП760 |
Chemical Composition of Hastelloy C276
| Grade | C | Mn | Si | Co | P | Fe | Mo | Ni | Cr | S | W | V |
| Hastelloy C276 | 0.010 max | 1 max | 0.08 max | 2.5 max | 0.04 max | 4 – 7 | 15 – 17 | Bal | 14.5-16.5 | 0.03 max | 3.0-4.5 | 0.35 max |
Mechanical Properties of Hastelloy C276
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52000 , MPa – 355 | 40% |
Hastelloy C276 Bars Standard
| Standard | Description |
|---|---|
| ASTM B574 | Specification for Hastelloy Bars and Shapes |
| ASTM A314 | Specification for Hastelloy Billets and Bars for Forging |
| ASTM A493 | Specification for Hastelloy Wire and Wire Rods for Cold Heading and Cold Forging |
| ASTM A564 | Specification for Hot-Rolled And Cold-Finished Age-Hardening Hastelloy Bars and Shapes |
| ASTM A565 | Specification for Martensitic Hastelloy Bars, Forgings, and Forging Stock for High Temperature Service |
| ASTM A582 | Specification for Free Machining Hastelloy Bars |
| ASTM A666 | Specification For Annealed or Cold-Worked Austenitic Hastelloy Flat Bar |
