TA3 Titanium Plate GR3 Pure Titanium Gr3 Titanium Plate ASTM B265 Ti Plate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | GR1 GR2 GR3 GR4 GR5 GR7 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Bars | Grade | GR1 GR2 GR3 GR4 GR5 GR7 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Length | Custom Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Pickled , Bright |
| Highlight | Pure Titanium Gr3 Titanium Plate,TA3 Titanium Plate,ASTM B265 Titanium Plate |
||
Product Description
TA3 Titanium Plate GR3 Pure Titanium Gr3 Titanium Plate ASTM B265 Ti Plate
| Product Name | Titanium plate/sheet |
| Grade | GR1, GR2, GR5, GR5ELI, GR7, GR9, GR12, GR23, Ti-4Al-2V, Ti-4Al-1.5Mn. |
| Size | thickness 0.1mm-40mm*length*Width or as your request |
| Standard | AMS 4900-2001, AMS 4900-2002, AMS4902-2001, AMS4907-2001, AMS4910-2003, AMS4911-2003, ASTM B265-2005, ASTM F67-2000, ASTM F136-2002, ASTM F2063-2000, MIL-T-9046-1999, MIL-T-46077, BS2TA1: 1974, BS2TA2: 1973, BS2TA6: 1973, BS2TA10:1974, BS2TA21: 1973, BSTA56: 1993, BSTA57: 1993, BSTA58: 1993, GJB2505-1995, GJB2921-1997, GJB944-1900, GB/T 3622-1999, GB/T 3621-2007, GB/T 14845-2007, GB/T 8546-2007, GB/T 8547-2006, ΓOCT22178-90, ΓOCT23755-87, JISH4600-1993, DIN17860-1990 |
| Application | chemical industry, Aerospace, deep sea, military, medical, etc. |
| Feature | High corrosion resistance, low density, good thermal stability, High strength and light weight. |
| Technics | hot rolled and cold rolled |
| Surface | Annealed surface, Pickled surface, bright surface, sandblasted surface |
| Packing | Export Standard Woodcase |
| MOQ | as your request |
| Payment terms | T/T, Western Union, PayPal. |
| Certificate | ISO 9001:2008; The third test report. |
| Delivery time | 10—25days according to the quantity and process of the product |
| Quality and test | Ingredient testing |
| Price Term: | CIF CNF/CFR FOB Ex-work |
Grade 3 pure titanium Plate is a high-purity titanium metal product with similar mechanical and physical properties to Gr1 and Gr2 but with greater strength. Gr3 titanium Plates have excellent corrosion resistance and good weldability. This grade of titanium is used in aircraft fuselage and engine parts.
The quality of the titanium plate is largely determined by the smelting process, including the chemical composition of the titanium, the cleanliness of the titanium water (gas, harmful elements, inclusions), and the quality of the casting (component segregation, decarburization, and surface conditions) These aspects are the key control points of smelting operations.
Chemical Composition of Titanium Plate
Mechanical Properties of Titanium Plate
| Grade | Mechanical Properties | |||||
| Tensile Strength | Yield Strength,0.2% | Elongation | Bend Testing | |||
| Min (Mpa) | Min (Mpa) | Max (Mpa) | Min (%) | T<1.8mm | T=1.8~4.75 | |
| Gr.1 | 240 | 138 | 310 | 24 | 1.5T | 2T |
| Gr.2 | 345 | 275 | 450 | 20 | 2T | 2.5T |
| Gr.3 | 450 | 380 | 550 | 18 | 2T | 2.5T |
| Gr.4 | 550 | 483 | 655 | 15 | 2.5T | 3T |
| Gr.5 | 895 | 828 | - | 10 | 4.5T | 5T |
| Gr.7 | 345 | 275 | 450 | 20 | 2T | 2.5T |
| Gr.9 | 620 | 483 | - | 15 | 2.5T | 3T |
| Gr.12 | 483 | 345 | - | 18 | 2T | 2.5T |
ADVANTAGES OF GR3 TITANIUM PLATE
- 1,High strength-to-weight ratio: Gr3 Titanium Plate has a high strength-to-weight ratio, making it suitable for use in various industrial and marine applications.
- 2,Excellent corrosion resistance: Titanium is known for its excellent corrosion resistance, making Gr3 Titanium Plate ideal for use in harsh environments.
- 3,Good weldability: Gr3 Titanium Plate has excellent weldability, making it easy to use in various types of fabrication work.
- 4,Biocompatible: Gr3 Titanium Plate is biocompatible, making it ideal for use in medical applications such as implants and prosthetics.
- 5,Versatile: Gr3 Titanium Plate has several applications across various industries, such as aerospace, marine, chemical processing, and medical.
- 6,Longer lifespan: Gr3 Titanium Plate has an extended lifespan due to its superior corrosion resistance properties, making it a cost-effective solution for many industries.
- 7,Light weight: Gr3 Titanium Plate is lightweight and easy to handle, transport, and fabricate.
