Nickel Alloy 201 Round Bar ASTM DIN EN Standard Alloy 200 Nickel UNS N02201 Bright Bar
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Nickel 201 / Nickel 200 |
| Minimum Order Quantity | 500 kgs |
| Price | 40-45 USD/Kg |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 3 Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products | Nickel Bars | Grade | UNS N02201 / Alloy 201 |
|---|---|---|---|
| Diameter | 4 - 200mm | Length | Custom Any Length As Request |
| Standard | ASTM EN | Service | Cutting |
| Loading Port | Shanghai Port | Surface | Bright |
| Highlight | Nickel Alloy 201 Round Bar,ASTM Nickel Alloy 201 Round Bar,DIN Nickel Alloy 201 Round Bar |
||
Product Description
Nickel Alloy 201 Round Bar ASTM DIN EN Standard Alloy 200 Nickel UNS N02201 Bright Bar
Products Specification
| Products Name | UNS N02201 / Nickel 201 Bars |
| Standard | ASTM B160 |
| Diameter | 4 - 200mm |
| Type | hot rolled , cold drawn |
| Length | 1m 2m 3m or custom any length as request |
| Other Shape | Pipe, sheet , plate , strip, square , hexagonal,wire |
| MOQ | 50 kgs |
| Loading Port | Shanghai Port |
| Packing | Wooden box |
| Deliver time | 4 - 15 days |
Alloy 201 (UNS N02201) is a commercially pure wrought nickel, with good mechanical properties and an excellent resistance to many corrosives. Nickel 201 has low carbon (0.02% max) for applications over 315°C it is mainly used for food processing equipment, chemical shipping drums, caustic handling equipment and piping, electronic parts, aerospace and missile components, rocket motor cases, magnetostrictive devices.
| Chemical Composition Limits | |||||||
| Weight% | Ni | Cu | Fe | Mn | C | Si | S |
| Nickel Alloy 200 | 99.0 min | 0.25 max | 0.40 max | 0.35 max | 0.15 max | 0.35 max | 0.01 max |
| Nickel Alloy 201 | 99.0 min | 0.25 max | 0.40 max | 0.35 max | 0.02 max | 0.35 max | 0.01 max |
Typical Mechanical Properties
| Material | Tensile Strength | Yield Strength (0.2% Offset) | Elongation in 2" (%) | Hardness | |||
| ksi | MPa | ksi | MPa | Brinnell (3000kg) | Rockwell B | ||
| Nickel 200 | 55-75 | 380-520 | 15-30 | 105-210 | 55-40 | 90-120 | 45-70 |
| Nickel 201 | 55-75 | 380-520 | 15-30 | 105-210 | 55-40 | 90-120 | 45-70 |
Nominal Results for Colled Rolled, Annealed Rod and Bar
Availability
Nickel 201 (UNS N02201) is available in Bar, Rods, Tube, Pipe, Plate, Sheet, Strip, Wire and Forging Stock. Nickel 210 Foil (Shim) is available in various thicknesses. View stock list for further information, Foil Stock List. For all stock availability contact Sales.
Features
Alloy 200 / 201 is similar in strength to mild steel in the annealed condition. The alloy offers exceptional resistance to caustic alkalis and good corrosion resistance in neutral and moderately reducing environments. Alloy 200/201 displays good mechanical properties over a wide temperature range.
Specifications
- UNS N02201
- BS 3072, BS 3073, BS 3074, BS 3075 and BS 3076 (NA12)
- ASTM B160, ASTM B162, ASTM B 163, ASTM B 725 and ASTM B 730
- SAE AMS 5553 Sheet, Strip
- ASME SB-160, ASME SB-163 and Boiler Code Sections III, VIII, IV
- DIN 17740, 17750, 17751, 17752, 17753 and 17754
- Werkstoff Nr. 2.4061 and WS2.4068
We stock Alloy 200 / 201 in round bar, sheet, strip, round tube and hollow bar.
TYPICAL APPLICATIONS
Commercial applications for this engineering material include:
- Food processing
- Fluorine generation
- Heat exchangers
- Tank heads
- Chemical processing & storage
- Phenol storage & transportation
- Sodium hydroxide production
- Pressure vessels & vessel components
