ASME SB265 GR2 Titanium Plate UNS R50400 Alloy TA2 With EN 10204-3.1 Certificate
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | GR1 GR2 GR3 GR4 GR5 GR7 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Bars | Grade | GR1 GR2 GR3 GR4 GR5 GR7 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Length | Custom Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Pickled , Bright |
| Highlight | ASME SB265 GR2 Titanium Plate,Alloy TA2 Titanium Plate,EN 10204-3.1 Titanium Plate |
||
Product Description
ASME SB265 GR2 Titanium Plate UNS R50400 Alloy TA2 With EN 10204-3.1 Certificate
| Grade | TA1, TA2, TA3, TA4, TA10, TA15, TA17, GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR11, GR12 |
| Size | T(3.0mm~120mm)*W(800mm~2200mm)*L T(0.4mm~3mm)*W(1500mm max)*L |
| Standard | ASTM B 265, ASME SB265 AMS491 |
| Application | Chemical, industry, sports etc. |
| Feature | High corrosion resistance, low density, good thermal stability |
| Surface | Bright, Polished, Pickling, Acid cleaning, Sandblasting |
| Quality and test | Hardness test, Bending test, Hydrostatic etc. |
| Finish | Roll-up(Hard) |
| Surface | Polished |
| CHEMICAL COMPOSITION | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| C ≤ 0.08% | H ≤ 0.015% | Fe ≤ 0.2% | N ≤ 0.03% | O 0.18% | |||||
| Ti balance | |||||||||
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat (BTU/lb-°F) | Thermal expansion (1/°F) | Thermal expansion | Melting Point (°F) |
| 0.163 | 4.11 | 111 | 0.124 | 4.78E-06 | – | 3040 |
| MECHANICAL PROPERTIES | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| PROPERTY | MINIMUM | MAXIMUM | |||||||
| Yield Strength Range (Rp0.2 Offset) (ksi) | 25 | – | |||||||
| Tensile Strength Range (Rm) (ksi) | 35 | – | |||||||
| Elongation (AL=5 x Ø) | 24.0% | 29.0% | |||||||
| Brinell Hardness (H) | – | 120 | |||||||
Ti Grade 2 Sheet & Plate Stock List
| TITANIUM GR2 ASTM B265 | Dimension |
|---|---|
| Sheet; cold rolled | 0.4x1000x2000 mm, 3.45 kg/pc |
| Sheet; cold rolled, annealed, clean | 0.5x1000x2000 mm, 4.51 kg/pc. |
| Sheet; cold rolled | 0.6x995x2000 mm, 5.5 kg/pc |
| Sheet; pickled, annealed | 1.0x1250x3000 mm, 16.9 kg/pc |
| Sheet; cold rolled | 2.5x1220x3000 mm, 42 kg/pc |
| Sheet; annealed | 3.0x1000x3000 mm, 40.5 kg/pc |
| Sheet; annealed | 3.0x1500x3000 mm, 60.75 kg/pc |
| Plate; annealed | 10x2000x3000 mm, 296 kg/pc |
| plate | 10.0x1250x4000 mm, 225,50 kg/Stk. |
| Plate; annealed | 12.0x2000x3000 mm, 352 kg/pc |
| Plate; annealed | 50.0x2000x3000 mm, 1896 kg/pc |
Types of ASTM B265 Grade 2 Sheet & Plate
Titanium Cp Grade 2 Plate
Cp Grade 2 Sheet
Grade 2 Titanium Coil
ASME SB 265 Gr 2 Clad Plate
Ti Cp Grade 2 Strips
ASTM B265 Gr2 Titanium Shim Stock
SB 265 Gr 2 Rolling Sheets
Titanium B265 Gr 2 Flat Sheet
Titanium Grade 2 Rolling Plate
ASTM B265 Grade 2 Flat Shim
Titanium Cp Grade 2 Perforated Plate
Cp Grade 2 Polished Plate
Grade 2 Titanium cold rolled sheet
ASME SB 265 Gr 2 hot rolled plate
Ti Cp Grade 2 Plate
ASTM B265 Gr2 Titanium Sheet
SB 265 Gr 2 Quarto Plate
Titanium B265 Gr 2 Precision Strip
Titanium Grade 2 Cold Rolled Coil, Strip And Sheet
ASTM B265 Grade 2 Hot Rolled Coil, Strip And Plate
