Titanium Grade 2 3.7035 R50400 ASTM EN DIN Standard TA2 Plate Thickness 3.0 - 40.0mm
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | GR1 GR2 GR3 GR4 GR5 GR7 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Bars | Grade | GR1 GR2 GR3 GR4 GR5 GR7 |
|---|---|---|---|
| Thickness | 0.4-30.0mm | Length | Custom Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Pickled , Bright |
| Highlight | 3.7035 titanium plate,40mm thick titanium plate,3mm thick titanium plate |
||
Product Description
Titanium-Grade 2 (3.7035), R50400 ASTM EN DIN Standard TA2 Plate Thickness 3.0 - 40.0mm
| Grade | TA1, TA2, TA3, TA4, TA10, TA15, TA17, GR1, GR2, GR3, GR4, GR5, GR7, GR9, GR11, GR12 |
| Size | T(3.0mm~120mm)*W(800mm~2200mm)*L T(0.4mm~3mm)*W(1500mm max)*L |
| Standard | ASTM B 265, ASME SB265 AMS491 |
| Application | Chemical, industry, sports etc. |
| Feature | High corrosion resistance, low density, good thermal stability |
| Surface | Bright, Polished, Pickling, Acid cleaning, Sandblasting |
| Quality and test | Hardness test, Bending test, Hydrostatic etc. |
| Finish | Roll-up(Hard) |
| Surface | Polished |
Titanium Grade 2 Plate has been known for its high strength and toughness, durability and low density, and ability to withstand high and low temperatures. Commercially Pure or SB 265 Gr 2 is unalloyed. Grade 2 Titanium Sheet has higher levels of iron and oxygen than other CP grades, which offers excellent formability and moderate strength with superior corrosion resistance. Titanium Alloy Grade 2 plate has good strength to weight ratio, maintained at high temperatures. Titanium Grade 2 Clad Plate is also known as Ti Grade 2 Coil, Timetal 50A, Titan Grade 2, and Allvac 40. Titanium Cp Grade 2 Flat Sheet is higher in strength than Grade 1 Titanium Sheet, but lower in strength than Grade 3 Titanium Sheet and Grade 4 Titanium Sheet. Cp Ti Grade 2 Plate typically comes in the Annealed condition. B265 Gr2 Shim Stock is an attractive Grade due to its excellent corrosion resistance, good formability, and limited strength. Ti Cp Grade 2 Rolling Sheets is used in a variety of industries such as chemical, marine, medical, recreational, and aerospace.
Titanium Grade 2 is an unalloyed, medium strength titanium product. This titanium grade is used in airframes, aircraft engines, and marine parts; good weldability and corrosion resistance are its distinguishing characteristics. Titanium Grade 2 Cold rolled Plate & Ti Alloy Grade 2 Plates can be cold formed by standards methods.
Titanium Plate Grade And Specification
| Range | 0.4mm to 40mm |
| Standards | GB / T 3621 -44 ASTM B 265, ASME SB 265. |
| Type | Sheet, Plates, Coils, Flat, Strips, Profile, Blank ,Circle, Ring etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grades | GR I, GR -2, GR-3, GR-4, GR-5, GR-7 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium | 3.7035 / 3.7165 / 3.7235 | R50400 / R56400 / R52400 |
|
COMMERCIALLY PURE TITANIUM SHEETÂ
|
|||
|---|---|---|---|
|
GRADE
|
BRITISH
STANDARD |
FRANCE
|
GERMAN
AEROSPCE |
|
GR.1
|
BS 2TA 1
|
T-35
|
3.7024
|
Titanium Plate Value Added Services
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication Etc.
Typical Application Of Titanium Plate
- shipbuilding: in submarines
- ship’s propellers
- shafts
- rigging
- medical applications
- petrochemical applications to sporting goods
Packing Detail
Each order is packaged according to the customer’ s standards including preparation for export such as wooden case, pallet or according to customer’s requirement All shipping documentation is provided for Titanium Plate delivery from mill to customer.
