Titanium Plate Sheet ASTM B265 Gr2 NACE MR0175 GR1 GR2 GR3 GR4 GR5 GR7 Pure Titanium
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | GR1 GR2 GR3 GR4 GR5 GR7 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Bars | Grade | GR1 GR2 GR3 GR4 GR5 GR7 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Length | Custom Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Pickled , Bright |
| Highlight | NACE MR0175 Titanium Plate Sheet,Pure Titanium Plate Sheet,ASTM B265 Titanium Plate Sheet |
||
Product Description
Titanium Plate Sheet ASTM B265 Gr2 NACE MR0175 GR1 GR2 GR3 GR4 GR5 GR7 Pure Titanium
Specification of TITANIUM Sheet Plate
| Standards | ASTM B265 / ASME SB265 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc. |
| Form | Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Titanium Plate is used in many difficult applications across the Aerospace, Medical, Industrial, and Oil and Gas industries. Titanium Plate is selected for its unique combination of high strength, light weight, corrosion resistance, biocompatibility, and higher temperature performance.
| SIZE RANGE | GRADES | STANDARD |
|---|---|---|
| 1mm to 100mm thk x upto 3000mm width x upto 12000mm length, COLD ROLLED upto 4mm thk, HOT ROLLED above 4MM thk | GR.1, GR.2, GR.3, GR.4, GR.5, GR.7, GR.9, GR.12 | ASTM B265, ASTM F67, ASME SB265, AMS 4901, MIL-T-9046 |
| Gr.5 / Ti6Al4V | ASTM B265, AMS 4911, ASME SB265 | |
| Gr.5 ELI / Ti6Al4V ELI | ASTM F136, AMS 4907 |
Titanium Plate Size Range: Min thickness: 0.156″/3.00 mm | Max thickness: 6.000″/200.00mm
| COMMERCIALLY PURE TITANIUM PLATE | ||||||
|---|---|---|---|---|---|---|
| Grade 1 CP 4 | UNS R50250 | Grade 2 CP 3 | UNS R50400 | Grade 3 CP 2 | UNS 50550 | Grade 4 CP 1 | UNS R50700 | |||
|
|
|||||
| TITANIUM ALLOY PLATE | ||||||
|---|---|---|---|---|---|---|
| 6Al-4V Grade 5 | UNS R56400 | 6Al-4V ELI Grade 23 | UNS R56407 | |||||
|
|
|||||
Titanium Sheet Size Range: Min thickness: 0.156″/ 3.00 mm | Max thickness: 6.000″/200.00mm
| COMMERCIALLY PURE TITANIUM SHEET | ||||||
|---|---|---|---|---|---|---|
| Grade 1 CP 4 | UNS R50250 | Grade 2 CP 3 | UNS R50400 | Grade 3 CP 2 | UNS 50550 | Grade 4 CP 1 | UNS R50700 | |||
|
|
|
||||
Titanium Grade 1 is an unalloyed, low strength titanium product containing low oxygen with high formability; this titanium grade is used in airframes, heat exchangers and desalination units.
Titanium Grade 1
Titanium Grade 1, Annealed
Titanium Grade 2 is an unalloyed, medium strength titanium product. This titanium grade is used in airframes, aircraft engines, and marine parts; good weldability and corrosion resistance are its distinguishing characteristics.
Titanium Grade 2
Titanium Grade 2, Annealed
Titanium Grade 3 is an unalloyed, high strength, titanium product providing excellent corrosion resistance and good weldability. This titanium grade is primarily used in airframe and aircraft engine parts.
Titanium Grade 3
Titanium Grade 3, Annealed
Titanium Grade 4 is the highest strength pure unalloyed titanium product. This titanium grade is used almost exclusively for airframe, aircraft engine parts, marine, surgical implants, hydraulic tubing. Good formability and corrosion resistance are its hallmark.
Titanium Grade 4
Titanium Grade 4, Annealed
Titanium Grade 5 (6AL-4V) is an alloyed titanium product containing 6% Aluminum and 4% Vanadium; is a medium strength product. This titanium grade is predominantly used in airframe and turbine engine parts; and for use in surgical implants.
